KMABP
Series
Miniature
Bi-Polar
7mm Nominal
Height
105 C
Maximum
Temperature
Actual
Size
MINIATURE -105 C
KMABP
The KMABP series are bi-polar capacitors similar to the KMA series. These capacitors have a 7mm
nominal height for use in ultra miniature applications where the polarity will be reversed or is
unknown. Please note that these capacitors cannot withstand an AC application in which the
maximum ripple current is exceeded.
The KMABP series capacitors are non-solvent proof and are not recommended when halogenated
cleaning solvents are used. Refer to the Mini-Glossary for recommended cleaning conditions.
Summary of Specifications
Radial lead terminals.
Capacitance range: 0.1 to 100µF.
Voltage range: 4 to 63VDC.
Operating temperature range: 55 C to 105 C.
Leakage current: 0.05CV or 10µA, whichever is greater, after 2 minutes at
Standard capacitance tolerance: 20%
Nominal case size (D L): 4 7mm to 7 7mm.
Rated lifetime: 1,000 hours at 105 C.
20 C.
184
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
KMABP Series
KMABP Specifications
Item
Operating Temperature Range
Rated Voltage Range
Capacitance Range
Capacitance Tolerance
Leakage Current
I
55 to 105 C
4 to 63VDC
0.1 to 100 F
20% ( M ) at
20 C, 120Hz
20 C.
Characteristics
0.05CV or 10 A, whichever is greater, after 2 minutes at
Where I = Leakage current ( A ), C = Nominal capacitance ( F ) and V = Rated voltage ( V )
Dissipation Factor ( Tan )
At
20 C, 120Hz
MINIATURE -105 C
Rated Voltage ( V )
Tan
( DF )
4
0.37
6.3
0.26
10
0.22
16
0.18
25
0.18
35
0.16
50
0.14
63
0.12
KMABP
Low Temperature
Characteristics
At 120Hz, impedance ( Z ) ratio between the
exceed the values given below.
Rated Voltage ( V )
Z ( 25 C ) / Z ( 20 C )
Z ( 40 C ) / Z ( 20 C )
4
4
10
6.3
4
10
10
3
8
25 C or
16
2
6
40 C value and
25
2
4
35
2
3
20 C value shall not
50
2
3
63
2
3
Load Life
The following specifications shall be satisfied when the capacitors are restored to 20 C
after subjecting them to the DC rated voltage for 1,000 hours at 105 C. Polarization shall be
reversed every 250 hours. The sum of DC voltage and peak AC voltage must not exceed the
full rated voltage of the capacitors.
Capacitance change:
≤
25% of initial measured value for
≤
16V
:
≤
20% of initial measured value for
≥
25V
Tan ( DF )
:
≤
200% of initial specified value
Leakage current
:
≤
initial specified value
Shelf Life
The following specifications shall be satisfied when the capacitors are restored to 20 C
after exposing them for 500 hours at 105 C without voltage applied. The rated voltage shall
be applied to the capacitors for a minimum of 30 minutes, at least 24 hours and not more
than 48 hours before the measurements.
Capacitance change:
≤
25% of initial measured value for
≤
16V
:
≤
20% of initial measured value for
≥
25V
Tan ( DF )
:
≤
200% of initial specified value
Leakage current
:
≤
initial specified value
Others
Satisfies characteristic W of JIS C5141
Part Numbering System for KMABP Series
KMABP
63
VB
4R7
M
7X7
LL
When ordering, always specify complete catalog number for KMABP Series.
Lead Length: LL is Standard.
Case Code: See Case Sizes in Tables.
Capacitance Tolerance: M = 20%
Capacitance Value: Expressed in Microfarads. The first two digits are
significant figures, and the third digit indicates the number of zeros
for capacitance of 100 F or more. R indicates the decimal point for
capacitance less than 100 F (e.g. R47 = .47 F; 4R7 = 4.7 F;
47R = 47 F; 471 = 470 F; 472 = 4,700 F; 473 = 47,000 F ).
Lead Configuration: VB = Radial Lead Terminals.
DC Rated Voltage: Expressed in Volts (e.g. 63 = 63WVDC).
Series Name: Indicates Basic Capacitor Design.
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
185
KMABP Series
Diagram of Dimensions
VB/Radial Lead
Unit: mm
PVC Sleeve
d
D
'
D
F
L
MINIATURE -105 C
L
'
15
MIN.
4
MIN.
4~ 7
KMABP
Gas escape end seal for all case diameters.
Ø
D
Ø
D
'
max.
Ø
D
Ø
D
For optional lead configurations and tape and ammo
packaging, refer to the beginning of the Miniature section.
4
5
0.6.3
7
0.5
0.5
Ø
D 0.5
Ø
D 0.5
L
'
max.
L 1.0
L 1.0
L 1.0
L 1.0
Ø
d
0.45
0.45
0.45
0.45
F 0.5
1.5
2.0
2.5
2.5
Standard Voltage Ratings - VB/Radial Lead
Rated
Voltage
(WVDC)
Capacitance
(µF )
Catalog
Part Number
Nominal
Case Size*
D L ( mm )
Maximum ESR
(
Ω
) at
20 C, 120Hz
Maximum
Ripple Current
( mA rms) at
105 C, 120Hz
5 Volts Surge
4 Volts
100
KMABP4VB101M7X7LL
7
7
6.133
66
6.3 Volts
8 Volts Surge
22
33
47
10
22
33
47
4.7
10
22
33
3.3
4.7
10
22
2.2
3.3
4.7
10
KMABP6.3VB22RM5X7LL
KMABP6.3VB33RM5X7LL
KMABP6.3VB47RM6X7LL
KMABP10VB10RM4X7LL
KMABP10VB22RM5X7LL
KMABP10VB33RM6X7LL
KMABP10VB47RM7X7LL
KMABP16VB4R7M4X7LL
KMABP16VB10RM5X7LL
KMABP16VB22RM6X7LL
KMABP16VB33RM7X7LL
KMABP25VB3R3M4X7LL
KMABP25VB4R7M5X7LL
KMABP25VB10RM6X7LL
KMABP25VB22RM7X7LL
KMABP35VB2R2M4X7LL
KMABP35VB3R3M5X7LL
KMABP35VB4R7M5X7LL
KMABP35VB10RM7X7LL
5
5
6.3
4
5
6.3
7
4
5
6.3
7
4
5
6.3
7
4
5
5
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
19.589
13.059
9.169
36.465
16.575
11.05
7.759
63.479
29.835
13.561
9.041
90.409
63.479
29.835
13.561
120.545
80.364
56.426
26.52
33
40
49
23
36
45
55
18
27
41
52
15
18
28
42
13
16
20
30
10 Volts
13 Volts Surge
16 Volts
20 Volts Surge
25 Volts
32 Volts Surge
35 Volts
44 Volts Surge
*
The case sizes in table are with no sleeve, refer to diagram for case sizes with sleeve.
186
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
