5.0V HCMOS TRI-STATE ENABLE/DISABLE OSCILLATORS
MODEL: H5C-2E
FEATURES
•
•
•
•
5.0V Operationg
HCMOS/TTL Output
Tri-State Enable/Disable
8-Pin DIP
OPTIONS
• 14-Pin DIP Available (F5C-2E)
Discontinued
Internet required
Learn more about:
Part Marking Identification
Mechanical Specification
• PART NUMBER SELECTION
Part Number
267-Frequency-xxxxx
347-Frequency-xxxxx
271-Frequency-xxxxx
335-Frequency-xxxxx
275-Frequency-xxxxx
336-Frequency-xxxxx
342-Frequency-xxxxx
Learn More - Internet Required
Operating
Model Frequency
Stability
1
Temperature (ºC)
Number
0 ~ +70
±100PPM
H5C-2E
-40 ~ +85
H5C-2ER
±100PPM
0 ~ +70
±50PPM
H6C-2E
-40 ~ +85
H6C-2ER
±50PPM
0 ~ +70
±25PPM
H7C-2E
-40 ~ +85
±25PPM
H7C-2ER
0 ~ +70
±20PPM
H8C-2E
Frequency
Range (MHz)
1.000 ~ 160.000
1.000 ~ 160.000
1.000 ~ 160.000
1.000 ~ 160.000
1.000 ~ 160.000
1.000 ~ 125.000
1.000 ~ 125.000
• ELECTRICAL CHARACTERISTICS
PARAMETERS
Frequency Range (F
O
)
Storage Temperature Range (T
STG
)
Supply Voltage
(V
DD
)
Input Current
(I
DD
)
1.000 ~ 40.000 MHz
40.000+ ~ 125.000 MHz
125.000+ ~ 160.000 MHz
Output Symmetry (50% V
DD
)
1.000 ~ 50.000 MHz
50.000+ ~ 160.000 MHz
Rise Time (10% ~ 90% V
DD
) (T
R
)
1.000 ~ 125.000 MHz
125.000+ ~ 160.000 MHz
Fall Time (90% ~ 10% V
DD
) (T
F
)
1.000 ~ 125.000 MHz
125.000+ ~ 160.000 MHz
Output Voltage
(V
OL
)
(V
OH
)
Output Current
(I
OL
)
(I
OH
)
Output Load
TTL
HCMOS
Start-up Time
(T
S
)
Output Enable/Disable Time
2
1
MAX
(unless otherwise noted)
1.000 ~ 160.000 MHz
-55ºC ~ +125ºC
5.0V ± 10%
40mA
60mA
100mA
45% ~ 55%
40% ~ 60%
10 nS
6 nS
10 nS
6 nS
10% V
DD
90% V
DD
Min
16mA Min
-16mA Min
10TTL
50pF
10mS
100nS
All dimensions are in millimeters.
Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, aging,
shock, and vibration.
2
An internal pullup resistor from pin 1 to V
DD
allows active output if pin 1 is left open.
All specifications subject to change without notice.
Rev. 6/1/04
• ENABLE / DISABLE FUNCTION
INH (Pin 1)
OUTPUT (Pin 5)
2
OPEN
ACTIVE
'1' Level V
IH
≥
2.2 V
ACTIVE
'0' Level V
IL
≤
0.8 V
High Z
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1(239)693-0099 FAX +1(239)693-1554
http://www.foxonline.com
© 2004 FOX ELECTRONICS
