ALUMINUM ELECTROLYTIC CAPACITOR
GHR
直立式
105°C
標準型品
Radial Leads, 105°C Standard Series
i
2,000
105
i
i
Designed in high CV value with smaller size and
suitable for high reliability products use.
i
Life guaranteed 2,000hours/105°C.
i
Specifications
Item
Operating Temperature
range
Rated Voltage
Capacitance Range
容量範圍
Capacitance Tolerance
Leakage Current
-40 + 105°C
6.3V
∼
100V
0.1
∼
47,000
µF
±20%
(120Hz, 20°C)
I
≤
0.02CV or 4
µA,
whichever is greater after 2 minutes
application of rated voltage.
Rated voltage (V)
Tan
δ
(max.)
6.3
0.28
10
0.24
16
0.20
25
0.16
I
≤
0.03CV + 10
µA,
whichever is greater after 2 minutes
application of rated voltage.
35
0.14
50
0.12
63
0.10
100
0.08
160∼250 350∼450
0.20
0.25
Performance Characteristics
-25 + 105°C
160V
∼
450V
Dissipation Factor
(120Hz, 20°C)
Temperature
Characteristics
(120Hz)
For capacitance of more than 1,000µF, add 0.02 for every increase of 1,000µF.
Impedance Ratio / Stability at Low Temperature
Rated voltage (V)
Z (-25°C) / Z (20°C)
Z (-40°C) / Z (20°C)
Capacitance change
Tan
δ
Leakage current
6.3
5
10
10
4
8
16
3
6
25
2
4
35
2
3
50
2
3
63
2
3
100
2
3
160∼200 250∼350
3
4
4
8
400
6
10
450
15
-
After 2,000 hours application of WV at 105°C, capacitor shall meet the characteristics requirements mentioned below.
Load Life
Within
±20%
of initial value
200% or less of initial specified value
Initial specified value or less
Shelf Life
After leaving capacitors under no load at 105°C for 1,000 hours and applying voltage according to JIS C5102 and C5141, they
shall meet the specified value as load life characteristics listed above.
i
Dimension
α
φ
D
P
φ
d
∼100WV
160WV∼
5
2.0
6.3
2.5
0.5
1.0
1.5
8
3.5
10
5.0
0.6
1.5
2.0
13
5.0
16
7.5
0.8
1.5
2.0
18
7.5
20
22
1.0
2.0
2.0
25
10.0 10.0 12.5
ALUMINUM ELECTROLYTIC CAPACITOR
i
Standard Products Table
WV(SV)
Cap(µF)
0.1
0.22
0.33
0.47
1
2.2
3.3
4.7
10
22
33
47
68
100
220
330
470
1000
2200
3300
100
(125)
5 x 11
5 x 11
5 x 11
5 x 11
5 x 11
5 x 11
5 x 11
5 x 11
6.3 x 11
5 x 11
6.3 x 11
8 x 11
10 x 12
8 x 11
10 x 12
10 x 20
10 x 16
13 x 25
13 x 20
13 x 25
16 x 25
18 x 40
18 x 36
22 x 50
25 x 50
1.5
3.4
5.0
7.1
15
21
29
32
54
50
93
130
165
140
190
265
240
440
390
540
715
985
960
1750
2070
16 x 36
16 x 32
18 x 40
18 x 36
22 x 40
18 x 40
25 x 50
570
410
750
570
900
855
1310
10 x 16
10 x 12
10 x 20
10 x 16
13 x 20
10 x 20
13 x 20
13 x 25
100
92
145
125
195
150
250
315
13 x 25
16 x 32
16 x 25
18 x 36
16 x 36
20 x 40
18 x 40
22 x 50
22 x 40
250
375
320
575
500
705
675
840
925
6.3 x 11
6.3 x 11
6.3 x 11
6.3 x 11
6.3 x 11
8 x 11
11
16
25
30
34
41
160
(200)
200
(250)
6.3 x 11
6.3 x 11
6.3 x 11
6.3 x 11
6.3 x 11
6.3 x 11
6.3 x 11
8 x 11
6.3 x 11
10 x 12
8 x 11
10 x 20
10 x 16
13 x 20
10 x 20
13 x 20
1.5
3.3
5
11
16
25
30
39
35
65
57
120
105
160
140
195
6.3 x 11
6.3 x 11
6.3 x 11
8 x 11
6.3 x 11
8 x 11
6.3 x 11
10 x 16
10 x 12
13 x 20
10 x 20
13 x 20
10 x 20
13 x 25
13 x 20
16 x 25
16 x 32
16 x 25
20 x 40
18 x 36
22 x 50
20 x 40
25 x 50
22 x 50
10
15
23
32
28
39
35
74
71
130
105
160
140
210
190
270
365
310
600
485
730
710
870
1000
25 x 50
710
6.3 x 11
8 x 11
6.3 x 11
10 x 12
8 x 11
10 x 12
8 x 11
10 x 20
10 x 12
13 x 25
13 x 20
16 x 25
13 x 25
16 x 36
16 x 25
16 x 25
18 x 40
18 x 36
22 x 50
15
26
21
38
30
45
39
80
64
115
105
195
170
270
210
285
420
370
620
6.3 x 11
8 x 11
6.3 x 11
10 x 12
8 x 11
10 x 12
8 x 11
10 x 16
10 x 12
13 x 20
10 x 16
16 x 25
13 x 25
16 x 32
16 x 25
16 x 36
16 x 25
16 x 32
20 x 40
18 x 36
25 x 50
22 x 50
8.5
17
14
30
27
38
34
50
42
90
64
165
140
215
170
270
200
240
450
310
660
460
10 x 12
8 x 11
10 x 16
10 x 12
10 x 20
10 x 12
13 x 20
10 x 20
16 x 25
13 x 25
16 x 36
16 x 25
18 x 40
16 x 32
18 x 36
22 x 40
18 x 40
25 x 50
23
20
31
28
40
32
65
27
115
100
165
125
185
155
185
270
200
250
8 x 11
13
250
(300)
350
(400)
400
(450)
D
φ
x L (mm)
450
(500)
Case Size Ripple
Ripple (mA rms) at 105°C 120 Hz
iFrequency
coefficient of allowable ripple current
WV
6.3~100
Cap(µF)
Frequency
50 Hz
0.75
0.80
0.85
0.80
0.95
120 Hz
1
1
1
1
1
300 Hz
1.35
1.23
1.10
1.25
1.10
1 KHz
1.57
1.34
1.13
1.40
1.13
10 KHz∼
2.00
1.50
1.15
1.60
1.15
~
47
100
~
470
1,000
~
33,000
160~450
0.47
~
220
330
~
1,000
iAllowable
ripple vs. Ambient temperature
Ambient Temp. (°C)
Compensating Coefficient
~
+70
1.78
+85
1.4
+105
1.1
