SHEET 1 OF 1
n
16.00
n
18.00
[.709 in]
n
10.40
[.630 in]
SWITCH FUNCTION
POS. 1
POS. 2
RING ILLUMINATION
COLOR: TRANSPARENT GREEN
[.409 in]
ON
PANEL CUTOUT
MAX. PANEL THICKNESS
14.0mm [.551]
1-3
(ON)
1-2
n
11.80
[.465 in]
(ON) = MOMENTARY
1
1
a
L
3
2
BODY:
STAINLESS STEEL
1.50
[.059 in]
ACTUATOR:
STAINLESS STEEL
b (+)
SPDT
CONTACT CONFIGURATION
M16x1.0
18.50
`
1.00
[.728
`
.039
in]
29.00
`
1.00
[1.142
`
.039
in]
NOTE 14
HARDWARE SUPPLIED
35.00
`
1.00
[1.378
`
.039
in]
2.00
[.079 in]
NOTE:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. CONTACT MATERIAL: SILVER
5. RATING: 2A 48VDC
6. ELECTRIC LIFE: 50,000 MAKE-AND-BREAK CYCLES
AT FULL LOAD.
7. INSULATION RESISTANCE: 1,000 M MIN.
8. DIELECTRIC STRENGTH: 2,000 VAC MIN. FOR 1 MINUTE
9. CONTACT RESISTANCE: 50m MAX. @ 1A 12VDC
10. OPERATING TEMP.: -20°C to 55°C
11. DENOTES CRITICAL PARAMETER.
12. LAMP VOLTAGE: 24V
13. ILLUMINATION COLOR: GREEN
14. HARDWARE SUPPLIED: O-RING AND HEXNUT
15. INGRESS RATING: IP67 TO FRONT PANEL
16. 2002/95/EC (ROHS) COMPLIANT
36.80
`
1.00
[1.449
`
.039
in]
(-)
1
.80
[.031 in]
2.5
[.10 in]
.40
[.016 in]
8.8
[.35 in]
(-)
1
2
3
(+)
1.80
[.071 in]
3
[.110 in]
A
REV
21545
PCR NO
INITIAL RELEASE
DESCRIPTION
8/8/14
DATE
EBP
BY
TITLE
SCALE
PV3WF2B0SS-335
DATE
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
8/8/2014
DR
EBP
DWG
52-PV3WF2B0SS335
REV
A
