RMCG Series
Gold Barrier Thick Film Chip Resistors
Features:
•
•
•
Gold terminations are completely impervious to sulfur
Zero ohm available (max resistance 0.05Ω)
RoHS compliant
Stackpole Electronics, Inc.
Resistive Product Solutions
Electrical Specifications
Type / Code
Power Rating
(Watts) @ 70ºC
Maximum Working
Maximum
(1)
Overload Voltage
Voltage
Resistance
Temperature
Coefficient
-0/+600 ppm/ºC
± 350 ppm/ºC
± 200 ppm/ºC
± 350 ppm/ºC
± 350 ppm/ºC
± 200 ppm/ºC
± 100 ppm/ºC
± 350 ppm/ºC
± 350 ppm/ºC
± 250 ppm/ºC
± 200 ppm/ºC
± 100 ppm/ºC
± 250 ppm/ºC
± 350 ppm/ºC
± 350 ppm/ºC
± 250 ppm/ºC
± 200 ppm/ºC
± 100 ppm/ºC
± 250 ppm/ºC
± 350 ppm/ºC
± 350 ppm/ºC
± 250 ppm/ºC
± 200 ppm/ºC
± 100 ppm/ºC
± 250 ppm/ºC
± 350 ppm/ºC
± 350 ppm/ºC
± 250 ppm/ºC
± 200 ppm/ºC
± 100 ppm/ºC
± 250 ppm/ºC
± 350 ppm/ºC
± 350 ppm/ºC
± 250 ppm/ºC
± 200 ppm/ºC
± 100 ppm/ºC
± 250 ppm/ºC
± 350 ppm/ºC
-
10 - 1M
1.1M - 10M
1 - 3.6
3.9 - 9.1
-
10 - 1M
1.1M - 5.1M
5.6M - 10M
1 - 3.6
3.9 - 9.1
-
10 - 1M
1.1M - 5.1M
5.6M - 10M
1 - 3.6
3.9 - 9.1
-
10 - 1M
1.1M - 5.1M
5.6M - 10M
1 - 2
2.2 - 9.1
-
10 - 1M
1.1M - 5.1M
5.6M - 10M
1 - 3.6
3.9 - 9.1
-
10 - 1M
1.1M - 5.1M
5.6M - 10M
10 - 1M
-
1 - 3.6
3.9 - 9.1
10 - 1M
-
10 - 1M
-
10 - 1M
-
10 - 1M
-
Ohmic Range (Ω) and Tolerance
1%
1 - 3.6
3.9 - 9.1
10 - 1M
1.1M - 10M
1 - 9.1
10 - 1M
-
2%, 5%
RMCG0402
0.063W
50V
100V
RMCG0603
0.1W
50V
100V
RMCG0805
0.125W
150V
300V
RMCG1206
0.25W
200V
400V
RMCG1210
0.333W
200V
400V
RMCG2010
0.75W
200V
400V
RMCG2512
1W
200V
400V
(1) Lesser of √PR or maximum working voltage.
Rev Date: 05/09/2016
This specification may be changed at any time without prior notice
Please confirm technical specifications before you order and/or use.
1
www.seielect.com
marketing@seielect.com
RMCG Series
Gold Barrier Thick Film Chip Resistors
Stackpole Electronics, Inc.
Resistive Product Solutions
Mechanical Specifications
Type / Code
RMCG0402
RMCG0603
RMCG0805
RMCG1206
RMCG1210
RMCG2010
RMCG2512
L
Body Length
0.039 ± 0.002
1.00 ± 0.05
0.063 ± 0.004
1.60 ± 0.10
0.079 ± 0.008
2.00 ± 0.20
0.126 ± 0.008
3.20 ± 0.20
0.126 ± 0.008
3.20 ± 0.20
0.197 ± 0.008
5.00 ± 0.20
0.248 ± 0.008
6.30 ± 0.20
W
Body Width
0.020 ± 0.002
0.50 ± 0.05
0.031 ± 0.004
0.80 ± 0.10
0.049 ± 0.004
1.25 ± 0.10
0.063 ± 0.006
1.60 ± 0.15
0.098 ± 0.008
2.50 ± 0.20
0.098 ± 0.008
2.50 ± 0.20
0.126 ± 0.008
3.20 ± 0.20
H
Body Height
0.014 ± 0.002
0.35 ± 0.05
0.018 ± 0.004
0.45 ± 0.10
0.020 ± 0.006
0.50 ± 0.15
0.022 ± 0.006
0.55 ± 0.15
0.022 ± 0.006
0.55 ± 0.15
0.022 ± 0.006
0.55 ± 0.15
0.022 ± 0.006
0.55 ± 0.15
a
Top Termination
0.008 ± 0.004
0.20 ± 0.10
0.012 ± 0.008
0.30 ± 0.20
0.016 ± 0.008
0.40 ± 0.20
0.020 ± 0.010
0.50 ± 0.25
0.020 ± 0.010
0.50 ± 0.25
0.024 ± 0.010
0.60 ± 0.25
0.024 ± 0.010
0.60 ± 0.25
b
Bottom Termination
0.010 ± 0.004
0.25 ± 0.10
0.012 ± 0.008
0.30 ± 0.20
0.016 ± 0.008
0.40 ± 0.20
0.020 ± 0.010
0.50 ± 0.25
0.020 ± 0.010
0.50 ± 0.25
0.024 ± 0.010
0.60 ± 0.25
0.024 ± 0.010
0.60 ± 0.25
Unit
inches
mm
inches
mm
inches
mm
inches
mm
inches
mm
inches
mm
inches
mm
Performance Characteristics
Test
Short Time Overload
Dielectric Withstanding Voltage
Resistance to Soldering Heat
Solderability
Temperature Cycle (100 cycles)
Endurance (Damp load)
Endurance (Rated load)
Voltage Coefficient
Robustness of Termination
Operating Temperature Range:
Test Conditions (JIS C 5202)
2.5x rated voltage for 5 seconds
100 VAC, 1 minute
260ºC ±5ºC, for 10 sec. ±0.5 sec. (Solder Bath)
245ºC ±5ºC, for 3 sec. ±0.5 sec. (Colophonium flux)
-55ºC: 30 min. 25ºC: 2 to 3 min.
125ºC: 30 min. 25ºC: 2 to 3 min.
60ºC ± 2ºC, 90% RH, Rated Load
90 min. On, 30 min. Off (1,000 hrs. -0hrs. +48hrs.)
70ºC ± 2ºC, Rated Load
90 min. On, 30 min. Off (1,000 hrs. -0hrs. +48hrs.)
1/10 rated voltage for 3 sec. max. then rated voltage for 3 sec. max.
Bend of 3mm for 5 ± 1 sec.
-55ºC to +125ºC (0402)
-55ºC to +155ºC (0603 - 2512)
Test Results
± (2% + 0.1Ω)
± (1% + 0.05Ω)
± (1% + 0.05Ω)
95% coverage, minimum
±(1% + 0.05Ω)
Jumper (<0.05Ω)
±(3% + 0.1Ω)
Jumper (<0.05Ω)
±(3% + 0.1Ω)
Jumper (<0.05Ω)
±100 (ppm/V)
± (1% + 0.05 Ohm)
Rev Date: 05/09/2016
This specification may be changed at any time without prior notice
Please confirm technical specifications before you order and/or use.
2
www.seielect.com
marketing@seielect.com
RMCG Series
Gold Barrier Thick Film Chip Resistors
Power Derating Curve:
100
-55ºC
70ºC
Stackpole Electronics, Inc.
Resistive Product Solutions
Percent Rated Power (%)
80
60
40
20
0
-60
125ºC
155°C
0402
0603 - 2512
0
20
40
60
80
100 120
Ambient Temperature (ºC)
140
160
180
How to Order
1
2
3
4
5
6
7
8
9
10
11
12
13
14
R
M
C
G
0
4
0
2
J
T
4
K
7
0
Product Series
Gold Termination
RMCG
Size
0402
0603
0805
1206
1210
2010
2512
Power
0.063W
0.100W
0.125W
0.250W
0.333W
0.750W
1.000W
Tolerance
Tol
Code
1%
F
2%
G
5%
J
Packaging
Code
Description
7" Reel
Paper Tape
7" Reel
Plastic Tape
Size
0402
0603, 0805
1206, 1210
2010, 2512
Quantity
10,000
5,000
4,000
Resistance Value
Four characters with
the multiplier used as
the decimal holder.
3.9 ohm = 3R90
10 Kohm = 10K0
1.1 Mohm = 1M10
T
Rev Date: 05/09/2016
This specification may be changed at any time without prior notice
Please confirm technical specifications before you order and/or use.
3
www.seielect.com
marketing@seielect.com
