BG026-42-I-0750-0300-L-G: DescriptionBoard Stacking Connector, 42 Contact(s), 2 Row(s), Male, Straight, 0.1 inch Pitch, Solder Terminal, Guide Slot,; CategoryThe connector The connector; File Size169KB，1 Pages; ManufacturerGlobal Connector Technology; Environmental Compliance

Download Datasheet Parametric View All

BG026-42-I-0750-0300-L-G Overview

Board Stacking Connector, 42 Contact(s), 2 Row(s), Male, Straight, 0.1 inch Pitch, Solder Terminal, Guide Slot,

BG026-42-I-0750-0300-L-G Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	1343031685
Reach Compliance Code	compliant
ECCN code	EAR99
body width	0.35 inch
subject depth	0.642 inch
body length	2.401 inch
Connector type	BOARD STACKING CONNECTOR
Contact to complete cooperation	GOLD (30)
Contact completed and terminated	Tin (Sn) - with Nickel (Ni) barrier
Contact point gender	MALE
Contact material	COPPER ALLOY
contact mode	RECTANGULAR
Contact resistance	20 mΩ
Contact style	SQ PIN-SKT
DIN compliance	NO
Dielectric withstand voltage	600VAC V
Durability	100 Cycles
Filter function	NO
IEC compliance	NO
Insulation resistance	1000000000 Ω
insulator material	LIQUID CRYSTAL POLYMER (LCP)
JESD-609 code	e3
MIL compliance	NO
Plug contact pitch	0.1 inch
Match contact row spacing	0.1 inch
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation option 1	GUIDE SLOT
Installation option 2	LOCKING
Installation method	STRAIGHT
Installation type	BOARD
Number of connectors	ONE
PCB row number	2
Number of rows loaded	2
Maximum operating temperature	105 °C
Minimum operating temperature	-40 °C
Options	GENERAL PURPOSE
PCB contact pattern	RECTANGULAR
PCB contact row spacing	2.54 mm
Plating thickness	30u inch
polarization key	POLARIZED HOUSING
Rated current (signal)	3 A
Guideline	UL
reliability	COMMERCIAL
Terminal length	0.098 inch
Terminal pitch	2.54 mm
Termination type	SOLDER
Total number of contacts	42
UL Flammability Code	94V-0

Preview

Download Datasheet

View All

H

Ø1

.0 2

2.54

1.2

6.5

8.9

Number of

Contacts

6

Dimensions

A

5.08

7.62

10.16

12.70

15.24

17.78

20.32

22.86

25.40

27.94

30.48

33.02

35.56

38.10

40.64

B

15.27

17.81

20.35

22.89

25.43

27.97

30.51

33.05

35.59

38.13

40.67

43.21

45.75

48.29

50.83

Number of

Contacts

36

38

40

42

44

46

48

50

52

54

56

58

60

62

64

Dimensions

A

43.18

45.72

48.26

50.80

53.34

55.88

58.42

60.96

63.50

66.04

68.58

71.12

73.66

76.20

78.74

B

53.37

55.91

58.45

60.99

63.53

66.07

68.61

71.15

73.69

76.23

78.77

81.31

83.85

86.39

88.93

2.54

4.50

2° Max. Sway & Toe

(Either Direction At The top)

8

10

12

14

16

18

G

Recommended PCB Layout

General Tolerance: ±0.05

F

B±0.38

20

22

5.8

24

8.8

0.3

26

28

C±0.2

E

2.54

30

32

34

2.5

D

2.54

A±0.25

Specifications

规格

D±0.2

0.64 sq. pin

5.00

2.54

Ordering Grid

BG026

No. of Contacts

06 to 64

XX

X

XXXX

X

Request Samples

and Quotation

C

Material

物料

Insulator

绝缘½

:

Standard

标准

: Polyamide, Nylon 6T, UL94V-0

Options

可选

: Polyester, LCP, UL94V-0

Polyester, PBT, UL94V-0

Contact

接触

: Copper Alloy

Plating

电镀

Contact

接触

: See Ordering Grid

Electrical

电气

Current Rating

电流额定值

: 3 Amp

Contact Resistance

接触电阻值

: 20 mΩ max.

Insulation Resistance

绝缘电阻值

: 1000 MΩ min.

Dielectric Withstand Voltage

寒耐电压

: 600 V AC

B

Mechanical & Environmental

机械

&

环境

Operating Temperature

工½温度

: -40°C to +105°C

Soldering Process

可焊性

Nylon 6T (Standard

标准物料

)

IR Reflow

回流焊

: 260°C for 10 sec.

Wave

波峰焊

: 230°C for 5-10 sec.

Manual Solder

人工焊接

: 350°C for 3-5sec

LCP (Option

可选物料

)

IR Reflow

回流焊

: 260°C for 10 sec.

Wave

波峰焊

: 250°C for 5-10 sec

Manual Solder

人工焊接

: 350°C for 3-5 sec

PBT (Option

可选物料

)

Manual Solder

人工焊接

: 330°C for 3-5sec

(Not suitable for hi-temp process

不适合高温处理

)

Mates with

配套之母座

(Subject to Pin Length

在端子长度适合的条件下

)

Allowing perfect polarisation: BG215 BG216

Non-Polarised mating connections available - contact GCT for details

Contact Plating

A = Gold Flash All Over

(Standard)

B = Selective Gold Flash Contact Area/

Tin On Tail

C = Tin All Over

G = 10µ" Gold Contact Area/Tin On Tail

I = 30µ" Gold Contact Area/Tin On Tail

Dimension C

(1/100mm) (Elevation Height)

0750 = 7.50mm

(Standard)

Or specify Custom Post Height

eg. 0250 = 2.50mm

Packing Options

G = Plastic Box

(Standard)

D = Tube

Insulator Material

N = Nylon 6T

(Standard)

P = PBT

L = LCP

Dimension D

(1/100mm) (Tail Length)

0300 = 3.00mm

(Standard)

Or specify Custom Footprint Width

eg. 0250 = 2.50mm

Part Number

Product Description

BG026

Drawing Date

A

30th March 2007

By

Detail

Revision

Date

AJO

Additional

Dimensions

C1

04/02/15

Length

Pitch Elevated Shrouded Pin Header,

Dual Row, Through Hole, Vertical

Tolerances

(Except as Noted)

Angle

1

2

3

4

5

X.° ± 5°

X. ± 0.30

X.X° ± 2°

X.X ± 0.20

X.XX° ± 1°

X.XX ± 0.15

X.XXX ± 0.10 X.XXX° ± 0.5°

Units:

Metric (mm)

C

7

3rd Angle Projection

This drawing is confidential and

copyright of Global Connector

Technology, Ltd (GCT).

This drawing must not be copied

or disclosed without written

consent. E & OE

Global Connector Technology

GC

Drawn By

AJO

www.gct.co

Not to

Scale

Sheet No.

1/1
