CBRLD102: DescriptionLow profile package; File Size1MB，2 Pages; ManufacturerCentral Semiconductor

Download Datasheet Compare View All

CBRLD102 Overview

Low profile package

Preview

Download Datasheet

View All

Product Brief

CBRLD1-02 CBRLD1-08

CBRLD1-04 CBRLD1-10

CBRLD1-06

1.0A, 200V thru 1000V Bridge Rectiﬁers

in the LPDIP package

Central Semiconductor’s CBRLD1 series is a family of full-wave

bridge rectifiers ideally suited for full-wave rectification applications

where high voltage capability, high power density, and low package

profile are critical design elements.

LPDIP

Typical Electrical Characteristics

Features:

•

Low profile package

High reverse voltage

Low reverse leakage current

Glass passivated silicon die

Applications:

• Input rectification for Solid State Lighting

• Steering diode array

• General purpose full-wave rectification

Benefits:

• High power density

• Space saving package with small footprint and

very low profile

Samples

Package Proﬁle Comparison:

The LPDIP utilizes

61%

less board space than the SMDIP

6.7

10.41mm

5.15mm

8.51mm

SMDIP

To request samples visit:

www.centralsemi.com/info/CBRLD1

Weblink

Use QR reader

for direct link to

product web page.

LPDIP

The LPDIP has a

41%

lower proﬁle than the SMDIP

1.6mm

LPDIP

SMDIP

Maximum Ratings

(TA = 25˚C)

Part Number

VRRM

(V)

MAX

CBRLD1-02

CBRLD1-04

CBRLD1-06

CBRLD1-08

CBRLD1-10

200

400

600

800

1000

(A)

MAX

1.0

TJ, Tstg

(˚C)

MAX

-55 to +150

(˚C/W)

MAX

2.69mm

Electrical Characteristics

(TA = 25˚C unless otherwise noted)

(V)

MAX

1.0

@ IF

(A)

1.0

(μA)

MAX

@ VRRM

(V)

200

400

600

800

1000

145 Adams Avenue

•

Hauppauge

•

New York

•

11788

•

USA

•

www.centralsemi.com
