1503A Paired - Single-Pair Cable
For more information please
call
1-800-Belden1
See Put-ups and Colors
Description:
22 AWG stranded (7x30) TC conductors, PVC insulation, twisted pair, overall Beldfoil shield (100% coverage), 24 AWG stranded TC drain
wire, PVC jacket.
PHYSICAL CHARACTERISTICS:
CONDUCTOR:
Number of Pairs
Total Number of Conductors
AWG
Stranding
Conductor Material
INSULATION:
Insulation Material
Nom. Insulation Wall Thickness
Lay Length
Twists/ft.
Pair Color Code Chart :
Number
1
OUTER SHIELD:
Outer Shield Material Trade Name
Outer Shield Type
Outer Shield Material
Outer Shield %Coverage
OUTER SHIELD DRAIN WIRE :
Outer Shield Drain Wire AWG
Outer Shield Drain Wire Stranding
Outer Shield Drain Wire Conductor Material
OUTER JACKET:
Outer Jacket Material
Outer Jacket Nominal Wall Thickness
OVERALL NOMINAL DIAMETER:
PVC - Polyvinyl Chloride
.020 in.
Page 1 of 3
1
2
22
7x30
TC - Tinned Copper
PVC - Polyvinyl Chloride
.010 in.
1.75 in.
6.86
Color
Black & Red
Beldfoil®
Tape
Aluminum Foil-Polyester Tape
100 %
24
7x32
TC - Tinned Copper
1503A Paired - Single-Pair Cable
Overall Nominal Diameter
MECHANICAL CHARACTERISTICS:
Operating Temperature Range
UL Temperature Rating
Bulk Cable Weight
Max. Recommended Pulling Tension
Min. Bend Radius (Install)
.142 in.
-30°C To +90°C
60°C
14.3 lbs/1000 ft.
25 lbs.
1.5 in.
APPLICABLE SPECIFICATIONS AND AGENCY COMPLIANCE:
APPLICABLE STANDARDS:
NEC/(UL) Specification
CEC/C(UL) Specification
EU CE Mark (Y/N)
EU RoHS Compliant (Y/N)
EU RoHS Compliance Date (mm/dd/yyyy):
FLAME TEST:
UL Flame Test
PLENUM/NON-PLENUM:
Plenum (Y/N)
ELECTRICAL CHARACTERISTICS:
Nom. Characteristic Impedance
Nom. Inductance
Nom. Capacitance Conductor to Conductor @ 1 KHz
Nom. Cap. Cond. to Other Cond. & Shield @ 1 KHz
Nominal Velocity of Propagation
Nominal Delay
Nom. Conductor DC Resistance @ 20 Deg. C
Nominal Outer Shield DC Resistance @ 20 Deg. C
Max. Operating Voltage - UL
Max. Recommended Current
38 Ohms
.18 µH/ft
53 pF/ft
97 pF/ft
66 %
1.5 ns/ft
14.7 Ohms/1000 ft
18 Ohms/1000 ft
300 V RMS
2.9 Amps per conductor @ 25°C
N
UL1666 Riser
CM
CM
Yes
Yes
04/01/2005
PUT-UPS AND COLORS:
Item
Description
1503A 001U1000
2 #22 PVC FS
FRPVC
1503A 002U1000
2 #22 PVC FS
FRPVC
1503A 003U1000
2 #22 PVC FS
FRPVC
Put-Up (ft.)
U1000
U1000
U1000
Ship Weight (lbs.)
16
16
16
Jacket Color
BROWN
RED
ORANGE
Notes
Page 2 of 3
1503A Paired - Single-Pair Cable
1503A 004U1000
1503A 006U1000
1503A 007U1000
1503A 008U1000
1503A 009U1000
1503A 010U1000
1503A N3UU1000
Revision Number: 1
2 #22 PVC FS
FRPVC
2 #22 PVC FS
FRPVC
2 #22 PVC FS
FRPVC
2 #22 PVC FS
FRPVC
2 #22 PVC FS
FRPVC
2 #22 PVC FS
FRPVC
2 #22 PVC FS
FRPVC
U1000
U1000
U1000
U1000
U1000
U1000
U1000
16
16
16
16
16
16
16
YELLOW
BLUE, LIGHT
VIOLET
GRAY
WHITE
BLACK
GREEN, MIL
Revision Date: 07-27-2005
© Copyright 2006 Belden, Inc
All Rights Reserved.
Although Belden ("Belden") makes every reasonable effort to ensure their accuracy at the time of this publication, information and
specifications described herein are subject to error or omission and to change without notice, and the listing of such information and
specifications does not ensure product availability.
Belden provides the information and specifications herein on an "AS IS" basis, with no representations or warranties, whether express,
statutory or implied. In no event will Belden be liable for any damages (including consequential, indirect, incidental, special, punitive, or
exemplary damages) whatsoever, even if Belden has been advised of the possibility of such damages, whether in an action under contract,
negligence or any other theory, arising out of or in connection with the use, or inability to use, the information or specifications described
herein.
All sales of Belden products are subject to Belden's standard terms and conditions of sale.
Belden believes this product to be in compliance with the following environmental regulations: California Proposition 65 Consent Judgment
For Wire & Cable Mfgs.(San Francisco Superior Court Nos. 312962 And 320342); EU RoHS (Directive 2002/95/EC, 27-Jan-
2003);Material manufactured prior to the compliance date may still be in stock at Belden facilities and in our Distributor's inventory. EU
ELV (Directive 2000/53/EC, 18-Sept-2000); EU WEEE (Directive 2002/96/EC, 27-Jan-2003); And EU BFR (Directive 2003/11/EC, 6-Feb-
2003). The information provided in this Product Disclosure, and the identification of materials listed as reportable or restricted within the
Product Disclosure, is correct to the best of Belden's knowledge, information and belief at the date of its publication. The information
provided in the Product Disclosure is designed only as a general guide for the safe handling, storage, and any other operation of the product
itself or the one that it becomes a part of. This Product Disclosure is not to be considered a warranty or quality specification. Regulatory
information is for guidance purposes only. Product users are responsible for determining the applicability of legislation and regulations
based on their individual usage of the product.
Belden declares this product to be in compliance with EU LVD (Low Voltage Directive 73/23/EEC), as amended by directive 93/68/EEC.
Page 3 of 3
