SHIELDED SMD POWER INDUCTOR

Preview

Download Datasheet

View All

SHIELDED SMD POWER

INDUCTOR

P171004 SERIES

• RoHS Compliant Product

• Inductance measured : < 100µH : 100KHz, 0.25V

RMS

• Inductance measured :

100µH : 1KHz, 0.25V

RMS

• Inductance Tolerance: K=±10%, L=15±%, M=±20%

Add suffix letter for tolerance after the part number

• I

RATED

: Max 10% inductance drop and

∆T=40°C

Temp Rise

• Operating Temperature: -40°C to +85°C

ELECTRICAL SPECIFICATION @ 25°C

PART NO

±20%

(µH)

1.0

1.5

2.2

2.4

2.8

3.8

5.2

7.0

100

150

220

330

DCR

Max

(W)

0.006

0.008

0.010

0.011

0.013

0.022

0.027

0.035

0.050

0.073

0.093

0.128

0.213

0.304

0.506

0.756

1.090

RATED

(A)

13.60

10.00

7.60

7.50

7.30

6.00

5.50

4.80

4.40

3.60

2.90

2.30

2.10

1.50

1.35

1.15

0.92

0.70

Mechanical

P171004-

1R0

1R5

2R2

2R4

2R8

3R8

5R2

7R0

100

150

220

330

470

680

101

151

221

331

Schematic

Dimensions

Unless otherwise specified, all tolerances are:

inch: .XX : ± 0.015 .XXX : ±0.010

mm: X,X : ± 0,38 X,XX : ±0,25

Product performance is limited to specified parameter. Data is subject to change without prior notice.

P171004-XX
