S4560P
Dual high slew rate OP AMP
Description
The S4560P is dual operational amplifiers which achieve approximately twice the high
output current of the S4560P, as well as featuring a higher slew rate of 4V/us, a gain band
width of 10MHz, and an improved frequency characteristic.
Features
•
•
•
•
•
Built-in output short-circuit protection circuit.
Internal phase correction.
No latch-up
Wide same phase mode and differential voltage ranges
High gain. low noise
Applications
•
•
•
•
Active filters
Audio amplifiers
VCOs
Other electronic circuits
Ordering Information
Type NO.
S4560P
Marking
S4560P
Package Code
DIP-8
Outline Dimensions
unit :
mm
Block Diagram
KSI-L011-000
1
S4560P
Absolute maximum ratings
Characteristic
Supply voltage
Differential input voltage
Input voltage
Power Dissipation
Operating temperature
Storage temperature
PCB(50
㎜×50 ㎜×1.6 ㎜).
(Ta =
2
5
°C
)
Symbol
V
CC
V
ID
V
IC
P
D
T
opr
T
stg
Ratings
±
18
±
30
Unit
V
V
V
mW
°C
°C
-Vcc~Vcc
800
-40 ~ +85
-55 ~ +125
* Refer to Pd characteristics diagram. The values for the S4560 are those when it is mounted on a glass epoxy
Electrical Characteristics
(Unless otherwise specified. V
CC
= +15V, V
EE
=-15V and
Ta =
2
5
°C
)
Characteristic
Input offset voltage
Input offset current
Input bias current
Input common mode
Voltage Range
Maximum Output Voltage
Symbol
V
IOS
I
IOS
I
IB
V
ICR
V
OM
Test Condition
Rg
≤
10
㏀
-
-
-
R
L
≥
10
㏀
R
L
≥
2
㏀
Vout=±10V,
Rg
≤
10
㏀
RL≥ 2
㏀
Min. Typ. Max.
-
-
-
±12
±12
±10
86
70
0.5
5
50
±14
±14
±13
100
90
6
200
500
-
-
-
-
-
Unit
mV
nA
nA
V
V
V
dB
dB
Large signal Voltage Gain
Common mode
rejection ratio
Power supply
rejection ratio
Slew Rate
Input conversion
noise voltage
Gain band width product
G
V
CMRR
PSRR
SR
V
n
GBW
Rg
≤
10
㏀
G
V
=1, R
L
≥
2
㏀
-
f=10kHz
-
-
-
-
30
4.0
-
10
150
-
2.2
-
uV/V
V/us
uV
MHz
