Data Sheet
Customer:
Product:
Size:
Issued Date:
Edition:
Metal Film Precision MELF Resistor-CSRV Series
0102/0204/0207
15-Feb-22
REV.C1
VIKING TECH CORPORATION
光頡科技股½有限公司
No.70 Guangfu N. Rd., Hukou
Township, Hsinchu County 303,
Taiwan
TEL:886-3-5972931
FAX:886-3-5972935•886-3-5973494
E-mail:sales@viking.com.tw
VIKING TECH CORPORATION KAOHSIUNG BRANCH
光頡科技股½有限公司高雄分公司
No.248-3, Sin-Sheng Rd., Cian-Jhen Dist., Kaohsiung,
806, Taiwan
VIKING ELECTRONICS (WUXI) CO., LTD.
光頡電子(無錫)有限公司
No.22 Xixia Road, Machinery & Industry Park,
National Hi-Tech Industrial Development Zone
of Wuxi, Wuxi, Jiangsu Province, China
Zip Code:214028
TEL:86-510-85203339
FAX:86-510-85203667•86-510-85203977
E-mail:china@viking.com.tw
TEL:886-7-8217999
FAX:886-7-8228229
E-mail:sales@viking.com.tw
Produced by
(QC)
15-Feb-22
Checked
(QC)
15-Feb-22
Approved by
(QC)
15-Feb-22
Prepared by
(Sales)
Accepted by
(Customer)
Susan Huang
J.C. Liu
J.C. Liu
【CSRV
Series】
Metal Film Precision MELF Resistor
■Features
－AEC-Q200
Compliance
－Thin
film technology
－Excellent
overall stability
－Sn
termination on Ni barrier layer
－Tight
tolerance down to ±0.1%
－Extremely
low TCR down to ±5 PPM/°C
－High
power rating up to 1 Watts
－SMD
enabled structure
－Lead-free
and RoHS compliant
■Applications
－Automotive(non-safety
parts)
－Industrial
－Telecommunication
－Medical
Equipment
－Measurement/Testing
Equipment
TECHNICAL SPECIFICATIONS
DESCRIPTION
Resistance range
Resistance tolerance
Temperature coefficient
Operation mode
Power rating P
70
Operating voltage U
max.
Operating temperature range
Max. resistance change at P70
for resistance range,
ΔR/R
max., after 1000 h
≦0.5%
±100ppm/℃; ±50ppm/℃;
±25ppm/℃; ±15ppm/℃
Standard
1/8W
150V
High power
1/5W
200V
0.3W
200V
Standard
1/4W
200V
CSRV0102
1Ω-1MΩ; 0Ω
CSRV0204
0.1Ω-3.4MΩ; 0Ω
±5%;±1%;±0.5%;±0.25%;±0.1%
±100ppm/℃; ±50ppm/℃; ±25ppm/℃;
±15ppm/℃; ±10ppm/℃; ±5ppm/℃
High power
2/5W
200V
Standard
1/2W
300V
High power
1W
350V
CSRV0207
0.1Ω-3.4MΩ; 0Ω
-55℃~155℃
≦0.5%
≦0.5%
■Construction
& Dimension
Insulation Coating
Trimming Line
Ceramic Rod
Electrode Cap
Resistor Layer
Marking
Type
CSRV0102
CSRV0204
CSRV0207
L
(mm)
2.20±0.10
3.50±0.2
5.90±0.2
L
1 min.
(mm)
1.1
1.7
2.9
ΦD
(mm)
1.10±0.10
1.40±0.15
2.20±0.20
ΦD
1
(mm)
D +0/-0.15
D +0/-0.2
D +0/-0.2
K
(mm)
0.45±0.05
0.8±0.1
1.3±0.1
Weight
1,000EA
(g)
7.7
18.7
80.9
www.viking.com.tw
For detail questions, contact
：
sales@viking.com.tw
1
Edition: REV.C1
Revision: 15-Feb-2022
【CSRV
Series】
Metal Film Precision MELF Resistor
■Part
Numbering
Part Number：CSRV0204DTDV1001
Part Number：CSRV0204JT-VR0R0
C
S
R
V
0
2
0
4
D
T
D
V
1
0
0
1
C
S
R
V
0
2
0
4
J
T
－
V
R
0
R
0
Product
Type
CSRV
Dimensions
(L×ΦD)
0102: 2.2x1.1
0204: 3.5x1.4
0207: 5.9x2.2
Resistance
Tolerance
B: ±0.1%
C: ±0.25%
D: ±0.5%
F: ±1%
J
: ±5% or Jumper
Packaging
Code
T: 7” Taping Reel
S:7” Taping Reel,
Antistatic Tape
※
W:13” Taping Reel
M:13” Taping Reel,
Antistatic Tape
※
TCR
(PPM/°C)
S: ±5
B: ±10
N: ±15
C: ±25
D: ±50
E: ±100
-: Jumper
Power
Rating
T: 1W
U: 1/2W
V: 1/4W
G: 2/5W
P: 1/5W
W: 1/8W
L: 0.3W
Resistance
0010: 1Ω
0100: 10Ω
2201: 2200Ω
1001: 1KΩ
1004: 1MΩ
R050: 0.05Ω
22R1: 22.1Ω
R0R0: 0Ω
※Packaging
Code “S” & “M” only for 0102 & 0204 size products, not include 0207 size product.
■Recommend
Land Pattern
■Derating
Curve
100
90
80
Power ratio(%)
70
60
50
40
30
20
10
5ppm
Except
for 5ppm
Type
CSRV0102
CSRV0204
CSRV0207
A
(mm)
1.0
1.6
3.0
B
(mm)
0.8
1.2
1.7
C
(mm)
1.5
1.6
2.4
0
-60 -50 -40 -30 -20 -10
0
10
20
30
40
50
60
70
80
90 100 110 120 130 140 150 160
Ambient Temperature(℃)
■Soldering
Condition (IPC/JEDEC J-STD-020)
www.viking.com.tw
For detail questions, contact
：
sales@viking.com.tw
2
Edition: REV.C1
Revision: 15-Feb-2022
【CSRV
Series】
Metal Film Precision MELF Resistor
■Standard
Electrical Specifications
Item
Type
Power
Rating
at 70°C
Operating
Max.
Max.
Temp.
Operating Overload
Range
Voltage
Voltage
Resistance Range
±0.1%
±0.25%
±0.5%
±1%
49.9Ω-
390KΩ
1Ω-1MΩ
1Ω-1MΩ
-
49.9Ω-20KΩ
0204
1/4W
10Ω-300KΩ
-55 ~
+155C
200V
400V
10Ω-1MΩ
10Ω-1MΩ
-
-55 ~
+125C
0207
1/2W
300V
600V
10Ω-332KΩ
49.9Ω-20KΩ
10Ω-300KΩ
300V
600V
10Ω-1MΩ
10Ω-1MΩ
-
10Ω-3.4MΩ
1Ω-3.4MΩ
1Ω-3.4MΩ
0.2Ω-3.4MΩ
0.1Ω-3.4MΩ
-
-
-
10Ω-3.4MΩ
1Ω-3.4MΩ
1Ω-3.4MΩ
0.2Ω-3.4MΩ
0.1Ω-3.4MΩ
-
-
±5%
-
-
±15
±25
±50
±100
±5
±10
±15
±25
±50
±100
±5
±10
±15
±25
±50
±100
TCR
(PPM/°C)
0102
1/8W
-55 ~
+155C
-55 ~
+125C
150V
300V
100Ω-56KΩ
49.9Ω-
100Ω-82KΩ
200KΩ
-
-
200V
400V
10Ω-332KΩ
-55 ~
+155C
■High
Power Rating Electrical Specifications
Item
Type
Power
Rating
at 70°C
Operating
Max.
Max.
Temp.
Operating Overload
Range
Voltage
Voltage
Resistance Range
±0.1%
±0.25%
±0.5%
±1%
±5%
-
49.9Ω-
390KΩ
1Ω-1MΩ
-
-55 ~
+125C
200V
400V
10Ω-332KΩ
49.9Ω-20KΩ
10Ω-300KΩ
0204
2/5W
-55 ~
+155C
200V
400V
10Ω-1MΩ
10Ω-1MΩ
-
-55 ~
+125C
350V
700V
10Ω-332KΩ
49.9Ω-20KΩ
10Ω-300KΩ
0207
1W
-55 ~
+155C
350V
700V
10Ω-1MΩ
10Ω-1MΩ
-
Operating Voltage=√(P*R) or Max. Operating Voltage listed above, whichever is lower.
Overload Voltage=2.5*√(P*R) or Max. Overload Voltage listed above, whichever is lower.
RCWV(Rated Continuous Working Voltage)=√(P*R) or Max. Operating Voltage whichever is lower.
■
Viking is capable of manufacturing the optional spec based on customer’s requirement.
10Ω-3.4MΩ
1Ω-3.4MΩ
1Ω-3.4MΩ
0.2Ω-3.4MΩ
0.1Ω-3.4MΩ
-
-
-
10Ω-3.4MΩ
1Ω–3.4MΩ
1Ω-3.4MΩ
0.2Ω-3.4MΩ
0.1Ω-3.4MΩ
-
-
-
1Ω-1MΩ
-
TCR
(PPM/°C)
±15
±25
±50
±100
±5
±10
±15
±25
±50
±100
±5
±10
±15
±25
±50
±100
100Ω-56KΩ
1/5W
0102
0.3W
-55 ~
+155C
100Ω-82KΩ
200V
400V
-
49.9Ω-
200KΩ
www.viking.com.tw
For detail questions, contact
：
sales@viking.com.tw
3
Edition: REV.C1
Revision: 15-Feb-2022
【CSRV
Series】
Metal Film Precision MELF Resistor
■Jumper
Specifications
Item
Power Rating
Type
1/8W
CSRV0102
1/5W
0.3W
1/4W
CSRV0204
2/5W
1/2W
CSRV0207
1W
-55 ~ +155C
5A
-55 ~ +155C
0
Ω
(<15mΩ)
3A
-55 ~ +155C
2A
Operating Temp.Range
Resistance
Rated Current
■Environmental
Characteristics
Requirement
Item
5% and Below
Jumper
JIS-C-5201-1 4.8
IEC-60115-1 4.8
At 25C/-55C and 25C/+125C, 25C is the
reference temperature
5ppm: At 25C/-10C and 25C/+85C, 25C is the
reference temperature
JIS-C-5201-1 4.13
IEC-60115-1 4.13
RCWV*2.5 or Max. Overload Voltage whichever is
lower for 5 seconds
JIS-C-5201-1 4.6
IEC-60115-1 4.6
Max. Overload Voltage for 1 minute
MIL-STD-202 Method 108
Condition D Steady State TA=125°C at derated
power.
Measurement at 24±4 hours after test conclusion.
5ppm: 702C, RCWV for 1000 hrs with 1.5 hrs “ON”
and 0.5 hr “OFF”
MIL-STD-202 Method 103
1000 hrs 85C/85%RH 10% of operating power.
(≦100 V)
MIL-STD-202 Method 108
at +125C/+155C for 1000 hrs
Test Method
Temperature Coefficient of
Resistance (T.C.R.)
As Spec
Short Time Overload
10Ω-270KΩ:
(0.1%+0.01Ω)
<10Ω & >270KΩ:
(0.15%+0.01Ω)
0102:
(0.15%+0.01Ω)
5ppm:
(0.05%+0.01Ω)
<15mΩ
Insulation Resistance
10G
Operational Life
10Ω-270KΩ:
(0.25%+0.01Ω)
<10Ω & >270KΩ:
(0.5%+0.01Ω)
0102:
(0.5%+0.01Ω)
<15mΩ
Biased Humidity
10Ω-270KΩ:
(0.5%+0.01Ω)
<10Ω & >270KΩ:
(1%+0.01Ω)
0102:
(2%+0.01Ω)
10Ω-270KΩ:
(0.25%+0.01Ω)
<10Ω & >270KΩ:
(1%+0.01Ω)
0102:
(1%+0.01Ω)
10Ω-270KΩ:
(0.1%+0.01Ω)
<10Ω & >270KΩ:
(0.5%+0.01Ω)
0102:
(0.5%+0.01Ω)
<15mΩ
High Temperature Exposure
<15mΩ
Board Flex
<15mΩ
AEC-Q200-005
Bending once for 60 seconds with 2mm
JIS-C-5201-1 4.17
IEC-60115-1 4.17
J-STD-002
2455C for 3 seconds
MIL-STD-202 Method 210
2605C for 10 seconds
Solderability
95% min. coverage
10Ω-270KΩ:
(0.1%+0.01Ω)
<10Ω & >270KΩ:
(0.25%+0.01Ω)
0102:
(0.25%+0.01Ω)
5ppm:
(0.05%+0.01Ω)
Resistance to Soldering Heat
<15mΩ
www.viking.com.tw
For detail questions, contact
：
sales@viking.com.tw
4
Edition: REV.C1
Revision: 15-Feb-2022
