LDC-185
Series
Compact, LED, 200W
Constant Current
AC/DC Power Supply
Key Features:
•
200W Output Power
•
UL 8750 Approved
•
Constant Current Output
•
Active PFC
•
90 - 305 VAC Input
•
IP65 / IP67 Rated
•
Meets EN 55015, EN 61547
•
Dimming Function
Power Factor Correction
Input Current
Electrical Specifications
Specifications typical @ +25°C, 230 VAC input voltage & rated output current, unless otherwise noted. Specifications subject to change without notice.
Input
Parameter
Input Voltage Range
Input Frequency
Inrush Current, See Note 1
Conditions
Min.
90
127
47
230 VAC
115 VAC
230 VAC
264 VAC
0.98 @ 115 VAC
0.95 @ 230 VAC
0.93 @ 264 VAC
See Note 2
115 VAC
230 VAC
277 VAC
Conditions
Min.
Typ.
Max.
305
431
63
Units
VAC
VDC
Hz
A Pk
A
75
2.10
0.90
0.80
•
>50 kHour Life Expectancy
Total Harmonic Distortion (THD)
•
Lightning Surge Protection
Turn On Delay, See Note 3
•
Over Volt/Temp Protection
Leakage Current
10
1.5
0.5
75
Typ.
±5.0
±1.0
2.0
±5.0
±10.0
Max.
%
S
mA
Units
%
%
V
P-P
%
mS
°C
Output
Parameter
Output Current Accuracy
Line Regulation
Ripple & Noise (20 MHz)
Output Ripple Current
Hold-Up Time
Over Temperature Protection
Short Circuit Protection
Overload Protection
V
IN
= Min to Max
See Note 4
Outputs Below 50 VDC
Outputs Above 71 VDC
115 VAC 12.0
±10%, Autorecovery
85
Continuous (Autorecovery)
Autorecovery
95
Conditions
Min.
Input to Output 3,750
Input to FG 2,000
Output to FG
500
Input to Output
Input to FG 100 M
Output to FG
107
Max.
%
IOUT
Units
VAC
General
Parameter
Isolation Voltage, 60S
Typ.
Insulation Resistance
EMI Characteristics
Parameter
EMI
EMS
Surge
/ 500 VDC / 25°C / 70% RH
Standard
EN 55015; EN 6100-3-2, -3; FCC Part 18; CNS 14115; GB 17743
EN 61547; EN 61000-4-2,-3, -4, -5, -6, -8, -11; GB 17625.1
10 kV (L/N - FG), 5 kV (L-N)/1.2 x 50
µS
Min.
Typ.
Max.
-40
+25
+70
-40
+85
Free Air Convection (See Derating Curve on Page 2)
RH, Non-condensing
95
Ambient
Conditions
Units
°C
°C
%
MicroPower Direct
292 Page Street
Suite D
Stoughton, MA 02072
USA
T:
(781) 344-8226
F:
(781) 344-8481
E:
sales@micropowerdirect.com
W:
www.micropowerdirect.com
Environmental
Parameter
Operating Temperature Range
Storage Temperature Range
Cooling
Humidity
Physical
Case Size
Weight
See Mechanical Diagrams (Page 4)
33.1 Oz (950g)
Conditions
Min.
Typ.
Max.
Units
MIL HDBK 217F, 25°C, Gnd Benign
220
kHours
See Note 5
50
kHours
UL 8750 Approved, Meets EN 61347, GB 19510.1, GB 19510.14
5 - 500 Hz, 1G , 1 Oct/Min, 2 Cycles, Period for 75 Min. Each Along X, Y, & Z Axis
Reliability Specifications
Parameter
MTBF
Life Expectancy
Safety Standards
Vibration
www.micropowerdirect.com
Model Selection Guide
Output
Model
Number
Max
(mA)
LDC-185-0500 x
LDC-185-0700 x
LDC-185-1050 x
LDC-185-1400 x
LDC-185-3150 x
LDC-185-3850 x
LDC-185-4200 x
LDC-185-5250 x
500
700
1,050
1,400
3,150
3,850
4,200
5,250
Current
Adj. Range
(mA)
300 - 500
360 - 700
600 - 1,050
750 - 1,400
1,650 - 3,150
2,000 - 3,850
2,200 - 4,200
2,750 - 5,250
Voltage
Range
(VDC)
200 - 400
143 - 286
95 - 190
71 - 143
32 - 58
32 - 49
27 - 42
25 - 35
www.micropowerdirect.com
OVP Level
(VDC)
Output
Power
(W)
Efficiency
(%, Typ)
420 - 450
320 - 350
210 - 240
160 - 170
62 - 80
54 - 73
49 - 65
41 - 55
200
200
200
200
183
189
177
183
92
92
92
92
91
91
91
91
Notes:
1. Inrush current is given for a cold start
at 25°C.
2. Total Harmonic Distortion (THD) is
specified with an input of 230 VAC/50
Hz at full load.
3. Turn on delay is specified at full load.
4. Ripple & noise is measured at 20 MHz.
Connection to the unit is made with a 0.1 µF
ceramic capacitor and a 22 µF electrolytic
capacitor connected in parallel.
5. Life expectancy is calculated at 230 VAC,
full load and a case temp of +70°C.
6. Recovery from an over voltage fault is
automatic.
Package Type
Model
LDC-185-xxxx A
LDC-185-xxxx B
Ingress Protection
IP65
IP67
Dimming Function
Adjust by internal, variable resistor
Adjust by external resistor, DC voltage level or PWM signal
Derating Curve:
Temperature
Derating Curve:
Input Voltage
Efficiency vs Load:
LDC-185-5250
PFC vs Load:
LDC-185-5250
292 Page Street Ste D Stoughton, MA 02072
•
TEL: (781) 344-8226
•
FAX: (781) 344-8481
•
E-Mail: sales@micropowerdirect.com
Functional Block Diagram
www.micropowerdirect.com
Dimming Mode:
B Model
With the
LDC-185
“B” model, the output current level can be adjusted (Dimmed) by three different methods; Resistive, Analog or
Digital. Adjustments are made using the +DIM and -DIM inputs.
Resistive:
Connect a 0.1 to 10 k resistor between the DIM+ (Blue) and DIM- (White) wires
Input Frequency
Percentage of Rated Current
10 k
10%
20 k
20%
30 k
30%
40 k
40%
50 k
50%
60 k
60%
70 k
70%
80 k
80%
90 k
90%
100 k
100%
Open
95~105%
Analog:
Apply 1 VDC to 10 VDC level between the DIM+ (Blue) and DIM- (White) wires
Adjust Voltage
Percentage of Rated Current
1 VDC
10%
2 VDC
20%
3 VDC
30%
4 VDC
40%
5 VDC
50%
6 VDC
60%
7 VDC
70%
8 VDC
80%
9 VDC
90%
10 VDC
100%
Open
95~105%
Digital:
Apply a PWM signal (100 Hz - 3 kHz) between the DIM+ (Blue) and DIM- (White) wires
Duty Cycle
Percentage of Rated Current
10%
10%
20%
20%
30%
30%
40%
40%
50%
50%
60%
60%
70%
70%
80%
80%
90%
90%
100%
100%
Open
95~105%
Notes:
1
.
The -DIM (White) and -LED (Black) wires should not be connected.
2. The Dimming function will not turn the lighting fixture totally off. For more info on how to do this, please contact the factory
MicroPower Direct
•
292 Page Street Ste D Stoughton, MA 02072
•
TEL: (781) 344-8226
•
FAX: (781) 344-8481
•
E-Mail: sales@micropowerdirect.com
Mechanical Dimensions:
A Model
www.micropowerdirect.com
Wire Connections:
Input
Color
Green/Yellow
Brown
Blue
Function
Field Ground
AC-Line
AC-Neutral
Wire Connections:
Output
Color
Black
Red
Function
-LED
+LED
Mechanical Dimensions:
B Model (Dimming Function)
Wire Connections:
Input
Color
Green/Yellow
Brown
Blue
Function
Field Ground
AC-Line
AC-Neutral
Wire Connections:
Output
Color
White
Blue
Black
Red
Function
-DIM
+DIM
-LED
+LED
MicroPower Direct
We Power Your Success - For Less!
292 Page Street Ste D Stoughton, MA 02072
•
TEL: (781) 344-8226
•
FAX: (781) 344-8481
•
E-Mail: sales@micropowerdirect.com
