Non-Polar Aluminum Electrolytic Capacitors
RADIAL LEADS NON-POLARIZED ALUMINUM ELECTROLYTIC CAPACITORS
FEATURES
• DESIGNED FOR APPLICATIONS WITH REVERSIBLE POLARITY
• LOW AC VOLTAGE CAN BE SUPERIMPOSED WITHIN THE LIMITED
ARIPPLE
CURRENT
NNR Series
CHARACTERISTICS
Rated Voltage Range
Capacitance Range
Operating Temperature Range
Capacitance Tolerance
Max. Leakage Current
After 5 minutes At +20°C
Surge Voltage &
Max. Tan
δ
@ 120Hz/+20°C
Low Temperature Stability
(Impedance Ratio @ 120Hz)
Load Life Test at Rated W.V. & +85°C
2,000 Hours (Polarity Shall Be
Reversed Every 250 Hours
10 ~ 100Vdc
1.0 ~ 1,000μF
-40 ~ +85°C
±20%(M)
includes all homogeneous materials
RoHS
Compliant
*See Part Number System for Details
P N b S
f D il
0.03CV +8μA
W.V. (Vdc)
S.V. (Vdc)
Tan
δ
Z-25°C/Z+20°C
Z-40°C/Z+20°C
Capacitance Change
Tan
δ
Leakage Current
10
13
0.20
3
8
16
25
35
50
100
20
32
44
63
125
0.18
0.14
0.13
0.09
0.10
2
2
2
2
2
6
4
3
3
3
Within ±25% of initial measured value
Less than 200% of specified maximum value
Less than specified maximum value
STANDARD PRODUCTS AND
CASE SIZE TABLE D
φ
x L (mm)
Cap. (μF)
1.0
2.2
3.3
4.7
10
22
33
47
100
220
330
470
1000
10
-
-
-
-
-
5x11
5x11
5x11
6.3x11
8x12.5
10x12.5
10x16
12.5x20
Working Voltage (Vdc)
16
25
35
50
-
-
-
5x11
-
-
-
5x11
-
-
-
5x11
-
5x11
5x11
5x11
5x11
5x11
5x11
6.3x11
5x11
5x11
6.3x11 8x11.5
5x11
6.3x11 6.3x11 8x11.5
6.3x11 6.3x11 8x11.5 10x12.5
8x11.5 8x11.5 10x12.5 10x20
10x12.5 10x16 10x20 12.5x25
10x16 10x20 12.5x25
-
10x20 12.5x20 12.5x25
-
12.5x25
-
-
-
100
5x11
5x11
6.3x11
6.3x11
8x12.5
10x16
10x20
12.5x25
-
-
-
-
-
LEAD SPACING AND DIAMETER (mm)
Case Dia. (Dφ)
Lead Dia. (dφ)
Lead Space (F)
Dim.
α
Dim.
β
5
0.5
2.0
0.5
1.5
6.3
0.5
2.5
0.5
1.5
8
0.6
3.5
0.5
1.5
10 12.5
0.6 0.6
5.0 5.0
0.5 0.5
1.5 1.5
DIMENSIONS (mm)
Insulation Sleeve
dφ ± 0.05
F ± 0.5
L +
β
max.
15mm Min.
4mm
Min.
Dφ ±
α
Drawing is representative of parts as supplied in bulk or
straight lead format, please see taping specification for details
on taped format packaging.
PART NUMBERING SYSTEM
NNR 101 M 25V 8X11.5 TB F
RoHS Compliant
TB = Tape & Box*
Case Size (Dφ x L)
Working Voltage (Vdc)
Tolerance Code (M=20%)
Cap. Code: First 2 characters significant
Third character is multiplier
Series
*see taping specifications for details
PRECAUTIONS
Please review the notes on correct use, safety and precautions found on
pages T10
&
T11
of NIC’s
Electrolytic Capacitor catalog.
Also found at
www.niccomp.com/precautions
If in doubt or uncertainty, please review your specific application - process
details with NIC’s technical support personnel:
tpmg@niccomp.com
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
SPECIFICATIONS ARE SUBJECT TO CHANGE
