S1D2518X01 datasheet, PDF - EEWORLD Datasheet

S1D2518X01: DescriptionI2C BUS CONTROLLED R/G/B VIDEO AMPLIFIER; CategoryAnalog mixed-signal IC Consumption circuit; File Size246KB，38 Pages; ManufacturerSAMSUNG; Websitehttp://www.samsung.com/Products/Semiconductor/

Download Datasheet Parametric View All

S1D2518X01 Overview

I2C BUS CONTROLLED R/G/B VIDEO AMPLIFIER

Parameter Name	Attribute value
Maker	SAMSUNG
Parts packaging code	DIP
package instruction	SDIP, SDIP30,.4
Contacts	30
Reach Compliance Code	compli
ECCN code	EAR99
Other features	IT ALSO REQUIRES 11.4V TO 12.6V SUPPLY
Commercial integrated circuit types	VIDEO AMPLIFIER
Gain	18 dB
harmonic distortion	1%
JESD-30 code	R-PDIP-T30
length	27.48 mm
Number of channels	3
Number of functions	1
Number of terminals	30
Maximum operating temperature	75 °C
Minimum operating temperature	-25 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SDIP
Encapsulate equivalent code	SDIP30,.4
Package shape	RECTANGULAR
Package form	IN-LINE, SHRINK PITCH
power supply	5,12 V
Certification status	Not Qualified
Maximum seat height	5.21 mm
Maximum supply voltage (Vsup)	5.25 V
Minimum supply voltage (Vsup)	4.75 V
surface mount	NO
technology	BIPOLAR
Temperature level	COMMERCIAL EXTENDED
Terminal form	THROUGH-HOLE
Terminal pitch	1.778 mm
Terminal location	DUAL
width	10.16 mm

DECEMBER. 2001

Ver 2.1

DATA SHEET

S1D2518X01

Preliminary
