5KP5.0(C)A(S) - 5KP240(C)A(S)
5000W TRANSIENT VOLTAGE SUPPRESSOR
Features
·
·
·
·
·
·
·
5000W Peak Pulse Power Dissipation
5.0V - 170V Standoff Voltages
Glass Passivated Die Construction
Uni- and Bi-directional Version Available
Excellent Clamping Capability
Fast Response Time
Plastic Case Material has UL Flammability
Classification Rating 94V-0
A
B
A
C
D
5KP
Dim
A
B
C
D
Min
25.40
¾
0.95
¾
Max
¾
8.60
1.07
9.53
5KW
Min
25.40
—
1.20
¾
Max
¾
9.00
1.30
8.00
Mechanical Data
·
·
·
·
·
Case: 5KP/5KW, Transfer Molded Epoxy
Terminals: Solderable per MIL-STD-202,
Method 208
Polarity Indicator: Cathode Band
(Note: Bi-directional devices have no polarity
indicator.)
Marking: Type Number
Weight: 2.1 grams (approx.)
All Dimensions in mm
“S” Suffix Designates 5KW Package
No “S” Designates 5KP Package
Maximum Ratings
@ T
A
= 25°C unless otherwise specified
Symbol
P
PK
Value
5000
Unit
W
Characteristic
Peak Pulse Power Dissipation
(Non repetitive current pulse derated above T
A
= 25°C)
( Note 1)
Peak Forward Surge Current, 8.3ms Single Half Sine
Wave Superimposed on Rated Load (JEDEC Method)
(Notes 1, 2, & 3)
Steady State Power Dissipation at T
L
= 75°C,
Lead Lengths @ 9.5mm(Note 1)
Instantaneous Forward Voltage @ I
PP
= 100A
(Notes 1, 2, & 3)
Operating and Storage Temperature Range
I
FSM
P
D
V
F
T
j
, T
STG
400
8.0
3.5
-55 to +150
A
W
V
°C
Notes:
1. Valid provided that the terminals are maintained at a distance of 10mm from case at 25°C.
2. Measured with 8.3ms single half sine-wave. Duty cycle = 4 pulses per minute maximum.
3. Unidirectional units only.
DS21504 Rev. H-2
1 of 3
5KP5.0(C)A(S) - 5KP240(C)A(S)
100,000
I
P
, PEAK PULSE CURRENT (%I
pp
)
C
j
, CAPACITANCE (pF)
100
t
r
= 10
m
s
Peak Value I
pp
T
j
= 25
°
C
10,000
Measured at
Stand-Off
Voltage V
R
Measured at
Zero Bias
Half Value I
pp
/2
50
1000
t
p
0
10 X 1000 Waveform
as defined by R.E.A.
0
1
2
3
100
1
10
100
200
t, TIME (ms)
Fig. 1 Pulse Waveform
V
RWM
, REVERSE STANDOFF VOLTAGE (V)
Fig. 2 Typical Junction Capacitance
1000
P
P
, PEAK PULSE POWER (kW)
100
10
1.0
0.1
1.0
10
100
1000
10,000
T
P,
PULSE WIDTH (
m
s)
Fig. 3 Pulse Derating Curve
P
D
, STEADY STATE POWER DISSIPATION (W)
100
8.0
PEAK PULSE DERATING IN % OF
PEAK POWER OR CURRENT
Single Phase
Half-Wave 60Hz
Resistive or
Inductive Load
75
6.0
50
4.0
L = 9.5 mm
25
10 X 1000 Waveform
as defind by REA
0
0
25
50
75
100
125
150
175
200
T
A
, AMBIENT TEMPERATURE (
°
C)
Fig. 4 Pulse Derating Curve
2.0
20 x 20 x 1 mm Cu
0
0
25
50
75
100
125
150
175
200
T
L
, LEAD TEMPERATURE (
°
C)
Fig. 5 Steady State Power Derating
DS21504 Rev. H-2
3 of 3
5KP5.0(C)A(S) - 5KP240(C)A(S)
