REV.
A
9.0 0.354
4.50 0.177
6.30 0.248
2.5 0.098
11.0 0.433
6.50 0.256
1.60 0.063
3.40 0.134
(TYP) 0.30
0.10 0.004
(TYP) 0.07
3.50 0.138
A
2.5 0.098
3.2 0.126
6.8 0.268
(2 PLCS)
10.7 0.421
3.9X6.2
(2 PLCS)
2.0 0.079
2
1.00X1.50
1.60 0.063
15.20 0.598
0.30
1
0.6 0.024
3
3.0 0.118
PCB LAYOUT
TOP VIEW
3.3X4.4
1.00X3.00
(2 PLCS)
3.2 0.126
10.7 0.421
13.6 0.535
3.1 0.122
SPECIFICATIONS:
RATING: 16V DC @ 2.5A
CONTACT RESISTANCE: 50m OHMS MAX
INSULATION RESISTANCE: 100M OHMS MIN: 500V DC
VOLTAGE WITHSTAND: 500V AC R.M.S. FOR 1 MINUTE
LIFE: 5,000 CYCLES
OPERATING TEMP: -25
°
~ +85
°
C
MATERIAL
TERMINAL 1
TERMINAL 2
TERMINAL 3
CENTER PIN
BODY
Brass
Copper Alloy
Brass
Copper
PA6T
4.60 0.181
(2 PLCS)
0.7 0.028
2
3
1
60°
6.8 0.268
(2 PLCS)
3.1 0.122
14.5 0.571
2.6 0.102
DESCRIPTION
NEW DRAWING
DATE
2/2/2007
DETAIL A
SCALE 5 : 1
0.80 0.031
2.50 0.098
1.1 0.043
4.8 0.189
1.70 0.067
9.0 0.354
TOLERANCE:
X.X ±0.2mm
X.XX ±0.1mm
X.XXX ±0.05mm
RoHS
MODEL NO.
SCHEMATIC
PJ-037B-SMT
1
3
2
PLATING
Silver
Silver
Silver
Nickel
TITLE:
PART NO.
20050 SW 112th Ave.
Tualatin, OR 97062
Phone: 503-612-2300
800-275-4899
Fax: 503-612-2383
Website: www.cui.com
2.5mm SURFACE MOUNT POWER JACK
PJ-037B-SMT
APPROVED BY:
UNITS:
REV:
A
CENTER PIN DIAMETER 2.5mm Dia.
PC FILE NAME:
MM [INCHES]
SCALE:
PJ-037B-SMT
DRAWN BY:
COPYRIGHT 2007 BY CUI INC.
ZRJ
3:1
