PDS1-S3-S3-M Overview

2-OUTPUT 1W DC-DC UNREG PWR SUPPLY MODULE

PDS1-S3-S3-M Parametric

Parameter Name	Attribute value
Brand Name	CUI Inc
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Parts packaging code	MODULE
package instruction	SMT-8/5
Contacts	8/5
Reach Compliance Code	compli
Analog Integrated Circuits - Other Types	DC-DC UNREGULATED POWER SUPPLY MODULE
Maximum input voltage	3.63 V
Minimum input voltage	2.97 V
Nominal input voltage	3.3 V
JESD-30 code	R-PDMA-G5
length	12.7 mm
Number of functions	1
Output times	1
Number of terminals	5
Maximum operating temperature	100 °C
Minimum operating temperature	-40 °C
Nominal output voltage	3.3 V
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum seat height	7.5 mm
surface mount	YES
technology	HYBRID
Temperature level	INDUSTRIAL
Terminal form	GULL WING
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum total power output	1 W
Fine-tuning/adjustable output	NO
width	8.3 mm
Base Number Matches	1

Preview

Download Datasheet

View All

For more information, please visit the

product page.

date

page

07/03/2018

1 of 8

SERIES:

PDS1-M

│

DESCRIPTION:

DC-DC CONVERTER

FEATURES

• 1 W isolated output

• smaller package

•

single and dual unregulated outputs

1,500 Vdc isolation

short circuit protection

extended temperature range (-40~105°C)

antistatic protection up to 8kV

high efficiency at light load

efficiency up to 82%

MODEL

typ

(Vdc)

input

voltage

range

(Vdc)

output

voltage

(Vdc)

min

(mA)

output

current

max

(mA)

output

power

max

(W)

ripple

and noise

typ

(mVp-p)

efficiency

typ

(%)

PDS1-S3-S3-M

PDS1-S3-S5-M

PDS1-S3-D5-M

PDS1-S3-D12-M

PDS1-S3-D15-M

PDS1-S5-S3-M

3.3

2.97~3.63

4.5~5.5

10.8~13.2

13.5~16.5

3.3

±5

±12

±15

3.3

±5

±9

±12

±15

±24

3.3

±5

±9

±12

±15

±24

±10

±5

±3

±10

±6

±5

±3

±2

±10

±6

±5

±3

±2

303

200

±100

±42

±33

303

200

111

±100

±56

±42

±33

±21

303

200

111

±100

±56

±42

±33

±21

PDS1-S5-S5-M

PDS1-S5-S9-M

PDS1-S5-S12-M

PDS1-S5-S15-M

PDS1-S5-S24-M

PDS1-S5-D5-M

PDS1-S5-D9-M

PDS1-S5-D12-M

PDS1-S5-D15-M

PDS1-S5-D24-M

PDS1-S12-S3-M

PDS1-S12-S5-M

PDS1-S12-S9-M

PDS1-S12-S12-M

PDS1-S12-S15-M

PDS1-S12-D5-M

PDS1-S12-D9-M

PDS1-S12-D12-M

PDS1-S12-D15-M

PDS1-S12-D24-M

PDS1-S15-S15-M

Notes:

1. UL approved

2. Ripple and noise are measured at 20 MHz BW by “parallel cable” method with 1 μF ceramic and 10 μF electrolytic capacitors on the output.

cui.com
