SIDACtor
®
Protection Thyristors
Baseband Protection (Voice-DS1)
SIDACtor
®
Balanced Multiport Series - MS-013
Description
SIDACtor
®
Balanced Multiport Series MS-013 are designed
to protect baseband equipment from overvoltage
balanced overvoltage protection.
The series provides a dual port surface mount solution that
enables voice through DS-1 equipment to comply with
various global regulatory standards.
Features and Benefits
Low voltage overshoot
Low on-state voltage
Agency Approvals
Agency
Agency File Number
E133083
Replaces six discrete
devices
Balanced overvoltage
protection
Meets UL/IEC 60950-1
creepage and clearance
Two-port protection
Does not degrade with
use
Fails short circuit when
surged in excess of
ratings
Low Capacitance
6
5
4
Pinout Designation
1
2
3
Applicable Global Standards
TIA-968-A
TIA-968-B
ITU K.20/21 Enhanced
Level*
ITU K.20/21 Basic Level
GR 1089 Intra-building
IEC 61000-4-5
YD/T 1082
YD/T 993
YD/T 950
Schematic Diagram
1
2
3
6
5
4
GR 1089 Inter-building*
*A/B-rated parts require series resistance
Electrical Characteristics
V
S
V
DRM
V
S
V
DRM
@l
DRM
=5μA @100V/μs @l
DRM
=5μA @100V/μs
V min
V max
V min
V max
Pins 1-2, 3-2, 4-5, 6-5
Pins 1-3, 4-6
Part Number
Marking
V
T
@I
T
=2.2 A
V max
Pins 1-2, 3-2, 4-5, 6-5
I
H
mA
min
I
S
mA
max
I
T
A
max
Capacitance
A2106UA6Lxx
A5030UA6Lxx
A2106UB6Lxx
A5030UB6Lxx
A2106UC6Lxx
A5030UC6Lxx
P1556UALxx
P1806UALxx
P2106UALxx
P2356UALxx
P2706UALxx
P3206UALxx
P3406UALxx
A2106UA6
A5030UA6
A2106UB6
A5030UB6
A2106UC6
A5030UC6
P1556UA
P1806UA
P2106UA
P2356UA
P2706UA
P3206UA
P3406UA
170
400
170
400
170
400
130
150
170
200
230
270
300
250
550
250
550
250
550
180
210
250
270
300
350
400
50
270
50
270
50
270
130
150
170
200
230
270
300
153
80
340
80
340
80
340
180
210
250
270
300
350
400
8
8
8
8
8
8
8
8
8
8
8
8
8
120 800 2.2
150 800 2.2
120 800 2.2
150 800 2.2
120 800 2.2
150 800 2.2
See
150 800 2.2
Capacitance
Values Table
150 800 2.2
150 800 2.2
150 800 2.2
150 800 2.2
150 800 2.2
150 800 2.2
Table continues on next page.
© 2011 Littelfuse, Inc.
Specifications are subject to change without notice.
Please refer to www.littelfuse.com for current information.
Revised: February 22, 2011
