FEATURES
UL & VDE CERTIFICATION
SMALL PHYSICAL FOOTPRINT
ENVIRONMENTALLY PROTECTED
COST EFFECTIVE DESIGN OPTION
INPUT 115V OR 230V / SINGLE AND DUAL OUTPUT
SPLIT BOBBIN DESIGN – ISOLATED PRIMARY
AND SECONDARY WINDINGS
SELF-EXTINGUISHING PLASTICS UL94V-0
DIELECTRIC STRENGTH 4200Vrms
INHERENTLY ENERGY LIMITED
RESIN CLASS B IEC 85, VACUUM SEALED
CONFORMS TO EN 61558 AND EN 60950
100% PRODUCTION TESTED
SEALED POWER TRANFORMERS
BV SERIES EI30 0.6VA – 2.8VA
OUTLINE DIMENSIONS
MECHANICAL DATA:
WIRING DIAGRAM:
Dual outputs
6
15.40
5
7
9
SCHEMATIC DIAGRAM:
Dual outputs
Input
Output
6
7
9
10
5.00±0.50
10,0±0.2
5,0±0.20
Ø0,8 TYP.
5
5,0±0.2
10,0±0.2
1
Input
1
1
6
27.80
20,0±0.20
5
7
9
10
27.80
20,0±0.20
5
7
9
Single output
7
1
5
9
Single output
Input
Output
7
1
20,0±0.20
32.8
20,0±0.20
32.8
5
1
Dual outputs
Single output
Input
1
9
1
