Features
■
Shielded construction
■
Inductance range: 1.5 to 330 µH
■
Heating current up to 7 A
■
AEC-Q200 qualified
■
RoHS compliant* and halogen free**
330
SRU1048A Series - Shielded Power Inductors
Electrical Specifications @ 25 °C
Bourns
Part Number
Inductance
@ 100 KHz / 1 V
L (µH)
Tol. (%)
Q
(Ref.)
Test
Freq.
(MHz)
SRF
(MHz)
Typ.
DCR
(mΩ)
Max.
I rms
(A)
I sat
(A)
General Specifications
Operating Temperature
................................-40 °C to +125 °C
(Temperature rise included)
Storage Temperature
................................-40 °C to +125 °C
Resistance to Soldering Heat
............................. +245 °C for 10 sec.
Temperature Rise
......................30 °C typ. at rated I rms
Inductance Drop .......... 35 % typ. at I sat
Materials
Core ..............................................Ferrite
Wire ............................Enameled copper
Terminal Finish .........................Ag/Ni/Sn
Packaging .................... 600 pcs. per reel
Product Dimensions
10.0 ± 0.3
(.394 ± .012)
SRU1048A-1R5Y
SRU1048A-2R2Y
SRU1048A-3R0Y
SRU1048A-4R7Y
SRU1048A-6R8Y
SRU1048A-8R2Y
SRU1048A-100Y
SRU1048A-150Y
SRU1048A-220Y
SRU1048A-330Y
SRU1048A-470Y
SRU1048A-560Y
SRU1048A-680Y
SRU1048A-820Y
SRU1048A-101Y
SRU1048A-151Y
SRU1048A-221Y
SRU1048A-331Y
1.5
2.2
3.0
4.7
6.8
8.2
10
15
22
33
47
56
68
82
100
150
220
330
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
14
14
14
12
10
8
26
30
22
24
26
26
24
24
26
24
20
18
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
0.796
0.796
0.796
0.796
70
55
40
30
20
18
16
14
12
10
8
7
6
5.5
5
4.5
4
3
5.8
7.2
10
12.5
18
20
25
40
55
84
120
145
170
200
220
305
455
640
7.0
6.5
6.2
5.5
4.8
4.6
4.5
3.2
2.6
2.1
1.7
1.6
1.4
1.3
1.2
1.0
0.8
0.65
7.2
6.3
6.0
4.75
4.1
3.8
3.7
2.7
2.0
1.7
1.5
1.4
1.25
1.1
1.0
0.8
0.7
0.52
How to Order
SRU1048A - 100Y
Model
Value Code (see table)
Electrical Schematic
10.0 ± 0.3
(.394 ± .012)
Inductor Connection
7.4
TYP.
(.291)
4.8 ± 0.3
(.189 ± .012)
3.4
(.134)
TYP.
LCR METER
3.2
(.126)
TYP.
3.4
TYP.
(.134)
Asia-Pacific:
Tel: +886-2 2562-4117 • Fax: +886-2 2562-4116
Europe:
Tel: +41-41 768 5555 • Fax: +41-41 768 5510
The Americas:
Tel: +1-951 781-5500 • Fax: +1-951 781-5700
www.bourns.com
Recommended Layout
7.2
(.283)
1.8
(.071)
1.8
(.071)
WARNING Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
* RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.
**Bourns considers a product to be “halogen free” if (a) the Bromine (Br) content is 900 ppm or less; (b) the Chlorine
(Cl) content is 900 ppm or less; and (c) the total Bromine (Br) and Chlorine (Cl) content is 1500 ppm or less.
Specifications are subject to change without notice. Users should verify actual device performance in their specific
applications. The products described herein and this document are subject to specific legal disclaimers as set forth on
the last page of this document, and at
www.bourns.com/docs/legal/disclaimer.pdf
4.0
(.157)
DIMENSIONS:
MM
(INCHES)
