Pico Electronics: SERIES VV/SVV
Page 1 of 6
SERIES VV/SVV
Low Voltage, Low Profile
Plug-In and Surface Mount
Single Output, Isolated, Proportional Modules
100 to 500 V dc at 4W Output
The VV/SVV Series of Single Output, Isolated, Proportional DC-DC Converters are manufactured in a miniature encapsolated package. The
Series features Surface Mount and Plug-In versions of all units. The operating termperature range of -25ºC to + 70ºC required no current
derating and/or heat sink.
FEATURES
Miniature, Surface Mount and Plug-In
Single Output, Isolated, 4 W max. Output Power
5V, 12V, 24V, 28V, and 48Vdc Standard Input Voltages
100V to 500Vdc in 5 Standard Output Voltages
Vout Proportional to Vin over wide voltage range
Maximum Load Current capability maintained over entire input range
High Efficiency: to 90%
Low Ripple: 0.2% to 0.5% Vout
Operating Temperature: -25ºC to +70ºC, no heat sink required
Low Profile: 0.400" Height
Epoxy encapsulation
OPTIONS AVAILABLE
TYPICAL CHARACTERISTICS:
Test Conditions:
+25ºC
Operating Temperature Range:
-25ºC to +70ºC, with no heat sink
or electrical derating required
Storage Temperature Range:
-55ºC to +125ºC
Converter Frequency:
8-25 kHz
Output Temperature Coefficient (typ.):
0.02%/ºC
http://www.picoelectronics.com/dcdclow/peVV_SVV.htm?PartNo=5SVV100S
12/18/2007
Pico Electronics: SERIES VV/SVV
Page 2 of 6
Per Mil. Std. 883
Expanded Operating Temperature: -40ºC to +85ºC
Stabilization Bake (at +125ºC ambient)
Temperature Cycle (between -55ºC and +125ºC)
Hi Temp, Burn-in Cycle
Vibration, Shock, Humidity, and Altitude
Consult factory for your particular requirments
SERIES VV/SVV
PICO
Part
Number
PLUG-IN
5VV100S
5VV200S
5VV300S
5VV400S
5VV500S
12VV100S
12VV200S
12VV300S
12VV400S
12VV500S
24VV100S
24VV200S
24VV300S
24VV400S
24VV500S
28VV100S
28VV200S
28VV300S
28VV400S
28VV500S
48VV100S
SURFACE
MOUNT
5SVV100S
5SVV200S
5SVV300S
5SVV400S
5SVV500S
12SVV100S
12SVV200S
12SVV300S
12SVV400S
12SVV500S
24SVV100S
24SVV200S
24SVV300S
24SVV400S
24SVV500S
28SVV100S
28SVV200S
28SVV300S
28SVV400S
28SVV500S
48SVV100S
Input Voltage
Range
(VDC)
Min
2.5
2.5
2.5
2.5
2.5
4.0
4.0
4.0
4.0
4.0
6.0
6.0
6.0
6.0
6.0
7.0
7.0
7.0
7.0
7.0
14
Max
5
5
5
5
5
12
12
12
12
12
24
24
24
24
24
28
28
28
28
28
48
*
Maximum
Load Current
(mA)
40
20
13.5
10
8
40
20
13.5
10
8
40
20
13.5
10
8
40
20
13.5
10
8
40
Output Voltage
Range
(VDC)
Min
47
90
130
175
220
30
60
90
120
150
23
48
70
95
120
23
48
70
95
120
27
Max
100
200
300
400
500
100
200
300
400
500
100
200
300
400
500
100
200
300
400
500
100
Max.
Output
Power
(Watts)
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
Typical
Efficiency
@ Full Load
& VIN,MAX.
(%)
83
82
82
81
81
87
85
85
84
84
85
84
84
83
83
85
84
84
83
83
89
Ripple
Typical
at
Full Load
(%)
0.5
0.5
0.3
0.3
0.2
0.5
0.5
0.3
0.3
0.2
0.4
0.4
0.3
0.3
0.2
0.4
0.4
0.3
0.3
0.2
0.5
Price
($)
109.00
119.00
129.00
139.00
149.00
109.00
119.00
129.00
139.00
149.00
109.00
119.00
129.00
139.00
149.00
109.00
119.00
129.00
139.00
149.00
109.00
http://www.picoelectronics.com/dcdclow/peVV_SVV.htm?PartNo=5SVV100S
12/18/2007
Pico Electronics: SERIES VV/SVV
Page 3 of 6
48VV200S
48VV300S
48VV400S
48VV500S
48SVV200S
48SVV300S
48SVV400S
48SVV500S
14
14
14
14
48
48
48
48
20
13.5
10
8
50
73
98
130
200
300
400
500
4
4
4
4
89
90
89
89
0.5
0.2
0.2
0.2
119.00
129.00
139.00
149.00
(*) Unit is capable of sourcing Maximum Load Current over entire Input Voltage Range
Safety Note:
The high voltage power supplies described in this datasheet generate voltages which can be lethal. They should only be installed and used by personnel
who have received the appropriate training and who are fully aware of the hazards that exist.
Series SVV SURFACE MOUNT
http://www.picoelectronics.com/dcdclow/peVV_SVV.htm?PartNo=5SVV100S
12/18/2007
Pico Electronics: SERIES VV/SVV
Page 5 of 6
For immediate engineering assistance or to place an order:
Call Toll Free: 800-431-1064
http://www.picoelectronics.com/dcdclow/peVV_SVV.htm?PartNo=5SVV100S
12/18/2007
