DATA SHEET
SEMICONDUCTOR
YSOTxxC-A
TVS DIODE ARRAY
FOR LATCH-UP PROTECTION
APPLICATIONS
◆
Portable Electronics
◆
Cellular Handsets and Accessories
◆
Industrial Controls
◆
Portable instrumentation
◆
Set-Top Box
◆
Peripherals
◆
AEC-Q 101 qualified
H
SOT-23
IEC COMPATIBILITY
◆
IEC61000-4-2 (ESD) ±30kV (air), ±30kV (contact) -- 3.0V~15V
◆
IEC61000-4-2 (ESD) ±15kV (air), ±8kV (contact) -- 24V~36V
◆
IEC61000-4-4 (EFT) 40A (5/50ηs)
◆
IEC61000-4-5 (Lightning) 5A (8/20µs)
PIN CONFIGURATION
FEATURES
◆
400 Watts Peak Pulse Power per Line (tp=8/20µs)
◆
Protects two I/O lines
◆
Low clamping voltage
◆
Working voltages: 3.0V ~ 36V
◆
Low leakage current
MECHANICAL CHARACTERISTICS
◆
JEDEC SOT-23 Package
Base P/N - RoHS compliant, commercial grade
Base P/N-A - RoHS compliant, AEC-Q101 qualified
◆
Molding Compound Flammability Rating : UL 94V-O
◆
Weight 8 Millgrams (Approximate)
◆
Quantity Per Reel : 3,000pcs
◆
Reel Size : 7 inch
◆
Lead Finish : Lead Free
http://www.yeashin.com
1
REV.02 20131002
DEVICE CHARACTERISTICS
YSOTxxC-A
MAXIMUM RATINGS (@ 25℃ Unless Otherwise Specified)
PARAMETER
Peak Pulse Power (tp=8/20µs waveform)
Lead Soldering Temperature
Operating Temperature Range
Storage Temperature Range
SYMBOL
P
PP
T
L
T
J
T
STG
VALUE
400
260 (10 sec.)
-55 ~ 150
-55 ~ 150
UNITS
Watts
℃
℃
℃
ELECTRICAL CHARACTERISTICS PER LINE (@ 25℃ Unless Otherwise Specified)
DEVICE
MARKING
V
RWM
(V)
V
B
(V)
(mA)
1
1
1
1
1
1
1
I
T
V
C
@1A
(max.) (max.)
7.5
9.8
13.4
19.0
24.0
43.0
55.0
8.5
9.8
15.0
17.0
22.0
32.0
55.0
(@A)
5
5
5
5
5
3
1
V
C
I
R
(µA)
(max.)
5
5
1
1
1
1
1
C
T
(pF)
(typ.)
120
110
70
60
50
25
20
PART NUMBER
(max.) (min.)
YSOT03C
YSOT05C
YSOT08C
YSOT12C
YSOT15C
YSOT24C
YSOT36C
B03C
B05C
B08C
B12C
B15C
B24C
B36C
3.0
5.0
8.0
12.0
15.0
24.0
36.0
4.0
6.0
8.2
13.3
16.7
26.7
40.0
