Datasheet for 76650-0023
General Information
Part Number:
76650-0023
Manufacturer:
Title:
Description:
Product Family:
Certificates:
Country of Origin:
Specifications
Design
Configuration:
Pitch:
Connector Type:
Entry Angle /
Orientation:
Circuit Sizes:
Current Rating:
Voltage:
Wire size:
Product Highlights
Eurostyle terminal blocks have a standard polarizing feature,
making many of them compatible with other industry standard blocks.
Eurostyle pluggable two-piece blocks consist of vertical or
right angle plugs and vertical, or right angle headers.
Wire-to-Board
5.00mm (.197")
Pluggable (two-piece) Terminal Blocks
Horizontal / Vertical
2, 3, 4 and 6
15 Amps
300 Volts
26-12 AWG
Molex / Waldom
EuroStyle Terminal Block Kit
Pluggable PCB Vertical and Right Angle Header and Plug
Eurostyle™ Pluggable
(Molex Parts within this kit) - EU and China RoHS Compliant, UL and CSA
Kit assembled in U.S.A.
Features and Benefits
• Rising cage pressure clamp provides a
secure, reliable contact without strand
damage or intermittence
• Polarization feature prevents mismating
Applications
• Factory automation equipment
• Motor drives
• Amplifiers
• Step motors
• Controllers
• Audio Equipment
For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com
Page 1 of 2
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0023
Bill of Materials for Part No. 76650-0023
Molex Part No.
39520-0002
39521-1002
39522-1002
39520-0003
39521-1003
39522-1003
39520-0004
39521-1004
39522-1004
39520-0006
39521-1006
39522-1006
Country
of Origin
Mexico
Mexico
Mexico
Mexico
Mexico
Mexico
Mexico
Mexico
Mexico
Mexico
Mexico
China
Description
2 Position .197” (5mm) Pitch Eurostyle Right Angle Plug
2 Position .197” (5mm) Pitch Eurostyle Vertical PCB Header
2 Position .197” (5mm) Pitch Eurostyle Right Angle PCB
Header
3 Position .197” (5mm) Pitch Eurostyle Right Angle Plug
3 Position .197” (5mm) Pitch Eurostyle Vertical PCB Header
3 Position .197” (5mm) Pitch Eurostyle Right Angle PCB
Header
4 Position .197” (5mm) Pitch Eurostyle Right Angle Plug
4 Position .197” (5mm) Pitch Eurostyle Vertical PCB Header
4 Position .197” (5mm) Pitch Eurostyle Right Angle PCB
Header
6 Position .197” (5mm) Pitch Eurostyle Right Angle Plug
6 Position .197” (5mm) Pitch Eurostyle Vertical PCB Header
6 Position .197” (5mm) Pitch Eurostyle Right Angle PCB
Header
Quantity in Kit
5
5
5
5
5
5
3
3
3
3
3
3
No Recommended Molex Tool for Part No. 76650-0023
For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com
Page 2 of 2
