MH100SE
Series
Low Cost, 1W
Ultra-Miniature
DC/DC Converters
Electrical Specifications
Specifications typical @ +25°C, nominal input voltage & rated output current, unless otherwise noted. Specifications subject to change without notice.
Key Features:
•
1W Output Power
•
Ultra-Miniature Case
•
Short Circuit Protected
•
1,500 VDC Isolation
•
>3.5 MHour MTBF
•
-40°C to +105°C Operation
•
LOW COST
Input
Parameter
Conditions
Min.
3.3 VDC Input 2.97
5 VDC Input 4.50
12 VDC Input 10.80
15 VDC Input 13.50
24 VDC Input 21.60
Internal Capacitor
Conditions
Min.
Typ.
3.3
5.0
12.0
15.0
24.0
Max.
3.63
5.50
13.20
16.50
26.40
Units
Input Voltage Range
VDC
Input Filter
Output
Parameter
Output Voltage Accuracy
Capacitive Load
Line Regulation
Load Regulation, See Note 1
Ripple & Noise (20 MHz), See Note 2
Temperature Coefficient
Output Short Circuit
Typ.
±3.0
Max.
220
±1.2
Units
%
µF
%
For Vin Change of 1%
See Model Selection Guide
Output Voltage <12 VDC
30
15 VDC, 24 VDC Output
60
Continuous (Autorecovery)
Conditions
60 Seconds
500 VDC
100 kHz, 1V
Min.
1,500
1,000
Typ.
mV P - P
±0.03
%/°C
General
Parameter
Isolation Voltage
Isolation Resistance
Isolation Capacitance, See Note 3
Switching Frequency
EMI Characteristics
Parameter
EMI Compliance, See Note 5
EMC Compliance
Max.
Units
VDC
M
pF
kHz
20
100
Min.
300
Conditions
Conducted
Electrostatic Discharge (ESD)
Conditions
Typ.
Max.
Units
CISPR22/EN 55022 Level B
EN 61000-4-2 Level B Contact ±8 kV
Max.
+105
+125
95
Units
°C
°C
%
Environmental
Parameter
Operating Temperature Range
Storage Temperature Range
Cooling
Humidity
Physical
Case Size
Case Material
Weight
Min.
Typ.
Ambient
-40
-55
Free Air Convection
RH, Non-condensing
MicroPower Direct
292 Page Street
Suite D
Stoughton, MA 02072
USA
T:
(781) 344-8226
F:
(781) 344-8481
E:
sales@micropowerdirect.com
W:
www.micropowerdirect.com
0.50 x 0.394 x 0.323 Inches (12.7 x 10.0 x 8.2 mm)
Non-Conductive Black Plastic (UL-94V0)
0.06 Oz (1.8g)
Conditions
MIL HDBK 217F, 25°C, Gnd Benign
Conditions
3.3 VDC Input
5 VDC Input
12 VDC Input
12 VDC Input
24 VDC Input
1.5 mm From Case For 10 Sec
Min.
3.5
Min.
-0.7
-0.7
-0.7
-0.7
-0.7
Typ.
Max.
Units
MHours
Units
Reliability Specifications
Parameter
MTBF
Absolute Maximum Ratings
Parameter
Typ.
Max.
5.0
9.0
18.0
21.0
30.0
300
Input Voltage Surge (1 Sec)
VDC
Lead Temperature
°C
Caution: Exceeding Absolute Maximum Ratings may damage the module. These are not continuous operating ratings.
www.micropowerdirect.com
Model Selection Guide
Input
Model
Number
MH103S-05E
MH105S-05E
MH105S-09E
MH105S-12E
MH105S-15E
MH105S-24E
MH112S-05E
MH112S-09E
MH112S-12E
MH112S-15E
MH115S-15E
MH124S-05E
MH124S-09E
MH124S-12E
MH124S-15E
MH124S-24E
Output
www.micropowerdirect.com
Load Regulation
% Typ.
12.0
12.0
8.0
7.0
6.0
5.0
12.0
8.0
7.0
6.0
6.0
12.0
8.0
7.0
6.0
5.0
% Max
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
Efficiency Fuse Rating
Slow-Blow
(%, Typ)
(mA)
80
80
80
81
81
81
80
80
81
80
81
80
80
81
82
82
750
500
500
500
500
500
200
200
200
200
200
100
100
100
100
100
Voltage (VDC)
Current (mA)
Voltage Current
Current
Nominal
Range
Full-Load No-Load (VDC) (mA, Max) (mA, Min)
3
2.97 - 3.63
380
30
5.0
200.0
20.0
5
5
5
5
5
12
12
12
12
15
24
24
24
24
24
4.5 - 5.5
4.5 - 5.5
4.5 - 5.5
4.5 - 5.5
4.5 - 5.5
10.8 - 13.2
10.8 - 13.2
10.8 - 13.2
10.8 - 13.2
13.5 - 16.5
21.6 - 26.4
21.6 - 26.4
21.6 - 26.4
21.6 - 26.4
21.6 - 26.4
250
250
248
248
248
104
104
103
103
82
52
52
50
50
50
20
20
20
20
20
15
15
15
15
10
7
7
7
7
7
5.0
9.0
12.0
15.0
24.0
5.0
9.0
12.0
15.0
15.0
5.0
9.0
12.0
15.0
24.0
200.0
111.0
84.0
67.0
42.0
200.0
111.0
84.0
67.0
67.0
200.0
111.0
84.0
67.0
42.0
20.0
12.0
9.0
7.0
4.0
20.0
12.0
9.0
7.0
7.0
20.0
12.0
9.0
7.0
4.0
Notes:
1. Output load regulation is specified for a load change of 10% to 100%.
2. When measuring output ripple, it is recommended that an external 0.33
µF
ceramic capacitor be placed
from the +Vout pin to the -Vout pin.
3. The isolation capacitance of model
MH124S-24E
is 30 pF.
4. Operation at no load will not damage these units, however, they may not meet all specifications.
5. These converters are specified for operation without external components. However, in some applications
the addition of input/output capacitors will enhance stability and reduce output ripple. The simple connection
shown at right will typically meet EN 55022 Class B.
6. It is recommended that a fuse be used on the input of a power supply for
protection. See the Model Selection table above for the correct rating.
Typical Connection
Pin Connections
Pin
1
4
Description
-V
IN
+V
IN
Pin
5
7
Description
+V
OUT
-V
OUT
V
IN
C
1
L
1
6.8
µH
6.8
µH
6.8
µH
6.8
µH
6.8
µH
C
2
---
---
---
V
OUT
5 VDC
9 VDC
12 VDC
C
3
10
µF
4.7
µF
2.2
µF
1.0
µF
Mechanical Dimensions
3.3 VDC 4.7
µF/50V
5 VDC
12 VDC
15 VDC
24 VDC
4.7
µF/50V
4.7
µF/50V
4.7
µF/50V
4.7
µF/50V
470 pF/2kV 15 VDC
470 pF/2kV 24 VDC 0.47
µF
Derating Curve
Notes:
•
All dimensions are typical in inches (mm)
•
Tolerance x.xx =
±
0.01 (
±
0.25)
•
Pin 1 is marked by a “dot” or indentation
on the unit
