BY9400 series
Fast high-voltage soft-recovery
controlled avalanche rectifiers
Product specification
Supersedes data of 1998 Aug 05
2000 Jan 10
Philips Semiconductors
Product specification
Fast high-voltage soft-recovery
controlled avalanche rectifiers
FEATURES
•
Plastic package
•
Glass passivated
•
High maximum operating temperature
•
Low leakage current
•
Excellent stability
•
40% overvoltage allowed during 5 seconds
•
Guaranteed avalanche energy absorption capability
•
Very low reverse recovery time
•
Soft-recovery switching characteristics
•
Compact construction.
APPLICATIONS
•
For colour television and monitors up to 32 kHz
(indication)
•
High-voltage applications for:
– Multipliers
– Diode-split-transformers (FBTs).
MARKING
Cathode band colour codes.
TYPE NUMBER
BY9410
BY9412
BY9414
BY9416
PACKAGE CODE
SOD107B
SOD107B
SOD107B
SOD107B
OUTER BAND
orange
orange
orange
orange
DESCRIPTION
BY9400 series
Plastic package, using glass passivation and a high
temperature alloyed construction.
This package is hermetically sealed and fatigue free as
coefficients of expansion of all used parts are matched.
The package should be used in an insulating medium such
as resin, oil or SF6 gas.
k
handbook, halfpage
CONDITIONS
a
MAM402
Fig.1 Simplified outline (SOD107B) and symbol.
INNER BAND
violet
orange
lilac
grey
LIMITING VALUES
In accordance with the Absolute Maximum Rating System (IEC 134).
SYMBOL
V
RRM1
BY9410
BY9412
BY9414
BY9416
V
RRM2
repetitive peak reverse voltage
BY9410
BY9412
BY9414
BY9416
max. 5 seconds
−
−
−
−
14.0
16.8
19.6
22.4
kV
kV
kV
kV
PARAMETER
repetitive peak reverse voltage
−
−
−
−
10
12
14
16
kV
kV
kV
kV
MIN.
MAX.
UNIT
2000 Jan 10
2
Philips Semiconductors
Product specification
Fast high-voltage soft-recovery
controlled avalanche rectifiers
SYMBOL
I
F(AV)
BY9410
BY9412
BY9414
BY9416
I
FRM
T
stg
T
j
repetitive peak forward current
storage temperature
junction temperature
BY9410
BY9412
BY9414
BY9416
Note
1. Withstands peak currents during flash-over in a picture tube.
ELECTRICAL CHARACTERISTICS
T
j
= 25
°C;
unless otherwise specified.
SYMBOL
V
F
PARAMETER
forward voltage
BY9410
BY9412
BY9414
BY9416
I
R
Q
r
t
rr
C
d
reverse current
recovery charge
reverse recovery time
diode capacitance
BY9410
BY9412
BY9414
BY9416
V
R
= V
RRM1
; T
j
= 120
°C
when switched from I
F
= 100 mA to V
R
≥
100 V
and dI
F
/dt =
−200
mA/µs
when switched from I
F
= 2 mA to I
R
= 4 mA;
measured at I
R
= 1 mA
V
R
= 0 V; f = 1 MHz
0.50
0.40
0.35
0.30
I
F
= 10 mA
−
−
−
−
−
0.7
−
CONDITIONS
−65
−65
−65
−65
note 1
PARAMETER
average forward current
CONDITIONS
averaged over any 20 ms period
−
−
−
−
−
−65
BY9400 series
MIN.
5
5
5
5
MAX.
UNIT
mA
mA
mA
mA
mA
°C
°C
°C
°C
°C
500
+175
+150
+145
+140
+140
TYP.
MAX.
24
30
34
40
3
−
100
V
V
V
V
UNIT
µA
nC
ns
−
−
−
−
pF
pF
pF
pF
2000 Jan 10
3
Philips Semiconductors
Product specification
Fast high-voltage soft-recovery
controlled avalanche rectifiers
GRAPHICAL DATA
MDA859
BY9400 series
handbook, halfpage
5
IF(AV)
(mA)
4
handbook, halfpage
5
MDA860
IF(AV)
(mA)
4
a = 6.32
1.57
a = 6.32
1.57
3
3
2
2
1
1
0
0
40
80
120
160
200
Tamb (°C)
0
0
40
80
120
160
200
Tamb (°C)
BY9410.
a = I
F(RMS)
/I
F(AV)
; V
R
= V
RWmax
; R
th j-a
≤
120 K/W.
a = 1.57: half sinewave.
a = 6.32: line output transformer application.
BY9412.
a = I
F(RMS)
/I
F(AV)
; V
R
= V
RWmax
; R
th j-a
≤
120 K/W.
a = 1.57: half sinewave.
a = 6.32: line output transformer application.
Fig.2
Maximum permissible average forward
current as a function of ambient temperature.
Fig.3
Maximum permissible average forward
current as a function of ambient temperature.
handbook, halfpage
5
MBL114
IF(AV)
(mA)
handbook, halfpage
handbook, halfpage
5
MBL115
IF(AV)
(mA)
4
4
3
a = 1.57
2
a = 6.32
1
3
a = 1.57
2
a = 6.32
1
0
0
40
80
120
160
200
Tamb (°C)
0
0
40
80
120
160
200
Tamb (°C)
BY9414.
a = I
F(RMS)
/I
F(AV)
; V
R
= V
RWmax
; R
th j-a
≤
120 K/W.
a = 1.57: half sinewave.
a = 6.32: line output transformer application.
BY9416.
a = I
F(RMS)
/I
F(AV)
; V
R
= V
RWmax
; R
th j-a
≤
120 K/W.
a = 1.57: half sinewave.
a = 6.32: line output transformer application.
Fig.4
Maximum permissible average forward
current as a function of ambient temperature.
Fig.5
Maximum permissible average forward
current as a function of ambient temperature.
2000 Jan 10
4
Philips Semiconductors
Product specification
Fast high-voltage soft-recovery
controlled avalanche rectifiers
BY9400 series
handbook, halfpage
200
MBD320
IF
handbook, halfpage
200
MBD322
IF
(mA)
160
(mA)
160
120
120
80
80
40
40
0
0
20
40
60
80
100
120
V F (V)
0
0
40
80
120
160
200
V F (V)
BY9410.
Dotted line: T
j
= 120
°C.
Solid line: T
j
= 25
°C.
BY9412.
Dotted line: T
j
= 120
°C.
Solid line: T
j
= 25
°C.
Fig.6
Forward current as a function of maximum
forward voltage.
Fig.7
Forward current as a function of maximum
forward voltage.
handbook, halfpage
200
MBD324
IF
handbook, halfpage
200
MBD326
IF
(mA)
160
(mA)
160
120
120
80
80
40
40
0
0
40
80
120
160
200
V F (V)
0
0
40
80
120
160
200
V F (V)
BY9414.
Dotted line: T
j
= 120
°C.
Solid line: T
j
= 25
°C.
BY9416.
Dotted line: T
j
= 120
°C.
Solid line: T
j
= 25
°C.
Fig.8
Forward current as a function of maximum
forward voltage.
Fig.9
Forward current as a function of maximum
forward voltage.
2000 Jan 10
5
