PolySwitch®
PTC Devices
Overcurrent Protection Device
PRODUCT: BD540-30
DOCUMENT: SCD28232
REV LETTER: B
REV DATE: APRIL 9, 2013
PAGE: 1 OF 1
Specification Status: Released
Electrical Rating
Voltage: 16Vdc MAX
Current: 100A MAX
Terminal Material:
Brass H65
Thickness: 0.8mm
Tin plating thickness: 5 μm
Insulating Material:
Green color PBT
Marking:
- Manufacturer’s Mark
BD540-30 - Part ID
- Lot Number
TABLE I. DIMENSIONS:
A
MIN
mm
in*
21.65
0.852
H
MIN
6.05
0.238
MAX
6.65
0.262
MAX
22.36
0.880
MIN
7.06
0.278
I(Ref.)
MIN
3.4
0.134
MAX
3.6
0.142
B
MAX
7.74
0.305
MIN
9.35
0.368
J(Ref.)
MIN
3.4
0.134
MAX
3.6
0.142
C
MAX
10.55
0.415
MIN
5.28
0.208
K(Ref.)
MIN
18
0.709
MAX
18.2
0.717
D
MAX
5.72
0.225
MIN
0.7
0.028
L(Ref.)
MIN
18.4
0.724
MAX
18.6
0.732
E
MAX
0.83
0.033
MIN
9.5
0.374
F
MAX
10
0.394
MIN
24.75
0.974
G
MAX
25.4
1.000
*Rounded off approximation
TABLE II: PERFORMANCE RATINGS:
TRIP
HOLD
TRIPPED-
CURRENT AT CURRENT AT
STATE
Rmin
Rmax
POWER
DISSIPATION
OHMS
SECONDS
AMPS
AMPS
WATTS AT
AT 25°C
AT 25°C
AT 25°C
AT 25°C
20°C, 14V
MIN │MAX
MAX
MAX
MIN
TYP
0.0016│0.0044
13
40
21
6.2
Reference Documents:
PS300, PS400
Precedence:
This specification takes precedence over documents referenced herein.
Effectivity:
Reference documents shall be the issue in effect on the date of invitation or bid.
CAUTION:
Operation beyond the rated voltage or current may result in rupture, electrical arcing or flame.
When using a test probe to probe either of the two test points on the top of the device, care should
be taken to avoid puncturing through the insulating material of the device, as this can result in
shorting out the terminals which can cause electrical arcing or flame.
RESISTANCE
VALUES
TIME TO
TRIP AT
120AMPS
Materials Information
ROHS Compliant
ELV Compliant
Pb-Free
© 2011, 2013 Tyco Electronics Corporation, a TE Connectivity Ltd. company. All rights reserved.
