CREAT BY ART
KBU801G - KBU807G
Pb
RoHS
COMPLIANCE
Single Phase 8.0AMPS. Glass Passivated Bridge Rectifiers
KBU
Features
UL Recoganized File #E-326243
Glass passivated junction
Ideal for printed circuit board
High case dielectric strength
Plastic material has Underwriters Laboratory
flammability Classification 94V-0
Typical IR less than 0.1uA
High surge current capability
High temperature soldering guaranteed:
260℃/10 seconds at 5 lbs.,(2.3kg) tension
Green compound with suffix "G" on packing
code & prefix "G" on datecode
Mechanical Data
Case: Molded plastic body
Terminal: Pure tin plated, lead free, solderable per
MIL-STD-202, Method 208
Weight: 7.2 grams
Mounting Torque: 5 in lbs max.
Dimensions in inches and (millimeters)
Marking Diagram
KBU80XG
G
Y
WW
= Specific Device Code
= Green Compound
= Year
= Work Week
Maximum Ratings and Electrical Characteristics
Rating at 25
℃
ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Type Number
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
@T
A
=65℃
Peak Forward Surge Current, 8.3 ms Single Half Sine-
wave Superimposed on Rated Load (JEDEC method)
Rating of fusing (t<8.3mS)
Maximum Instantaneous Forward Voltage (Note 1)
@4A
@8A
Maximum DC Reverse Current
at Rated DC Blocking Voltage
@ T
A
=25
℃
@ T
A
=125
℃
Symbol
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
I
2
t
V
F
KBU
801G
50
35
50
KBU
802G
100
70
100
KBU
803G
200
140
200
KBU
804G
400
280
400
8
200
166
1.0
1.1
5
500
400
18
3
KBU
805G
600
420
600
KBU
806G
800
560
800
KBU
807G
1000
700
1000
Units
V
V
V
A
A
A
2
S
V
I
R
Cj
R
θJA
R
θJC
T
J
T
STG
uA
pF
O
Typical Junction Capacitance per leg (Note 2)
Typical Thermal Resistance
Operating Temperature Range
Storage Temperature Range
Note 1 : Pulse Test with PW=300u sec, 1% Duty Cycle
C/W
O
O
- 55 to + 150
- 55 to + 150
C
C
Note 2 : Measured at 1MHz and applied Reverse bias of 4.0V D.C.
Version:F12
RATINGS AND CHARACTERISTIC CURVES (KBU801G THRU KBU807G)
FIG.1 MAXIMUM DERATING CURVE FOR OUTPUT
CURRNET
8
PEAK FORWARD SURGE
A
CURRENT (A)
AVERAGE FORWARD
A
CURRENT (A)
6
4
2
0
0
20
40
60
80
100
o
200
180
160
140
120
100
80
60
40
20
0
120
140
160
1
AMBIENT TEMPERATURE ( C)
FIG. 2 MAXIMUM FORWARD SURGE CURRENT
PER LEG
8.3mS Single
Half Sine Wave
(JEDEC Method)
10
NUMBER OF CYCLES AT 60 Hz
100
1000
INSTANTANEOUS REVERSE CURRENT
(uA)
FIG. 3 TYPICAL REVERSE CHARACTERISTICS PER
LEG
100
INSTANTANEOUS FORWARD CURRENT
(A)
100
120
140
FIG. 4 TYPICAL FORWARD CHARACTERISRICS PER
LEG
100
TA=125℃
10
10
1
TA=25℃
1
0.1
0
20
40
60
80
PERCENT OF RATED PEAK REVERSE VOLTAGE (V)
0.1
0.6
0.7
0.8
0.9
1
1.1
1.2
INSTANTANEOUS FORWARD VOLTAGE (V)
1.3
FIG. 5 TYPICAL JUNCTION CAPACITANCE
1000
JUNCTION CAPACITANCE (pF)
A
100
10
0.1
1
10
100
REVERSE VOLTAGE (V)
Version:F12
