Datasheet> All Categories > The connector> 39100-1006

Preview

39100-1006: Description30 A, BARRIER STRIP TERMINAL BLOCK, 1 ROW, 1 DECK; CategoryThe connector; File Size30KB，2 Pages; ManufacturerMolexKits; Websitehttp://www.molexkits.com

Download Datasheet Parametric Compare View All

39100-1006 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	39100-1006	-	-	View	Buy Now

39100-1006 Overview

30 A, BARRIER STRIP TERMINAL BLOCK, 1 ROW, 1 DECK

39100-1006 Parametric

Parameter Name	Attribute value
Rated current	30 A
Rated voltage	300 V
Lead-free	Yes
EU RoHS regulations	Yes
China RoHS regulations	Yes
state	ACTIVE
contact surface	NOT SPECIFIED
Contact materials	NOT SPECIFIED
Manufacturer Series	39100
Fastening method	SCREW
Number of layers	1
Rows	1
Number of channels	2
safety certificate	UL; CSA
Terminal module type	BARRIER STRIP
Wire gauge	10 AWG

Preview

Download Datasheet

View All

1801 Morgan Street

Rockford, Illinois 61102

800-435-2931

www.molexkits.com

Datasheet for 76650-0021

General Information

Part Number:

76650-0021

Manufacturer:

Title:

Description:

Product Family:

Certificates:

Molex / Waldom

EuroStyle Barrier Strip Kit

10.00mm (.394") Pitch Two Screw Terminal Strip with Standoffs

Terminal Blocks - Beau™ Eurostyle™

(Molex Parts within this kit) - EU RoHS Compliant, UL and CSA

Country of Origin:

Kit assembled in U.S.A.

Specifications

Design

Configuration:

Pitch:

Connector Type:

Entry Angle /

Orientation:

Circuit Sizes:

Current Rating:

Voltage:

Wire size:

Product Highlights

All Two-Screw terminal strips meet applicable industry

standards and have a flammability rating of UL 94V-2.

In addition, they are designed with wire protectors to

prevent wire damage and to ensure a reliable

connection. Pre-drilled mounting holes allow for quick

and easy installation in the field.

Features and Benefits

• Modular design allows larger blocks to be

easily cut into smaller circuit sizes

• Contacts and screws are recessed in the

housing to help prevent short circuits

• Wire protectors prevent stranded wire

damage during connection

Applications

• Power supplies

• Spa controllers

• HVAC equipment

• Motor controls

• Lighting controls

Wire-to-Wire

10mm (.394")

Two-Screw Terminal Strips

Horizontal

2, 3, 4, 6, and 8

30 Amps

600 Volts

18-10 AWG

For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com

Page 1 of 2

39100-1006 Related Products

	39100-1006	39100-1002	39100-1004	39100-1008	76650-0021	39100-1003
Description	30 A, BARRIER STRIP TERMINAL BLOCK, 1 ROW, 1 DECK	30 A, BARRIER STRIP TERMINAL BLOCK, 1 ROW, 1 DECK	30 A, BARRIER STRIP TERMINAL BLOCK, 1 ROW, 1 DECK	30 A, BARRIER STRIP TERMINAL BLOCK, 1 ROW, 1 DECK	30 A, BARRIER STRIP TERMINAL BLOCK, 1 ROW, 1 DECK	30 A, BARRIER STRIP TERMINAL BLOCK, 1 ROW, 1 DECK
Rated current	30 A	30 A	30 A	30 A	30 A	30 A
Rated voltage	300 V	300 V	300 V	300 V	300 V	300 V
Lead-free	Yes	Yes	Yes	Yes	Yes	Yes
EU RoHS regulations	Yes	Yes	Yes	Yes	Yes	Yes
China RoHS regulations	Yes	Yes	Yes	Yes	Yes	Yes
state	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE
contact surface	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Contact materials	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Manufacturer Series	39100	39100	39100	39100	39100	39100
Fastening method	SCREW	SCREW	SCREW	SCREW	SCREW	SCREW
Number of layers	1	1	1	1	1	1
Rows	1	1	1	1	1	1
Number of channels	2	2	2	8	2	2
safety certificate	UL; CSA	UL; CSA	UL; CSA	UL; CSA	UL; CSA	UL; CSA
Terminal module type	BARRIER STRIP	BARRIER STRIP	BARRIER STRIP	BARRIER STRIP	BARRIER STRIP	BARRIER STRIP
Wire gauge	10 AWG	10 AWG	10 AWG	10 AWG	10 AWG	10 AWG
