TECHNICAL DATA SHEET
Coax RG178 PE PVC
code
version
date
page
MRG1781
1
2006-07-11
1/2
APPLICATION
Coaxial communication cable based on MIL-C-17.
CONSTRUCTION
1 2
3
4
1
2
3
4
Inner conductor
Dielectric
Braid
Sheath
Silver plated, copper cladded steel
Solid PE
Tinned copper
PVC according the European Standard HD 624.
REQUIREMENTS AND TEST METHODS
Test methods in accordance with European standard EN 50289.
Mechanical characteristics
1. Inner conductor.
Diameter:
2. Dielectric:
Diameter:
3. Outer conductor:
Diameter screen:
Coverage braid:
4. Sheath:
Diameter:
5. Cable:
Storage/operating temperature:
Minimum installation temperature:
Total weight:
7 x 0.1 mm
0.3 mm
±
0.02 mm
0.84 mm
±
0.15 mm
1.37 mm
±
0.15 mm
95 %
±
4 %
1.8 mm
±
0.1 mm
-25°C to +70°C
-5
°C
8.5 g/m
©
Belden Wire & Cable B.V.
All rights are reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner
TECHNICAL DATA SHEET
Coax RG178 PE PVC
Electrical characteristics
Mean characteristic impedance:
Regularity of impedance:
DC resistance inner conductor:
Capacitance:
Nominal velocity of propagation:
Voltage Rating
DC:
RMS
Nominal Attenuation:
10 MHz:
19
200 MHz:
63
400 MHz:
92
1000 MHz:
151
50
±
2
Ω
> 40 dB
≤
802 Ohm/km
100 pF/m
±
3 pF/m
66 %
1.0 kVdc
0.6 kVrms
code
version
date
page
MRG1781
1
2006-07-11
2/2
dB/100m
dB/100m
dB/100m
dB/100m
Belden CDT believes this product to be in compliance with the environmental regulations EU RoHS (Directive 2002/95/EC,
27 January 2003); this is valid for all material produced after the RoHS compliant date for this product.
©
Belden Wire & Cable B.V.
All rights are reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner
