ZRL-700: DescriptionLow Noise Amplifier 50з 250 to 700 MHz; CategoryWireless rf/communication Radio frequency and microwave; File Size182KB，1 Pages; ManufacturerMini-Circuits; Websitehttps://www.minicircuits.com

Download Datasheet Parametric View All

ZRL-700 Overview

Low Noise Amplifier 50з 250 to 700 MHz

ZRL-700 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Mini-Circuits
package instruction	CASE FJ893
Reach Compliance Code	unknow
Other features	SMA
Characteristic impedance	50 Ω
structure	COAXIAL
Gain	27 dB
Maximum input power (CW)	10 dBm
JESD-609 code	e0
Number of functions	1
Maximum operating frequency	700 MHz
Minimum operating frequency	250 MHz
Maximum operating temperature	60 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
Encapsulate equivalent code	MODULE(UNSPEC)
power supply	12 V
RF/Microwave Device Types	WIDE BAND MEDIUM POWER
Terminal surface	Tin/Lead (Sn/Pb)
Maximum voltage standing wave ratio	1.1

Preview

Download Datasheet

View All

High IP3

Low Noise Amplifier

50Ω 250 to 700 MHz

Maximum Ratings

Operating Temperature

Storage Temperature

DC Voltage

-40°C to 80°C case

-40°C to 60°C ambient

-55°C to 100°C

+17V max.

EW!

ZRL-700

Features

•

high IP3, +46 dBm typ.

low noise figure, 2.0 dB typ.

broadband flat gain response

internal voltage regulated

over voltage and transient protected

high dynamic range applications

mobile radio service

NMT 450 cellular service

aeronautical communications

UHF television

CASE STYLE: FJ893

PRICE: $119.95 ea. QTY (1-9)

Applications

Outline Drawing

FREQ.

RANGE

(MHz)

- f

250-700

300-500

Electrical Specifications (T

AMB

=25°C)

GAIN

(dB)

Flatness

Typ. Min.

29 27

29 27.5

Typ.

±0.5

±0.3

Max. Typ. Max.

±1.0

±0.7

2.0

3.5

NOISE MAXIMUM POWER

(dBm)

FIGURE

(dB)

Output

(1 dB Comp.)

Typ. Min.

24.8 23.5

Input

(no

damage)

+10

INTER-

CEPT

POINT

IP3

dBm

Typ.*

VSWR

(:1)

Typ.

Out

DIRECTIVITY

(dB)

POWER

Max.

Volt

Current

Typ. (mA)

550

Typ.

14.5

1.20 1.10

1.10 1.05

* 1MHz tone spacing

Other voltages available in the 6.5 to 17V range, please contact factory.

ZRL-700

GAIN

GAIN (dB)

NOISE FIGURE (dB)

2.8

2.6

2.4

2.2

2.0

250

ZRL-700

NOISE FIGURE

Outline Dimensions (

inch

)

2.00 3.75

.80 3.00

50.80 95.25 20.32 76.20

.26 1.00

.51

6.60 25.40 12.95

.22

5.59

.19 3.374 1.624

4.83 85.70 41.25

.26

6.60

—

.19

4.83

.156

.44

3.96 11.18

wt.

.10 grams

2.54

135

250

300

350

400

450

500

550

600

650

700

300

350

400

450

500

550

600

650

700

FREQUENCY (MHz)

ZRL-700

IP3

IP3 (dBm)

VSWR

1.20

ZRL-700

VSWR

INPUT

1.16

1.12

1.08

1.04

1.00

250

OUTPUT

250

300

350

400

450

500

550

600

650

700

340

430

520

610

700

FREQUENCY (MHz)

Mini-Circuits

INTERNET

http://www.minicircuits.com

P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661

Distribution Centers

NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010

ISO 9001 CERTIFIED

REV. E

M92817

ZRL-700

EDB011108

BLUEC/RS/CP

040608
