HS2A - HS2M
2.0AMPS High Efficient Surface Mount Rectifiers
SMB/DO-214AA
Pb
RoHS
COMPLIANCE
Features
Glass passivated junction chip.
For surface mounted application
Low forward voltage drop
Low profile package
Built-in stain relief, ideal for automatic
placement
Fast switching for high efficiency
High temperature soldering:
260℃/10 seconds at terminals
Plastic material used carries Underwriters
Laboratory Classification 94V-0
Green compound with suffix "G" on packing
code & prefix "G" on datecode
Mechanical Data
Cases: Molded plastic
Terminal: Pure tin plated, lead free
Polarity: Indicated by cathode band
Packing: 12mm tape per EIA STD RS-481
Weight: 0.093 grams
Dimensions in inches and (millimeters)
Marking Diagram
HS2X = Specific Device Code
G
Y
M
= Green Compound
= Year
= Work Month
Maximum Ratings and Electrical Characteristics
Rating at 25
℃
ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Type Number
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
See Fig. 1
Peak Forward Surge Current, 8.3 ms Single Half Sine-
wave Superimposed on Rated Load (JEDEC method)
Maximum Instantaneous Forward Voltage (Note 1)
@2A
Maximum DC Reverse Current
at Rated DC Blocking Voltage
@ T
A
=25
℃
@ T
A
=125
℃
Symbol
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
V
F
I
R
Trr
Cj
R
θJA
T
J
T
STG
HS
2A
50
35
50
HS
2B
100
70
100
HS
2D
200
140
200
HS
2F
300
210
300
2
50
HS
2G
400
280
400
HS
2J
600
420
600
HS
2K
800
560
800
HS
2M
1000
700
1000
Units
V
V
V
A
A
1.0
5
150
50
50
80
1.3
1.7
V
uA
uA
Maximum Reverse Recovery Time (Note 2)
Typical Junction Capacitance (Note 3)
Maximum Thermal Resistance
Operating Temperature Range
Storage Temperature Range
Note 1: Pulse Test with PW=300 usec, 1% Duty Cycle
75
30
O
nS
pF
C/W
O
O
- 55 to + 150
- 55 to + 150
C
C
Note 2: Reverse Recovery Test Conditions: I
F
=0.5A, I
R
=1.0A, I
RR
=0.25A
Note 3: Measured at 1 MHz and Applied V
R
=4.0 Volts
Version:E11
RATINGS AND CHARACTERISTIC CURVES (HS2A THRU HS2M)
FIG.1- MAXIMUM FORWARD CURRENT DERATING
CURVE
3
AVERAGE FORWARD
CURRENT (A)
1000
FIG. 2- TYPICAL REVERSE
CHARACTERISTICS
2.5
2
1.5
1
0.5
0
0
25
50
75
100
125
150
175
LEAD TEMPERATURE (
o
C)
INSTANTANEOUS REVERSE CURRENT (uA)
100
TA=100℃
10
TA=25℃
1
70
FIG. 3- MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT
0.1
0
20
40
60
80
100
120
PERCENT OF RATED PEAK REVERSE
VOLTAGE (%)
140
PEAK FORWARD SURGE
URRENT (A)
60
50
40
30
20
10
0
1
8.3mS Single Half Sine Wave
JEDEC Method
10
NUMBER OF CYCLES AT 60 Hz
100
10
FIG. 5- TYPICAL INSTANTANEOUS
FORWARD CHARACTERISRICS
INSTANTANEOUS FORWARD CURRENT (A)
FIG. 4- TYPICAL JUNCTION CAPACITANCE
175
JUNCTION CAPACITANCE (pF)
1
HS2A-HS2D
150
125
100
HS2A-HS2G
0.1
HS2G
75
50
25
0
0.1
1
10
REVERSE VOLTAGE (V)
HS2J-HS2M
0.01
HS2J-HS2M
100
1000
0.001
0
0.2
0.4
0.6
0.8
1
FORWARD VOLTAGE (V)
1.2
1.4
Version:E11
