ALUMINUM ELECTROLYTIC CAPACITORS
LHA
■FEATURES
Goback
series
SUPER LONG LIFE 9000HRS
l
Load Life:105℃ 9000 hours
l
High Ripple Current
l
For Electronic Ballast, Power Supply
■SPECIFICATIONS
Item
Operating Temperature
Range
Rated Voltage Range
Capacitance Tolerance
Performance Characteristics
-25℃~ +105℃
160V~450W.V.
±20%
(20℃,120Hz)
I=0.04CV +100μA(After 1minutes application of rated voltage)
Leakage Current(MAX) I=0.02CV +25μA(After 5minutes application of rated voltage)
I=Leakage Current(μA) , C=Nominal Capacitance(μF) , V=Rated Voltage(V)
(tanδ)
Rated voltage (V)
Tan
δ
0.15
160
0.15
200
0.15
250
0.20
350
400
0.20
0.20
450
(20
℃,120Hz)
Stability at Low
Temperature
Rated voltage (V)
Z(-25℃)/Z(+20℃)
160
3
200
3
250
3
350
6
400
6
450
6
(
120Hz)
Load Life
After life test at conditions stated in the table below, the capacitors shall meet the following
requirement
Leakage Current
Not more than the specified value.
Case Dia
Life Time(hrs)
Capacitance Change Within ±25% of initial value.
φD=10
9000
Dissipation Factor
Not more than 200% of the specified value.
φD≧12.5
9000
After leaving capacitors under no load at 105℃ for 1000 hours and applying voltage according to JIS
C-5102 4-3, they meet the specified value for load life characteristics listed above.
Shelf Life
Standard
According to JIS C-5141
■MULTIPLIER
FOR RIPPLE CURRENT
Frequency coefficient
Frequency(Hz)
120
0.5
1k
0.80
10k
0.90
100k≦
1.00
Temperature coefficient
Temperature ~55℃
Coefficient
1.78
75℃
1.70
85℃
1.40
105℃
1.00
Coefficient
LHA-0401
ALUMINUM ELECTROLYTIC CAPACITORS
LHA
series
SUPER LONG LIFE 9000HRS
φD
φd
F
α
10
0.6
5.0
12.5
16
0.8
7.5
18
■DIMENSIONS
(mm)
L≦16:α=1.5, L≧20:α=2.0
■STANDARD
SIZES AND PERMISSIBLE RIPPLE CURRENT
SIZEφDxL(mm)Ripple Current(mA r.m.s/105℃,100kHz)
W.V
Cap(μF)
6.8
10
22
6R8
100
220
160V
(2C)
Size Ripple
200V
(2D)
Size Ripple
250V
350V
400V
(2E)
(2V)
(2G)
Size Ripple Size Ripple Size Ripple
10x16
220
280
350
10x20
12.5x20
16x25
220
280
430
450V
(2W)
Size Ripple
12.5x20
16x25
16x35.5
150
320
560
10x16
10x20
240
500
10x16
10x20
250
530
10x20
12.5x20
280
600
10x20
12.5x20
33
330 12.5x20
550
12.5x20
600
12.5x20
650
16x25
500
16x31.5
640
18x31.5
700
47
68
100
150
220
470 12.5x20
680
16x25
630
760
1120
1360
1400
12.5x25
16x25
16x31.5
18x31.5
18x35.5
660
760
1120
1360
1650
16x25
16x31.5
18x31.5
18x35.5
720
920
1200
1500
16x31.5
18x31.5
660
850
16x35.5
18x35.5
840
1000
18x35.5
880
101 16x31.5
151 16x35.5
221 18x31.5
LHA-0401
