39-28-1123 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 39-28-1123

39-28-1123: Description12 CONTACT(S), MALE, POWER CONNECTOR, SOLDER; CategoryThe connector; File Size31KB，2 Pages; ManufacturerMolexKits; Websitehttp://www.molexkits.com

Download Datasheet Parametric Compare View All

39-28-1123 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	39-28-1123	-	-	View	Buy Now

39-28-1123 Overview

12 CONTACT(S), MALE, POWER CONNECTOR, SOLDER

39-28-1123 Parametric

Parameter Name	Attribute value
Contact materials	NOT SPECIFIED
Total number of contacts	12
Processing package description	LEAD FREE
Lead-free	Yes
EU RoHS regulations	Yes
China RoHS regulations	Yes
state	ACTIVE
Options	GENERAL PURPOSE
Manufacturer Series	5566
Contact surface matching	tin
Contact coated terminals	tin
Connection Type	power connector
Connector male and female	Pin
collocation information	MULTIPLE MATING PARTS AVAILABLE
Installation type	BOARD
Shell material	Polyamide 66
Terminal type	welding
UL flammability code	94V-2

Preview

Download Datasheet

View All

1801 Morgan Street

Rockford, Illinois 61102

800-435-2931

www.molexkits.com

Datasheet for 76650-0015

General Information

Part Number:

76650-0015

Manufacturer:

Title:

Description:

Product Family:

Certificates:

Molex / Waldom

Mini-Fit Jr. Power Connector Kit

Vertical Header and Receptacle

Mini-Fit Jr.™

(Molex parts within this kit) - EU and China RoHS, UL, CSA and TUV

Country of Origin:

Kit assembled in U.S.A.

Specifications

Design

Configuration:

Pitch:

Connector Type:

Mounting

Orientation:

Circuit Sizes:

Current Rating:

Voltage:

Wire size:

Product Highlights

The Mini-Fit Jr. Series is designed for high current/high density applications. The

Mini-Fit Jr. is appropriate for both power and signal applications as it can carry

currents of up to 8 amps per circuit. The Mini-Fit product family accepts the same

terminals and application tooling, further reducing your design and qualification

effort.

Features and Benefits

• Fully isolated terminals

• Positive housing locks

• Four point of contact for reliability

• Low engagement force terminals

Applications

• Security and Alarms

• Vending and Gaming Machines

• White Goods

• Production Equipment

• Broadcast Equipment

• Telecom Infrastructure

Wire-to-Board

4.20mm (.165")

Receptacle and Header

Vertical

2, 3, 4, 6, 8, 10, 12, 14, 16, 18 and 20

(3 - 9) Amps dependent on AWG and circuit size

600 Volts

24-18 AWG

For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com

Page 1 of 2

39-28-1123 Related Products

	39-28-1123	39-28-1043	39-28-1143	39-28-1163	39-28-1183	39-28-1203	76650-0015	39-28-1083	39-28-1063
Description	12 CONTACT(S), MALE, POWER CONNECTOR, SOLDER	4 CONTACT(S), MALE, POWER CONNECTOR, SOLDER	14 CONTACT(S), MALE, POWER CONNECTOR, SOLDER	16 CONTACT(S), MALE, POWER CONNECTOR, SOLDER	18 CONTACT(S), MALE, POWER CONNECTOR, SOLDER	20 CONTACT(S), MALE, POWER CONNECTOR, SOLDER	8 CONTACT(S), FEMALE, POWER CONNECTOR, RECEPTACLE	8 CONTACT(S), MALE, POWER CONNECTOR, SOLDER	6 CONTACT(S), MALE, POWER CONNECTOR, SOLDER
Contact materials	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Total number of contacts	12	4	14	16	18	20	8	8	6
Lead-free	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes
EU RoHS regulations	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes
state	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Manufacturer Series	5566	5566	5566	5566	5566	5566	5557	5566	5566
Contact surface matching	tin	tin	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Contact coated terminals	tin	tin	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Connection Type	power connector	power connector	power connector	POWER CONNECTOR	POWER CONNECTOR	POWER CONNECTOR	power connector	power connector	power connector
Connector male and female	Pin	Pin	Pin	MALE	MALE	MALE	Jack	Pin	Pin
collocation information	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE
Installation type	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD	CABLE	BOARD	BOARD
Shell material	Polyamide 66	Polyamide 66	Polyamide 66	POLYAMIDE66	POLYAMIDE66	POLYAMIDE66	Polyamide 66	Polyamide 66	Polyamide 66
UL flammability code	94V-2	94V-2	94V-2	94V-2	94V-2	94V-2	94V-2	94V-2	94V-2
Processing package description	LEAD FREE	LEAD FREE	LEAD FREE	LEAD FREE	LEAD FREE	LEAD FREE	-	LEAD FREE	LEAD FREE
China RoHS regulations	Yes	Yes	-	-	Yes	-	-	Yes	Yes
Terminal type	welding	welding	welding	SOLDER	SOLDER	SOLDER	-	welding	welding
