J5800-001 INSERTION TOOL

PRODUCT SPECIFICATION

ATP-J5800-001E

2005/03/31, Rev.- A

Molex Japan Co., Ltd.

1. Description

This tool is an Insertion Tool for the crimp terminal of Molex.

Please take the time to read attached the operating manual (IS-0004) of Insertion Tool, making

sure you understand the operating procedures described it before attempting to operate this

tool.

2. Specifications

1) Tool name:

2) Tool number:

3) Outer dimensions and weight:

4) Management method:

J5800-001 Insertion Tool

J5800-001

105 (width) x 25 (depth) x 10 (thickness) mm, Approx. 20gf

Please confirm that the terminal is locked surely with pulling

the wire lightly after inserting the terminal.

5) Applicable housing and terminal: 5025 Mini-Fit Connector

Applicable hosing number

5025

5005, 5006, 5008, 5009

5505, 5506

Applicable terminal number

3. Tool Appearance

Insertion of terminal

Insertion part

Tool point

Pull the wire

J5800-001

Terminal

Insulation barrel
