UNISONIC TECHNOLOGIES CO., LTD
L8562
POWER FACTOR CORRECTOR
DESCRIPTION
The UTC
L8562
is a Power Factor Corrector, which can work in
wide input voltage range applications (from 85V ~ 265V) with an
excellent THD. It has very low start up current (about 20 uA) and
a disable function on the ZCD pin, which is designed to keep
lower current consumption in stand by mode.
The device is operating in transition mode, and is able to drive
a Power MOS or IGBT with a ± 400mA current for sourcing and
sinking.
LINEAR INTEGRATED CIRCUIT
FEATURES
* 1% Precision (@ T
J
= 25℃) Internal Reference Voltage
* Output Overvoltage Protection
* Very Low Power Start-Up Current
* Current Sense Filter On Chip
* Disable Function (with ZCD pin)
* Transition Mode Operation
* Gate Driving Current: ± 400mA
* 15V Gate clamped
ORDERING INFORMATION
Ordering Number
Lead Free
Halogen Free
L8562L-D08-T
L8562G-D08-T
L8562L-S08-R
L8562G-S08-R
L8562L-S08-T
L8562G-S08-T
Package
DIP-8
SOP-8
SOP-8
Packing
Tube
Tape Reel
Tube
www.unisonic.com.tw
Copyright © 2011 Unisonic Technologies Co., LTD
1 of 6
QW-R119-018.C
L8562
PIN CONFIGURATION
LINEAR INTEGRATED CIRCUIT
PIN DESCRIPTION
PIN NO
1
2
3
4
5
6
7
8
PIN NAME
INV
COMP
MULT
CS
ZCD
GND
GD
V
CC
DESCRIPTION
Inverting input of the error amplifier.
Output of the error amplifier.
Input of the multiplier stage.
Input of the current sense stage.
Input of the zero current detection .
Ground.
Gate driver output.
Voltage supply.
BLOCK DIAGRAM
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
+
2 of 6
QW-R119-018.C
L8562
PARAMETER
Analog Inputs & Outputs
Current Sense Input
Iq+Iz (I
GD
= 0)
Output Totem Pole Peak Current (2ms)
SYMBOL
INV, COMP MULT
CS
IV
CC
I
GD
LINEAR INTEGRATED CIRCUIT
ABSOLUTE MAXIMUM RATING
(T
A
=25℃, unless otherwise specified)
RATINGS
UNIT
-0.3 ~ 7
V
-0.3 ~ 7
V
30
mA
±700
mA
50 (source)
mA
Zero Current Detector
ZCD
-10 (sink)
mA
SOP-8
1
W
Power Dissipation @ T
A
=50℃
P
D
DIP-8
0.65
W
Junction Temperature
T
J
125
℃
Operating Temperature
T
OPR
-20 ~ +85
℃
Storage Temperature
T
STG
-40 ~ +150
℃
Note 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
2. The device is guaranteed to meet performance specification within 0℃~70
℃
operating temperature range
and assured by design from –20℃~85℃.
ELECTRICAL CHARACTERISTICS
(V
CC
=12V, T
A
=-25
℃
~ 125℃, unless otherwise specified)
PARAMETER
SUPPLY VOLTAGE SECTION
Operating Range
Turn-on Threshold
Turn-off Threshold
Hysteresis
SUPPLY CURRENT SECTION
Start-up Current
Quiescent Current
Operating Supply Current
Quiescent Current
Zener Voltage
ERROR AMPLIFIER SECTION
Voltage Feedback Input
Threshold
Line Regulation
Input Bias Current
Voltage Gain
Gain Bandwidth
Source Current
Sink Current
Upper Clamp Voltage
Lower Clamp Voltage
MULTIPLIER SECTION
Linear Operating Voltage
Output Max.Slope
Gain
PIN
8
8
8
8
8
8
8
8
8
8
1
1
SYMBOL
V
CC
V
CC(ON)
V
CC OFF
Hys
I
START-U
Iq
I
CC
Iq
V
Z
V
INV
I
INV
G
V
G
B
I
COMP
V
COMP
V
MULT
△
V
CS
△
V
MULT
K
V
CCON
-1V
C
L
=1nF @ 70KHz
In OVP condition V
pin1
=2.7V
V
PIN5
≤150mA,
V
CC
>V
CC off
V
PIN5
≤150mV,
V
CC
<V
CC
off
I
CC
=20mA
T
A
=25℃
10.3V<V
CC
<18V
V
CC
=10.3 ~ 18V
Open loop
V
COMP
=4V, V
INV
=2.4V
V
COMP
=4V, V
INV
=2.6V
I
SOURCE
=0.5mA
I
SINK
=0.5mA
TEST CONDITIONS
after turn-on
MIN
11
14
7.2
6.5
TYP
MAX
18
16.5
8.7
8.3
50
9
15
6.8
6
10
24
2.535
2.56
5
-1
UNIT
V
V
V
V
μA
mA
mA
mA
mA
μA
V
V
V
mV
μA
dB
MHz
mA
mA
V
V
V
15.3
7.9
30
6
10
4
18
2.465
2.44
7
21
2.5
3
-0.1
80
0.8
-4
4.5
5
2.4
60
-2
2.5
4.5
2.25
2
2
3
-8
5.5
2.55
0~ 2.5 0 ~ 3.5
V
MULT
=from 0V ~ 0.5V
V
COMP
=Upper Clam Voltage
V
MULT
=1V, V
COMP
=4V
1.65
0.5
1.9
0.7
0.9
1/V
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
3 of 6
QW-R119-018.C
L8562
ELECTRICAL CHARACTERISTICS
(Cont.)
PARAMETER
CURRENT SENSE COMPARATOR
Current Sense Reference Clamp
Input Bias Current
Delay to Output
ZERO CURRENT DETECTOR
Input Threshold Voltage Rising Edge
Hysteresis
Upper Clamp Voltage
Upper Clamp Voltage
Lower Clamp Voltage
Sink Bias Current
Source Current Capability
Sink Current Capability
Disable threshold
Restart Current After Disable
OUTPUT SECTION
Dropout Voltage
PIN SYMBOL
4
4
4
5
5
5
5
5
5
5
5
5
V
CS
I
CS
t
D(H-L)
V
ZCD
V
ZCD
V
ZCD
V
ZCD
I
ZCD
I
ZCD
I
ZCD
V
DIS
I
ZCD
(Note)
(Note)
I
ZCD
=20μA
I
ZCD
=2.5mA
I
ZCD
=-2.5mA
1V
≦
V
ZCD
≦
4.5V
LINEAR INTEGRATED CIRCUIT
TEST CONDITIONS
V
MULT
=2.5V
V
COMP
=Upper Clamp Voltage
V
OS
=0
MIN
1.6
TYP
1.7
-0.05
200
2.1
0.6
6.5
6.6
0.7
2
MAX
1.8
-1
450
UNIT
V
μA
ns
V
V
V
V
V
μA
mA
mA
mV
μA
V
V
V
ns
ns
mA
μA
V
μs
0.4
5.9
6.1
0.3
-3
3
100
-20
0.8
7.3
7.5
1
-10
10
300
V
ZCD
<V
DIS
, V
CC
>V
CCOFF
I
GD(SOURCE)
=200mA
I
GD(SOURCE)
=20mA
I
GD(SINK)
=200mA
C
L
=1nF
C
L
=1nF
V
CC
=3.5V, V
GD
=1V
200
-50
1.2
0.8
1.2
40
40
40
40
2.4
130
7
V
GD
Output Voltage Rise Time
7
t
R
Output Voltage Fall Time
7
t
F
IGD Sink Current
7
I
GD(OFF)
OUTPUT OVERVOLTAGE SECTION
OVP Triggering Current
2
I
OVP
Static OVP Threshold
RESTART TIMER
Start Timer
t
START
Note: Parameter guaranteed by design, not tested in production.
2
1.2
1.9
100
100
10
30
2.25
70
50
2.55
300
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
4 of 6
QW-R119-018.C
L8562
TYPICAL APPLICATION CIRCUIT
150W, Wide-range mains
T1 PFC CHOKE
11
7
BD1
1 2KBP06M
+
2
-
4
R1
620K/
1206
R6
620K/
1206
R2
2
62K/1206
R7
56K/1206
C1
10nF/0805
D2 1N4148
C4
1μF/
400V
R3
110/
0805
6
R8
22K/1206
LINEAR INTEGRATED CIRCUIT
D1
BYC5-600
+
F1
2.0A/250V
~ V
AC
(90V~264V)
3
R4
750K/1206
R9
750K/1206
R5 10K/0805
C3
1μF/0805
5 2
1
R13
7 10/1206
D3 1N4148
ZCD COMP INV
R14
10K/
0805
C8
10nF/
0805
C6
22μF/50V
3
MULT
UTC
8
VCC
GND
L8562
CS
GD
Q1
12N65
R11
19K/
0.25W
C5
120μF/
450V
R12
19K/
0.25W
6 4
ZD1
ZD18.0
R16
0.47/1W
R17
0.47/1W
-
