Ceramic SMD Crystal Oscillator
SMD 7.0 x 5.0mm PECL
F
EATURE
Output Logic: PECL
Small SMD Ceramic Package
Low Jitter Performance
MO7P series
Applications: 10G-BIT, Ethernet, Fiber Channel, Storage Area Network,
SONET, Enterprise Servers, Reference Clocks for ADC and DAC Telecom
P
ART
N
UMBERING
S
YSTEM
MO7
(1)
No
(1)
(2)
(3)
(4)
(5)
(6)
(7)
P
(2)
33
(3)
J
(4)
C
(5)
24M0
(6)
Code
MO7
P
33
J
C
24M0
Blank
Description
Oscillator Unit
P: PECL
33: 3.3V
J: ±50ppm
C: -20~+70ºC
24M0: 24.000MHz
Blank: Tri-State on Pin 1,
No connection on Pin 2
Series Reference (options)
Ceramic SMD Crystal Oscillator 7.0x5.0mm 6 Pads
P: PECL
25: 2.5V
F: ±20ppm, G: ±25ppm, H: ±30ppm (see avail options)
A: -10~+60ºC, B: 0~+70ºC, I: -40~+85ºC (see options)
19M44 ~ 320M0 (M denotes decimal point)
N: No connection on Pin 1, Tri-State on Pin 2
Item
Meritek Series
Logic
Supply Voltage
Frequency Stability
Operating Temp.
Frequency
Pin 1
D
IMENSIONS AND
R
ECOMMENDED
P
ATTERN
Pin
1
2
3
4
5
6
Function
Tri-state / NC
NC / Tristate
GND
Q
Q Complimentary
V
DD
(Unit:mm)
A
VAILABLE
O
PTIONS
Parameters
Supply Voltage
Frequency Stability
Operating Temp.
25: 2.5V±10%, 33: 3.3V±10%
F: ±20ppm, G: ±25ppm, H: ±30ppm, J: ±50ppm, K: ±100ppm
A: -10~+60C, B: 0~+70C, C: -20~+70C, K: -30~+85C, I: -40~+85C, R: -40~+105C
Part Number Options
Note: Custom options available. Contact Meritek for more information.
Meritek Electronics Corporation
|
www.meritekusa.com
Rev.8a 04/02/2018
Ceramic SMD Crystal Oscillator
SMD 7.0 x 5.0mm PECL
E
LECTRICAL
C
HARACTERISTICS
Parameters
Frequency Range
Logic
Supply Voltage
Frequency Stability
Operating Temperature
Storage Temperature
Duty Cycle
Aging @25°C (first year)
Ouput Level (PECL)
Output Load (PECL)
Supply Current
Start Up Time
Rise/ Fall Time (Tr/Tf)
Tri-State (Input Pin 1 or
Pin 2)
19.44MHz ~ 320.0MHz
Enable High or Float
Disable Low or GND
High (Logic 1)
Low (Logic 0)
MO7P series
Characteristic
19.44 ~ 320.000 MHz
PECL
3.3V ±10% (see options)
±50 ppm (see options)
-20 ~ +70°C (see options)
-55 ~ +125°C
50±5%
±3 ppm
Vdd -1.025V min.
Vdd -1.620V max.
50 Ω
100mA max. (see Table 1)
3mSec max.
1nSec max.
0.7 Vdd min.
0.3 Vdd max.
1pSec max.
-70 dBc/Hz
-100 dBc/Hz
-125 dBc/Hz
(mA max.)
RMS Phase Jitter (12Khz~20MHz)
100 Hz
Phase Noise
1 KHz
10 KHz
T
ABLE 1: SUPPLY CURRENT
Frequency
80.00 MHz ~ 159.99 MHz
160.00 MHz ~ 249.99 MHz
250.00 MHz ~ 320.00 MHz
3.3V
75
100
100
2.5V
75
100
100
R
ECOMMENDED
S
OLDERING
P
ROFILES
Reflow Condition
Pre
Heat
Temp. Min T
s(min)
Temp. Max T
s(max)
Time (min. to max.) (t
s
)
150°C
180°C
60~120 seconds
1°C/second max.
3°C/second max.
230°C
30~40 seconds
260°C
10 seconds max.
6°C/second
Average ramp up rate (T
L
) to peak
T
s(max)
to T
L
(Ramp-up rate)
Reflow
Temp. (T
L
)
Time (min. to max.) (t
L
)
Peak Temperature (T
P
)
Time within 5°C of actual peak
Temperature (t
p
)
Ramp-down Rate
*Specifications subject to change without notice.
Meritek Electronics Corporation
|
www.meritekusa.com
Rev.8a 04/02/2018
