Datasheet for 76650-0002
General Information
Part Number:
76650-0002
Manufacturer:
Title:
Description:
Product Family:
Certificates:
Molex / Waldom
Mini-Fit Sr. Power Connector Kit
Fully Polarized Single Row Plug and Receptacle
Mini-Fit Sr.™
(Molex Parts within this kit) - EU RoHS Compliant, UL, CSA and TUV
Country of Origin:
Kit assembled in U.S.A.
Specifications
Design
Configuration:
Pitch:
Connector Type:
Circuit Sizes:
Current Rating:
Voltage:
Wire size:
Product Highlights
Need for power connectors above 20 Amps. Lower mating forces with increased
reliability. More current packed into fewer lines. The system is UL, CSA and TUV
approved. -40 Degrees C to +105 Degrees C
Wire-to-Wire
10mm (.393”)
Plugs and Receptacles
2, 3, 4 and 6
(23 - 33) Amps - Depending on circuit size and wire gauge
600 Volts
(12-10) AWG
For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com
Page 1 of 2
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0002
Features and Benefits
• High current
• Fully polarized, Prevents Mis-Mating
• Positive Locks, Secure Mating, guards
against accidental disengagement of
housings
• Low engagement force for greater ease in
mating
• Includes mandatory Terminal Position
Assurance (TPA) clip
• Fully-Isolated Contacts, Withstand Reflow
Process
• Four points of electrical contact provide
high reliability
• Design Flexibility
Bill of Materials for Part No. 76650-0002
Country
Molex Part No. of Origin
42815-0011
42816-0212
42816-0312
42816-0412
42816-0612
42817-0011
42818-0212
42818-0312
42818-0412
42818-0612
USA
USA
USA
USA
USA
USA
USA
USA
USA
USA
Description
Mini-Fit Sr.™ Female Socket Terminals, 12-10 AWG
10mm (.393”) Mini-Fit Sr.™ Receptacle 2 Circuit
10mm (.393”) Mini-Fit Sr.™ Receptacle 3 Circuit
10mm (.393”) Mini-Fit Sr.™ Receptacle 4 Circuit
10mm (.393”) Mini-Fit Sr.™ Receptacle 6 Circuit
Mini-Fit Sr.™ Male Pin Terminals, 12-10 AWG
10mm (.393”) Mini-Fit Sr.™ Plug 2 Circuit
10mm (.393”) Mini-Fit Sr.™ Plug 3 Circuit
10mm (.393”) Mini-Fit Sr.™ Plug 4 Circuit
10mm (.393”) Mini-Fit Sr.™ Plug 6 Circuit
Quantity in
Kit
25
3
3
2
2
25
3
3
2
2
Applications
• High-end Computers
• Power Supplies, Generators, Battery Chargers
• Factory Automation Machines
• Cellular Base Station
• Air Conditioners
• Telecom Backplane
• Stadium Lighting and Scoreboards
• Medical Equipment
• Power Station
• Deep Well Pumps
• Welders
• Construction Signs
• Other High Amperage Devices
• HVAC
Recommended Molex Tool(s) for Part No. 76650-0002*
Country
Molex Part No. of Origin
63811-1600 *
63813-0400 *
Germany
Hand Crimper
USA
Extraction Tool
Description
*Tool(s) not included in kit. Tool(s) ordered separately.
