KBP301G - KBP307G
Pb
RoHS
COMPLIANCE
Single Phase 3.0AMPS. Glass Passivated Bridge Rectifiers
KBP
Features
UL Recoganized File #E-326243
Glass passivated junction
Ideal for printed circuit board
High case dielectric strength
Plastic material has Underwriters laboratory
flammability Classification 94V-0
Typical IR less than 0.1uA
High surge current capability
High temperature soldering guaranteed:
260℃/10 seconds at 5 lbs.,(2.3kg) tension
Green compound with suffix "G" on packing
code & prefix "G" on datecode
Mechanical Data
Case: Molded plastic body
Terminals: Pure tin plated, lead free, solderable
per MIL-STD-202, Method 208
Weight: 1.54 grams (0.055 ounce)
Mounting position : Any
Dimensions in inches and (millimeters)
Marking Diagram
KBP30XG
G
Y
WW
= Specific Device Code
= Green Compound
= Year
= Work Week
Maximum Ratings and Electrical Characteristics
Rating at 25
℃
ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Type Number
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current @TA=50℃
Peak Forward Surge Current, 8.3 ms Single Half Sine-
wave Superimposed on Rated Load (JEDEC method)
Rating of fusing ( t<8.3ms)
Maximum Instantaneous Forward Voltage
@3A
Maximum DC Reverse Current
at Rated DC Block Voltage
@T
A
=25℃
@ T
A
=125
℃
Symbol
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
I
2
T
V
F
I
R
Cj
R
θjA
R
θjL
T
J
T
STG
KBP
301G
50
35
50
KBP
302G
100
70
100
KBP
303G
200
140
200
KBP
304G
400
280
400
3
80
26.5
1.1
10
500
215
30
11
KBP
305G
600
420
600
KBP
306G
800
560
800
KBP
307G
1000
700
1000
Unit
V
V
V
A
A
A
2
S
V
uA
pF
O
Typical Junction Capacitance per leg (Note 1)
Typical Thermal Resistance (Note 2)
Operating Temperature Range
Storage Temperature Range
C/W
O
O
- 55 to + 150
- 55 to + 150
C
C
Note 1 : Measured at 1MHz and applied Reverse bias of 4.0V DC
Note 2 : Unit mount on P.C.B. 0.4" x 0.4" (10mmx10mm) Copper pads, 0.375"(9.5mm) lead length
Version:E10
RATINGS AND CHARACTERISTIC CURVES (KBP301G THRU KBP307G)
FIG.1 FORWARD CURRENT DERATING CURVE
4
PEAK FORWARD SURGE
A
CURRENT (A)
AVERAGE FORWARD
A
CURRENT (A)
80
FIG. 2 MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT
8.3mS Single Half Sine Wave
(JEDEC Method)
3
60
2
40
1
20
0
0
20
40
60
80
100
o
0
120
140
160
1
CASE TEMPERATURE ( C)
10
NUMBER OF CYCLES AT 60 Hz
100
FIG. 3 TYPICAL REVERSE CHARACTERISTICS
1000
INSTANTANEOUS REVERSE
A
CURRENT (uA)
100
FIG. 4 TYPICAL FORWARD CHARACTERISRICS
100
TA=125℃
10
INSTANTANEOUS FORWARD
A
CURRENT (A)
100
120
140
10
1
1
TA=25℃
0.1
0.1
0
20
40
60
80
0.01
0.4
0.5
0.6
0.7
0.8
0.9
1
1.1
1.2
1.3
1.4
FORWARD VOLTAGE (V)
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
FIG. 5 TYPICAL JUNCTION CAPACITANCE
1000
CAPACITANCE (pF)
A
100
10
0.1
1
10
100
REVERSE VOLTAGE (V)
Version:E10
