STANDARD POWER INDUCTORS - THRU HOLE
24FP
TRADITIONAL
Pb
24FPLF
*
PART
NUMBER
COMPLIANT
RoHS
Wirewound, High Current, Molded
L
µH
DCR
OHMS
MAX
FERRITE CORE
24FP-101K
1.0
0.009
24FP-121K
1.2
0.010
24FP-151K
1.5
0.011
24FP-181K
1.8
0.012
24FP-221K
2.2
0.013
24FP-271K
2.7
0.014
24FP-331K
3.3
0.016
24FP-391K
3.9
0.017
24FP-471K
4.7
0.022
24FP-561K
5.6
0.024
24FP-681K
6.8
0.026
24FP-821K
8.2
0.028
24FP-102K
10
0.033
24FP-122K
12
0.037
24FP-152K
15
0.040
24FP-182K
18
0.044
24FP-222K
22
0.050
24FP-272K
27
0.070
24FP-332K
33
0.075
24FP-392K
39
0.084
24FP-472K
47
0.104
24FP-562K
56
0.130
24FP-682K
68
0.145
24FP-822K
82
0.152
24FP-103K
100
0.208
24FP-123K
120
0.283
24FP-153K
150
0.330
24FP-183K
180
0.362
All part numbers provide 10% tolerance on inductance
Optional tolerances are available; please contact factory
Custom designs are available to meet your specific requirements; please contact factory
6.27
5.95
5.67
5.43
5.22
5.03
4.70
4.56
4.01
3.84
3.69
3.55
3.27
3.09
2.97
2.84
2.66
2.25
2.17
2.05
1.84
1.65
1.56
1.53
1.30
1.12
1.04
0.99
13.8
12.8
11.2
10.0
9.0
8.2
6.9
6.2
5.5
5.0
4.5
4.1
3.6
3.2
2.9
2.7
2.5
2.3
2.0
1.9
1.7
1.5
1.4
1.2
1.1
1.0
0.95
0.86
continued next page
CURRENT
RATING
A DC MAX
INC 1
A DC
*Add “LF” suffix for RoHS requirement. Example: 24FP-101KLF
Gowanda designates a component RoHS-compliant by adding “LF” (lead free) to the part number.
These LF components meet the ≤ .1% lead requirement and they are compatible with 260°C soldering processes.
NOTES:
• Operating Temperature Range:
-55°C to +125°C
• Current Rating is based on a 40°C temperature rise
at an ambient temperature of 85°C
• Incremental Current is the approximate value
that will cause a percentage drop in inductance as
indicated in the table
1.438
±
0.188
(36.525
±
4.77)
4.7mH
0.740
±
0.010
(18.796
±
0.25)
0.240
±
0.010
(6.10
±
0.25)
• Epoxy Encapsulated for environmental protection
and superior strength to withstand all types of reflow
soldering
TAPE AND REEL SPECS:
Pcs./Reel maximum:
Pitch between parts:
Tape width:
Reel diameter:
Class
1000
0.400 in.
2.500 in.
12 in.
2
20 AWG
in. (mm)
One Magnetics Pkwy, Gowanda, NY 14070 • (t) 716-532-2234 • (f) 716-532-2702 • sales@gowanda.com
www.gowanda.com
030614
STANDARD POWER INDUCTORS - THRU HOLE
continued from previous page
24FP
24FPLF
*
PART
NUMBER
24FP-223KLF
24FP-273KLF
24FP-333KLF
24FP-393KLF
24FP-473KLF
24FP-563KLF
24FP-683KLF
24FP-823KLF
24FP-104KLF
24FP-124KLF
24FP-154KLF
24FP-184KLF
24FP-224KLF
24FP-274KLF
24FP-334KLF
24FP-394KLF
24FP-474KLF
24FP-564KLF
24FP-684KLF
24FP-824KLF
24FP-105KLF
24FP-125KLF
24FP-155KLF
24FP-185KLF
TRADITIONAL
Pb
COMPLIANT
RoHS
Wirewound, High Current, Molded
L
µH
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
12000
15000
18000
DCR
OHMS
MAX
FERRITE CORE
0.505
0.557
0.650
0.770
1.03
1.14
1.50
1.98
2.30
2.55
3.00
4.00
4.40
5.80
6.56
8.63
10.1
11.2
15.0
20.8
23.4
26.0
36.0
40.0
0.84
0.80
0.74
0.68
0.59
0.56
0.49
0.42
0.39
0.37
0.34
0.30
0.28
0.25
0.23
0.20
0.19
0.18
0.15
0.13
0.12
0.12
0.10
0.09
0.79
0.71
0.63
0.58
0.53
0.49
0.45
0.41
0.37
0.33
0.30
0.27
0.25
0.22
0.20
0.18
0.17
0.15
0.14
0.13
0.11
0.10
0.09
0.08
CURRENT
RATING
A DC MAX
INC 1
A DC
All part numbers provide 10% tolerance on inductance
Optional tolerances are available; please contact factory
Custom designs are available to meet your specific requirements; please contact factory
*Add “LF” suffix for RoHS requirement. Example: 24FP-101KLF
Gowanda designates a component RoHS-compliant by adding “LF” (lead free) to the part number.
These LF components meet the ≤ .1% lead requirement and they are compatible with 260°C soldering processes.
NOTES:
• Operating Temperature Range:
-55°C to +125°C
• Current Rating is based on a 40°C temperature rise
at an ambient temperature of 85°C
• Incremental Current is the approximate value
that will cause a percentage drop in inductance as
indicated in the table
1.438
±
0.188
(36.525
±
4.77)
4.7mH
0.740
±
0.010
(18.796
±
0.25)
0.240
±
0.010
(6.10
±
0.25)
• Epoxy Encapsulated for environmental protection
and superior strength to withstand all types of reflow
soldering
TAPE AND REEL SPECS:
Pcs./Reel maximum:
Pitch between parts:
Tape width:
Reel diameter:
Class
1000
0.400 in.
2.500 in.
12 in.
2
20 AWG
in. (mm)
One Magnetics Pkwy, Gowanda, NY 14070 • (t) 716-532-2234 • (f) 716-532-2702 • sales@gowanda.com
www.gowanda.com
030614
