LL4001G - LL4007G
1.0AMP Surface Mount
Glass Plassivated Silicon Rectifiers
MELF
Features
Plastic package has carries underwriters
Laboratory flammability classification 94V-0
Surge overload rating to 30 Ampers peak
Ideal for printed circuit board.
Reliable low cost construction utilizing molded
plastic technique results in in-expensive
product.
High temperature soldering guaranteed:
o
260 C / 10 seconds at terminals.
Mechanical Data
Solderability per MIL-STD-750, method 208 at
terminals.
Mounting position: Any
Weight: 0.12 gram
Dimensions in inches and (millimeters)
Maximum Ratings and Electrical Characteristics
Rating at 25
o
C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Type Number
M
aximum
Recurrent P
eak
R
everse
V
oltage
Symbol
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
V
F
I
R
LL
LL
LL
LL
LL
LL
LL
4001G 4002G 4003G 4004G 4005G 4006G 4007G
Units
V
V
V
A
A
V
uA
uA
pF
o
C/W
o
C
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
@T
A
= 75
o
C
Peak Forward Surge Current, 8.3 ms Single
Half Sine-wave Superimposed on Rated Load
(JEDEC method )
Maximum Instantaneous Forward Voltage
@1.0A
Maximum DC Reverse Current @ T
A
=25
o
C
at Rated DC Blocking Voltage @ T
A
=125
o
C
Typical Junction Capacitance ( Note 1 )
Typical Thermal Resistance (Note 2)
50
35
50
100
70
100
200
140
200
400
280
400
1.0
30
1.1
600
420
600
800
560
800
1000
700
1000
Cj
R
θJC
Operating and Storage Temperature Range
T
J
,T
STG
1. Measured at 1 MHz and Applied Reverse Voltage of 4.0 Volts D.C.
Notes:
2. Thermal Resistance from Junction to case. Mount on 0.2” x 0.2” Cu-pad on P.C.B.
5
100
15
50
- 65 to + 150
Version: A06
