MPM-10SV
Series
85 to 305 VAC Input, 10W
Miniature PC Mount
AC/DC Power Supplies
Electrical Specifications
Key Features:
•
10W Output Power
•
Universal 85-305 VAC Input
•
EN 60950 Approved
•
Six Single Output Models
•
Meets EN 55022 B
•
>300 kHour MTBF
•
Compact PC Mount Case
Specifications typical @ +25°C, 230 VAC input voltage & rated output current, unless otherwise noted. Specifications subject to change without notice.
Input
Parameter
Input Voltage Range
Input Frequency
Input Current
Inrush Current
Leakage Current
Conditions
Min.
Typ.
85
100
47
See Model Selection Guide
115 VAC
10.0
230 VAC
15.0
230 VAC/50 Hz
0.3
Max.
305
430
63
Units
VAC
VDC
Hz
A Pk
mA rms
Max.
Units
Output
Parameter
Output Voltage
Output Current
Minimum Load
Output Voltage Accuracy
Line Regulation
Load Regulation
Ripple & Noise (20 MHz)
Hold-Up Time
Temperature Coefficient
Short Circuit Protection
Overload Protection
Conditions
Min.
Typ.
See Model Selection Guide
See Model Selection Guide
0
±2.0
V
IN
= Min to Max
±0.5
See Note 2
±1.0
See Note 3
50
115 VAC
15
80
230 VAC
±0.02
Continuous (Autorecovery)
Autorecovery
110
Conditions
Input to Output, 60S
Input to FG, 60S
Min.
3,000
2,000
Typ.
100
%
%
%
%
mV Pk - Pk
mSec
%/°C
%
General
Parameter
Isolation Voltage
Switching Frequency
Max.
Units
VAC
100
Conditions
Min.
Typ.
Max.
Ambient
-40
+25
+70
-40
+105
Free Air Convection (See Derating Curve)
RH, Non-condensing
95
kHz
Units
°C
°C
%
Environmental
Parameter
Operating Temperature Range
Storage Temperature Range
Cooling
Humidity
Physical
Case Size
Case Material
Weight
MicroPower Direct
292 Page Street
Suite D
Stoughton, MA 02072
USA
T:
(781) 344-8226
F:
(781) 344-8481
E:
sales@micropowerdirect.com
W:
www.micropowerdirect.com
See Mechanical Diagram On Page 4
Non-Conductive Black Plastic (UL94-V0)
2.64 Oz (75g)
Conditions
Min.
Typ.
MIL HDBK 217F, 25°C, Gnd Benign
300
Wave Solder
Hand Solder
UL 60950, EN 60950
Class I
Max.
260
360
Units
kHours
°C
Reliability Specifications
Parameter
MTBF
Lead Temperature, See Note 4
Safety Standards
Safety Class
www.micropowerdirect.com
Model Selection Guide
Input
Model
Number
MPM-10SV-03
MPM-10SV-05
MPM-10SV-09
MPM-10SV-12
MPM-10SV-15
MPM-10SV-24
Current
(A)
115
VAC
0.26
0.26
0.26
0.26
0.26
0.26
230
VAC
0.16
0.16
0.16
0.16
0.16
0.16
Voltage
(VDC)
www.micropowerdirect.com
Output
Current
(A Max.)
Power
(W)
Over Volt.
Protection
(VDC)
Capacitive
Load
(µF, Max)
Efficiency
(%, Typ)
3.3
5.0
9.0
12.0
15.0
24.0
2.00
2.00
1.10
0.90
0.70
0.45
6.60
10.0
10.0
10.0
10.0
10.0
7.5
7.5
12.0
20.0
20.0
30.0
26,000
9,400
3,600
2,400
1,200
370
70
76
78
80
81
82
Notes:
1. Operation at no load will not damage the units, however, they
may not meet all specifications.
2. Load regulation is measured for an output change of 10% to
100% at nominal input line.
3. When measuring output ripple, it is recommended that an
external 0.1
µF
high frequency ceramic capacitor be placed
in parallel with a 47
µF
high frequency electrolytic capacitor
from the +V
OUT
pin to the -V
OUT
pin.
4. The max lead temp for wave soldering is
±5%
for a time
period of 5 to 10S. For hand soldering, it is
±10%
for 3 to 5S.
5. All units are rated for EN 55022 (CE/RE) class B without
external components.
6. All units are rated for EN 61000-4-4 (±2 kV) with the addi-
tion of the MOV shown in the typical connection below. They
will meet EN 61000-4-4 (±4 kV) with the additional input
components shown in the typical connection diagram shown
on page 3.
7. All units are rated for EN 61000-4-5 (±1 kV/±2 kV) with the addi-
tion of the MOV shown in the typical connection below. They will
meet EN 61000-4-5 (±2 kV /±4 kV) with the input components
shown in the typical connection diagram on page 3.
8. It is recommended that a fuse be used on the input of a power
supply for protection. For the
MPM-10SV-xx
series, a
2.0A/300 VAC slow blow should be used.
MPD
offers a wide variety of input protection and
filtering modules for use with our AC & DC power
modules. The
MACFM-02A
may be used with
the
MPM-10SV,
as shown on page. Full data-
sheets for all our input modules are available on
our website, or call the factory for a more help.
Typical Connection
The diagram above illustrates a typical application connection of the
MPM-10SV
series. Notes on this circuit (starting with the input circuit) are:
1. It is recommended that an external fuse and NTC be used. The
recommended fuse is a 1.0A/300 VAC slow blow.
2. All units are rated for EN 55022 (CE/RE) class B without external
components.
3. All units are rated for EN 61000-4-4 (±2 kV) with the addition of
the MOV shown in the typical connection above. They will meet
EN 61000-4-4 (±4 kV) with the additional input components
shown in the typical connection diagram shown on page 3.
4. All units are rated for EN 61000-4-5 (±1 kV/±2 kV) with the addi-
tion of the MOV shown in the typical connection above. They will
meet EN 61000-4-5 (±2 kV /±4 kV) with the input components
shown in the typical connection diagram on page 3.
5. If output noise levels lower than the specified limits are required,
the addition of C
1
and C
2
should be sufficient for most applications.
The recommended values are shown in the table at right. The
output filtering capacitor C
2
is a high frequency, low resistance
electrolytic capacitor. Capacitor C
1
is ceramic. Voltage derating
of capacitors should be 80% or above.
6. The TVS is added to protect circuits being powered from damage
if the module fails.
Model
MPM-10SV-03
MPM-10SV-05
MPM-10SV-09
MPM-10SV-12
MPM-10SV-15
MPM-10SV-24
C
1
1.0
µF/50V
1.0
µF/50V
1.0
µF/50V
1.0
µF/50V
1.0
µF/50V
1.0
µF/50V
C
2
470
µF/10V
330
µF/10V
120
µF/25V
120
µF/25V
120
µF/25V
68
µF/35V
TVS
SMBJ7.0A
SMBJ7.0A
SMBJ12A
SMBJ20A
SMBJ20A
SMBJ30A
Derating Curve
Input Voltage Vs Load
292 Page Street Ste D Stoughton, MA 02072
•
TEL: (781) 344-8226
•
FAX: (781) 344-8481
•
E-Mail: sales@micropowerdirect.com
EMI Characteristics
Parameter
Radiated Emissions
Conducted Emissions
ESD
RS
EFT
Surge
CS
PFM
Voltage Dips, Short, Interruptions
EN 61000-4-4
EN 61000-4-5
Conditions
EN 55022
EN 55022
EN 61000-4-2
EN 61000-4-3
See Note 1
See Note 2
EN 61000-4-6
EN 61000-4-8
EN 61000-4-11
www.micropowerdirect.com
Criteria
B
A
B
B
B
B
A
A
B
Level
Class B
Class B
±8 kV Air
±6 kV Contact
10V/m
±2 kV
±4 kV
±1 kV/±2 kV
±2 kV/±4 kV
10V rms
10A/m
0% - 70%
Notes:
1. To meet the requirements of EN 61000-
4-4 (±4 kV), external components are
needed. This can be done discretely (as
shown below), or with the addition of the
MACFM-02A.
Contact the factory for more
information.
2. To meet the requirements of EN 61000-4-5
(±2 kV/
±4
kV ), external components are
needed. This can be done discretely (as
shown below), or with the addition of the
MACFM-02A.
Contact the factory for more
information.
Typical Connection:
With Input Protection/Filtering Components
The diagram above illustrates a typical connection of the
MPM-10SV
series. 5. Suggested component values are:
The input components are required to meet the more stringent EFT/Surge levels
Component
MPM10SV-03 MPM10SV-05 MPM10SV-09 MPM10SV-12 MPM10SV-15 MPM10SV-24
of EN 61000-4 (see notes for EMC Characteristics table above). Some notes on
2.0A/300 VAC
2.0A/300 VAC
2.0A/300 VAC
2.0A/300 VAC
2.0A/300 VAC
2.0A/300 VAC
Fuse
these components are:
MOV
S14K350
S14K350
S14K350
S14K350
S14K350
S14K350
1. It is recommended that an external fuse be used. The recommended fuse
size is a 2.0A/300 VAC slow blow.
0.1
µF/310V
0.1
µF/310V
0.1
µF/310V
0.1
µF/310V
0.1
µF/310V
0.1
µF/310V
C
X
2. An external MOV is recommended on the input to protect the unit in the event
LDM
4.7
µH/2A
4.7
µH/2A
4.7
µH/2A
4.7
µH/2A
4.7
µH/2A
4.7
µH/2A
of a surge. A recommended value is given in the table at right.
LCM
10 mH
10 mH
10 mH
10 mH
10 mH
10 mH
3. The output filtering capacitors (C
1
& C
2
) will reduce the output noise below
1,000 pF/400VAC 1,000 pF/400VAC 1,000 pF/400VAC 1,000 pF/400VAC 1,000 pF/400VAC 1,000 pF/400VAC
C
Y1
/C
Y2
specified levels. Recommended values are given in the table on page 2.
4. The TVS is added to protect circuits being powered from damage if the module
6. Input protection and filtering modules are available for a number of
MPD
AC/DC power supplies. For use with the
MPM-10SV
product series,
fails. A recommended value for each model is given in the table on page 2.
the
MACFM-02A
filter module is recommended. A typical connection diagram and board layout with this module is shown in the figures
below. For pricing or full technical information on the
MACFM-02A
(or any of our other modules) please contact the factory.
Typical Board Layout
: With External Filter Module
Typical Board Layout
: With External Filter Module
1. The width of circuit traces should be a minimum of 3 mm.
2. The distance between traces should be a minimum of 6 mm.
3. The distance between a trace and ground should be a minimum of 6 mm.
MicroPower Direct
•
292 Page Street Ste D Stoughton, MA 02072
•
TEL: (781) 344-8226
•
FAX: (781) 344-8481
•
E-Mail: sales@micropowerdirect.com
Mechanical Dimensions
www.micropowerdirect.com
Pin Connections
Pin
1
2
3
4
8
Function
AC-Ground
AC-Neutral
AC-Line
-V
OUT
+V
OUT
Notes:
•
All dimensions are typical in inches (mm)
•
Tolerance x.xx = ±0.02 (±0.50)
Other Power Ranges
Series
Input
Output Voltage
3.3 VDC
5.0 VDC
9.0 VDC
12.0 VDC
15.0 VDC
24.0 VDC
3.3 VDC
5.0 VDC
9.0 VDC
12.0 VDC
15.0 VDC
24.0 VDC
48.0 VDC
3.3 VDC
5.0 VDC
9.0 VDC
12.0 VDC
15.0 VDC
24.0 VDC
3.3 VDC
5.0 VDC
9.0 VDC
12.0 VDC
15.0 VDC
24.0 VDC
48.0 VDC
Output Current
1.250A
1.000A
0.550A
0.420A
0.330A
0.230A
3.000A
2.800A
1.600A
1.250A
1.000A
0.625A
0.320A
3.500A
3.500A
2.100A
1.600A
1.300A
0.850A
4.100A
4.100A
2.500A
2.100A
1.600A
1.100A
0.500A
Module Dimensions
The
MPM-10SV
family is part of a
series of products that range from 5W to
25W. The chart at left gives a summary
of the other models in this series. Full
data on all products is available on the
MPD
website. Contact the factory for
more information.
MPM-05SV
85 - 305 VAC
2.16 x 1.77 x 0.83
(55.0 x 45.0 x 21.0)
MPM-15SV
85 - 305 VAC
2.44 x 1.77 x 0.88
(62.0 x 45.0 x 22.5)
MPM-20SV
85 - 305 VAC
2.75 x 1.88 x 0.92
(70.0 x 48.0 x 23.5)
MPM-25SV
85 - 305 VAC
2.75 x 1.88 x 0.92
(70.0 x 48.0 x 23.5)
MicroPower Direct
We Power Your Success - For Less!
292 Page Street Ste D Stoughton, MA 02072
•
TEL: (781) 344-8226
•
FAX: (781) 344-8481
•
E-Mail: sales@micropowerdirect.com
