17,76
Ansaughaube
4,2
hood
Verpackt im Gurt nach DIN IEC 60286-3
5,2
Tape on Reel Packaging according to DIN IEC 60286-3
9,05
9,35
Verpackungseinheit: 280 Stück
Packaging unit: 280 pcs
1,5
-0,03
46,33
±0,03
1
48,26
a25
43,93
a1
1,27
0,75
-0,05
330
Abspulrichtung -
Reel off Direction
3,05
7,2
1,55
1,27
33 x 1,27 = 41,91
44,93
Anforderungsstufe 1
Performance Level 1
Kontaktbereich vergoldet
Mating Area gold plating
Anschlussbereich verzinnt 4-6 µm
Terminal Area 4-6 µm tin plating
Leiterplatten-Layout Vorschlag für SMT
Koplanarität der Anschlüsse
PCB-Layout Proposal for SMT
46,33
±0,03
33 x 1,27 = 41,91
2,21
±0,03
1,27
a1
Coplanarity Area of Termination
≤
0,1 mm
a1
≤
0,1 mm
72
16
BA 7-03 - Standard Bauhöhe
type 7-03 - Standard Assembly Height
Copyright by ERNI GmbH
Proprietary notice pursuant to ISO 16016 to be observed.
Information:
Tolerances
All Dimensions
in mm
Scale
3:1
7,6
2,2
5,5
1,1
0,3
1,2
0,8
1,6
-0,03
All rights reserved.
Only for Information.
To ensure that this is the latest
version of this drawing, please
contact one of the ERNI companies
before using.
e
Index
10.12.2013
Date
Designation
Subject to modification without
prior notice.
Drawing will not be updated.
Federl. SMC-B 68-SMD-BA7-03
Female SMC-B 68-SMD-type7-03
www.ERNI.com
Class
100400760007
SMCB
K
A3
