SFAF1001G - SFAF1008G
10.0AMPS. Isolated Glass Passivated Super Fast Rectifiers
ITO-220AC
Features
UL Recognized File # E-326243
High efficiency, low VF.
High current capavility
High reliability
High surge current capability
Low power loss.
For use in low voltage, high frequency inverter,
free wheeling, and polarity protection
application
Green compound with suffix "G" on packing
code & prefix "G" on datecode.
Mechanical Data
Cases: ITO-220AC molded plastic
Epoxy: UL 94V-0 rate flame retardant
Terminals: Pure tin plated, lead free, solderable per
MIL-STD-202, Method 208 guaranteed
Polarity: As marked
High temperature soldering guaranteed:
260
o
C/10 seconds
Weight: 1.70 grams
Ordering Information(example)
Part No.
SFAF1001G
Package
ITO-220AC
Packing
50 / TUBE
Packing code
C0
Packing code
(Green)
C0G
Maximum Ratings and Electrical Characteristics
Rating at 25
℃
ambient temperature unless otherwise specified.
Parameter
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
Peak Forward Surge Current, 8.3 ms Single Half Sine-wave
Superimposed on Rated Load (JEDEC method)
Maximum Instantaneous Forward Voltage
@ 10 A
Maximum DC Reverse Current
at Rated DC Blocking Voltage
(Note 1)
Symbol
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
V
F
I
R
Trr
Cj
R
θJC
T
J
T
STG
SFAF SFAF SFAF SFAF SFAF SFAF SFAF SFAF
1001G 1002G 1003G 1004G 1005G 1006G 1007G 1008G
50
100
150
200
300
400
500
600
35
50
70
100
105
150
140
200
10
150
0.975
10
400
35
170
4
- 65 to + 150
- 65 to + 150
140
1.3
1.7
210
300
280
400
350
500
420
600
Units
V
V
V
A
A
V
uA
uA
nS
pF
O
@ T
A
=25
℃
@ T
A
=100
℃
Maximum Reverse Recovery Time (Note 2)
Typical Junction Capacitance (Note 3)
Typical Thermal Resistance
Operating Temperature Range
Storage Temperature Range
Note 1: Pulse Test with PW=300 usec, 1% Duty Cycle
C/W
O
O
C
C
Note 2: Reverse Recovery Test Conditions: I
F
=0.5A, I
R
=1.0A, I
RR
=0.25A.
Note 3: Measured at 1 MHz and Applied Reverse Voltage of 4.0V D.C.
Version:E13
RATINGS AND CHARACTERISTIC CURVES (SFAF1001G THRU SFAF1008G)
FIG.1- MAXIMUM FORWARD CURRENT
DERATING CURVE
FIG. 2- TYPICAL REVERSE CHARACTERISTICS
1000
12
AVERAGE FORWARD
A
CURRENT (A)
10
8
6
4
2
0
0
RESISTIVE OR
INDUCTIVELOAD
WITH HEAT SINK
INSTANTANEOUS REVERSE CURRENT. (uA)
100
TA=100℃
TA=75℃
10
50
100
CASE TEMPERATURE (
o
C)
150
FIG. 3- MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT
PEAK FORWARD SURGE CURRENT
(A)
250
1
TA=25℃
TA=25℃
200
150
100
50
0
1
10
NUMBER OF CYCLES AT 60 Hz
100
8.3ms Single Half Sine Wave
JEDEC Method
0.1
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
FIG. 5- TYPICAL FORWARD CHARACTERISTICS
100
SFAF1001G-SFAF1004G
INSTANTANEOUS FORWARD CURRENT. (A)
FIG. 4- TYPICAL JUNCTION CAPACITANCE
300
250
CAPACITANCE (pF)
200
10
TA=25
o
C
SFAF1001G~SFAF1004G
150
100
50
1
SFAF1005G-SFAF1006G
SFAF1007G-SFAF1008G
TA=25
o
C
Pulse Width=300us
1% Duty Cycle
0.4
0.6
0.8
1
1.2
1.4
FORWARD VOLTAGE. (V)
1.6
1.8
SFAF1005G~SFAF1008G
0
1
10
100
1000
REVERSE VOLTAGE. (V)
0.1
Version:E13
