76650-0004

Description
Ultra Low Profile SMT ZIF Right Angle Receptacle
File Size30KB,2 Pages
ManufacturerMolexKits
Websitehttp://www.molexkits.com
Download Datasheet Compare View All

76650-0004 Online Shopping

Suppliers Part Number Price MOQ In stock
76650-0004 - - View Buy Now

76650-0004 Overview

Ultra Low Profile SMT ZIF Right Angle Receptacle

1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0004
General Information
Part Number:
76650-0004
Manufacturer:
Title:
Description:
Product Family:
Certificates:
Country of Origin:
Specifications
Design
Configuration:
Pitch:
Connector Type:
Mounting
Orientation:
Circuit Sizes:
Current Rating:
Voltage:
Wire:
Product Highlights
Molex offers one of the industry's broadest selections of high-density
FFC/FPC connectors for Flat Panel Display (FPD) and other high pincount
applications. Molex applied its existing Easy-On™ actuator technologies
to create a robust connector that has a strong latch and is easy to use.
Wire-to-Board
0.3mm (0.012”)
Receptacles
Right Angle
11, 15, 19, 21 and 25
0.3 Amps
50 Volts AC(RMS)/DC
FPC Wire/Cable Type only
Molex / Waldom
FPC Connector Kit
Ultra Low Profile SMT ZIF Right Angle Receptacle
FFC/FPC Connectors
(Molex Parts within this kit) - EU and China RoHS Compliant
Kit assembled in U.S.A.
Features and Benefits
• Robust design, more durable than
competition
• BackFlip type actuator, strong actuator;
easy cable insertion
• Dust cover Protection from debris and
short-circuiting
• Dual-sided staggered PCB layout Enables
high-density mounting
• Design flexibility
• Low profiles, space savings
Applications
• Plasma Display Panels (PDP)
• Liquid Crystal Display (LCD) Panels
• HDTV
• TV Tuners
• Power Units
For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com
