Customer Specification

PART NO. 5020/25C

Construction

Diameters (In)

1) Component 1

a) Conductor

b) Insulation

(1) Color Code

Cond

1

Color

BLACK

25 X 1 COND

24 (7/32) AWG Tinned Copper

0.010" Wall, Nom. PVC, Semi Rigid

Alpha Wire Color Code E

Cond

10

Color

WHITE

Cond

19

Color

WHITE/SLATE

0.024

0.044

2

BROWN

11

WHITE/BLACK

20

WHITE/BLACK/BROW

N

WHITE/BLACK/RED

3

RED

12

WHITE/BROWN

21

4

ORANGE

13

WHITE/RED

22

WHITE/BLACK/ORAN

GE

5

YELLOW

14

WHITE/ORANGE

23

WHITE/BLACK/YELL

OW

6

GREEN

15

WHITE/YELLOW

24

WHITE/BLACK/GREE

N

WHITE/BLACK/BLUE

7

8

9

2) Cable Assembly

a) Twists:

b) Orientation:

c) Core Wrap

3) Jacket

a) Color(s)

b) Ripcord

BLUE

VIOLET

SLATE

16

17

18

25 Components Cabled

4.0 Twists/foot (min)

WHITE/GREEN

WHITE/BLUE

WHITE/VIOLET

25

Components to be arranged from INSIDE

LAYER to OUTSIDE LAYER

Nonwoven Polyester Tape, 25% Overlap, Min.

0.032" Wall, Nom.,PVC

0.332 (0.351 Max.)

Slate, Black, Yellow, Orange, Blue, Green, Red, Sand Beige, White

1 End 810 Denier Nylon

ALPHA WIRE-* P/N 5020/25C 25C 24 AWG

XTRAGUARD(R) 1 (UL) TYPE CM 105C OR AWM 2464 80C

300V OR AWM 21894 105C 300V SUN RES 60C OIL

VW-1 --- LLXXXXXX CSA 105C TYPE CMG FT4

CE ROHS (SEQ FOOTAGE)

* = Factory Code

[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.]

c) Print

Applicable Specifications

1) UL

a) Component 1

b) Overall

AWM/STYLE 10002

AWM/STYLE 21894

SUN RES

60C OIL

AWM/STYLE 2464

CM

VW-1

2) CSA International

CMG

FT4

3) IEC

EN 60332-1 Flame Behavior

EN 60332-2 Flame Behavior

4) CE:

EU Low Voltage Directive 2014/35/EC

105°C

80°C / 300 VRMS

105°C

105°C / 300 V

RMS

105°C / 300 VRMS

Environmental

1) CE: EU Directive 2011/65/EU(RoHS2):

This product complies with European Directive 2011/65/EU (RoHS Directive) of the European

Parliament and of the Council of 8 June 2011and the amending Directive 2015/863/EU of 4 June

2015 . No Exemptions are required for RoHS Compliance on this item. Consult Alpha Wire's web

site for RoHS C of C.

2) REACH Regulation (EC 1907/2006):

This product does not contain Substances of Very High Concern (SVHC) listed on the European

Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information,

please see Alpha's REACH SVHC Declaration.

3) California Proposition 65:

Exempt from warning labels based on the Consent Judgment. Please see Alpha's CA Prop 65

Statement for more information.

Properties

Physical & Mechanical Properties

1) Temperature Range

2) Bend Radius

3) Pull Tension

4) Sunlight Resistance

Electrical Properties

1) Voltage Rating

2) Capacitance

3) Inductance

4) Conductor DCR

-35 to 105°C

10X Cable Diameter

88 Lbs, Maximum

Yes

(For Engineering purposes only)

300 VRMS

21.8 pF/ft @1 kHz, Nominal Conductor to Conductor

0.19 µH/ft, Nominal

26 Ω/1000ft @20°C, Nominal

Other

Packaging

a) 1000 FT

b) 500 FT

c) 100 FT

d) Bulk(Made-to-order)

Flange x Traverse x Barrel (inches)

18 x 12 x 8 Continuous length

16 x 11 x 8 Continuous length

12 x 10 x 5 Continuous length

[Spool dimensions may vary slightly]
