DATA SHEET
SEMICONDUCTOR
YSESDAR5V0SP-10P
SMD ESD Protection Diode
FEATURES
◆
IEC61000-4-2 (ESD)±14kV(Contact),±15kV(Air).
◆
Working voltage: 5.0 V
◆
Low leakage current.
◆
Low capacitance: 0.15 pF typical (I/O to GND)
DFN10P
0.100(2.55)
0.096(2.45)
H
0.041(1.05)
0.037(0.95)
◆
Case: DFN10p package,molded plastic.
◆
Terminals: Gold plated, solderable per
MIL-STD-750,method 2026.
0.008(0.20) Typ.
◆
Mounting position: Any
Circuit diagram
I/O
Pin 1
I/O
Pin 2
I/O
Pin 4
I/O
Pin 5
Package
0.016(0.40) Typ.
0.022(0.55)
0.018(0.45)
N/C
N/C
N/C
N/C
10
9
8
7
6
GND
0.014(0.35) Typ.
1
I/O
GND
Pin 3
2
I/O
3
4
I/O
5
I/O
Dimensions in inches and (millimeters)
Maximum Rating
(at T
A
=25°C unless otherwise noted)
Parameter
Peak pulse power ( tp = 8/20 us)
Peak pulse current ( tp = 8/20 us)
ESD per IEC 61000-4-2(Air)
ESD per IEC 61000-4-2(Contact)
Operating temperature
Storage temperature
Symbol
P
PP
I
PP
ESD
T
J
T
STG
Value
60
3
±15
±14
-55 to +125
-55 to +150
Unit
W
A
kV
°C
°C
Electrical Characteristics
(at TA=25 °C unless otherwise noted)
Parameter
Reverse stand-off voltage
Breakdown voltage
Leakage current
Clamping voltage
Junction capacitance
I
R
= 1mA
V
R
= 5.0V
I
PP
= ±1A, Tp = 8/20us
Any Channel Pin to Ground
V
R
= 0 V, f = 1MHz
Any Channel Pin to Ground
Conditions
Symbol
V
RWM
V
BR
I
L
V
C
C
j
Min
Typ
Max
5.0
Unit
V
V
6.0
50
12
0.15
0.25
nA
V
pF
http://www.yeashin.com
1
REV.01 20150530
0.014(0.35) Typ.
MECHANICAL CHARACTERISTICS
DEVICE CHARACTERISTICS
YSESDAR5V0SP-10P
RATING AND CHARACTERISTIC CURVES
Fig.1 - 8/20us Peak Pulse Current
Waveform ACC. IEC 61000-4-5
120%
100%
Fig.2 - Typical Capacitance Between
Terminals Characteristics
0.30
Peak Valur Ipp
Capacitance Between Terminals, (pF)
Ta=25°C
Test Waveform
parameters
tf=8us
td=20us
f=1MHz
T
A
=25°C
0.25
0.20
0.15
0.10
0.05
0.00
0
1
2
3
4
5
Percentage of Ipp
80%
60%
40%
20%
0%
0
5
e-t
td= t Ipp/2
10
15
20
25
30
Time, (us)
Fig.3 - Typical Clamping Voltage Vs.
Peak Pulse Current
30
120
Fig.4 - Power Rating Derating Curve
Mounting on glass epoxy PCBs
25
100
Clamping Voltage, (V)
Power Rating, (%)
Waveform
Parameters:
tr=8us
td=20us
20
80
60
15
10
40
20
0
0
25
50
75
100
125
150
5
0
1
1.5
2.0
2.5
3.0
Peak Pulse Current, (A)
Ambient Temperature, ( °C )
http://www.yeashin.com
2
REV.01 20150530
