Datasheet> All Categories > The connector> 39-28-1023
PDF
Preview

39-28-1023

Description
2 CONTACT(S), MALE, POWER CONNECTOR, SOLDER
CategoryThe connector
File Size30KB，2 Pages
ManufacturerMolexKits
Websitehttp://www.molexkits.com
Download Datasheet Parametric Compare View All

39-28-1023 Online Shopping

Suppliers Part Number Price MOQ In stock
39-28-1023 - - View Buy Now

39-28-1023 Overview

2 CONTACT(S), MALE, POWER CONNECTOR, SOLDER

39-28-1023 Parametric

Parameter NameAttribute value
Contact materialsNOT SPECIFIED
Total number of contacts2
Processing package descriptionLEAD FREE
Lead-freeYes
EU RoHS regulationsYes
China RoHS regulationsYes
stateACTIVE
OptionsGENERAL PURPOSE
Manufacturer Series5566
Contact surface matchingNOT SPECIFIED
Contact coated terminalsNOT SPECIFIED
Connection Typepower connector
Connector male and femalePin
collocation informationMULTIPLE MATING PARTS AVAILABLE
Installation typeBOARD
Shell materialPolyamide 66
Terminal typewelding
UL flammability code94V-2

Preview

Download Datasheet
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0082
General Information
Part Number:
Manufacturer:
Title:
Description:
Product Family:
Certificates:
76650-0082
Molex / Waldom
Mini-Fit Jr. Connector Kit
Vertical Header and Receptacle, 2 Circuit
Mini-Fit Jr.™
(Molex parts within this kit) - EU and China RoHS, UL, CSA and TUV
Country of Origin:
Kit assembled in U.S.A.
Specifications
Design
Configuration:
Pitch:
Connector Type:
Mounting
Orientation:
Circuit Sizes:
Current Rating:
Voltage:
Wire size:
Product Highlights
The Mini-Fit Jr. Series is designed for high current/high density applications. The
Mini-Fit Jr. is appropriate for both power and signal applications. The Mini-Fit
product family accepts the same terminals and application tooling, further reducing
your design and qualification effort.
Features and Benefits
• Fully isolated terminals
• Positive housing locks
• Four point of contact for reliability
• Low engagement force terminals
Applications
• Security and Alarms
• Vending and Gaming Machines
• White Goods
• Production Equipment
• Broadcast Equipment
• Telecom Infrastructure
Wire-to-Board
4.2mm (.165")
Receptacles and Headers
Vertical
2
6 Amps
600 Volts
24-18 AWG
For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com
Page 1 of 2

39-28-1023 Related Products

39-28-1023 76650-0082
Description 2 CONTACT(S), MALE, POWER CONNECTOR, SOLDER 2 CONTACT(S), MALE, POWER CONNECTOR, SOLDER
Contact materials NOT SPECIFIED NOT SPECIFIED
Total number of contacts 2 2
Processing package description LEAD FREE LEAD FREE
Lead-free Yes Yes
EU RoHS regulations Yes Yes
China RoHS regulations Yes Yes
state ACTIVE ACTIVE
Options GENERAL PURPOSE GENERAL PURPOSE
Manufacturer Series 5566 5566
Contact surface matching NOT SPECIFIED NOT SPECIFIED
Contact coated terminals NOT SPECIFIED NOT SPECIFIED
Connection Type power connector power connector
Connector male and female Pin Pin
collocation information MULTIPLE MATING PARTS AVAILABLE MULTIPLE MATING PARTS AVAILABLE
Installation type BOARD BOARD
Shell material Polyamide 66 Polyamide 66
Terminal type welding welding
UL flammability code 94V-2 94V-2
