Series 801 Mighty Mouse
High-Speed
Double-Start ACME Threads
801-038 PCB Receptacle Ordering Information
Printed Circuit Board Receptacles
feature low profile shells for minimum protrusion inside
enclosures and integral standoffs for board washout. The connector is equipped with special
PFA (Fluoropolymer) insulators and is optimized for use with high-speed differential wire such
as our 963-001 Series cable. Five insert arrangements are offered with 4, 7, 10, 19 and 26 PC
tail or solder cup terminations. Contacts are non-removable.
Water Immersion, Unmated
Specify 801-038 connectors for applications where open
face water immersion is not a requirement. For MIL-STD-810 Method 512G immersion
requirements, specify 801-041 watertight connectors . These 801-041 connectors are specially
sealed (“MOD-518”) and are 100% tested to maintain a helium leak rate of 1 x 10
-4
cc/second
at one atmosphere pressure differential from -40° C to +70° C.
How To Order
Sample Part Number
801-038
801-038
= PCB or Solder Cup Terminated Receptacle with Standard
Epoxy Potting.
801-041
= Receptacle for Solder Cup or PCB Termination with Special
Mod Code 518 Sealing for Open Face (Unmated) Water Immersion
Requirements. 100% Leak Tested.
-02
= Square Flange For Front or Rear Mounting
-07
= Jam Nut For Rear Panel Mounting
M
= Aluminum / Electroless Nickel RoHS Compliant
NF
= Aluminum / Cadmium with Olive Drab Chromate
ZNU
= Aluminum / Zinc-Nickel with Black Chromate
MT
= Aluminum / Nickel-PTFE RoHS Compliant
P
Series 801
High-Speed
Series
Shell Style
(See Table I)
Shell Material and Finish
1
4
6-4
2
6
3
5
6-7
1
7
-07
M
7-10
P
A
Z1
= Stainless Steel / Passivated RoHS Compliant
Shell Size - Insert Arrangement
6-4, 6-7, 7-10, 9-19, 10-26
(See page P-3)
P
= Pin, PC Tail
E
= Pin, Solder Cup
Contact Type
S
= Socket , PC Tail
F
= Socket, Solder Cup
A
= Normal
B
= Pos. B
C
= Pos. C
D
= Pos. D
E
= Pos. E
F
= Pos. F
Shell Key Positions
(See Page P-3)
Table I: Shell Style
-02
Square Flange
-07
Jam Nut
Table II: Shell Size – Insert Arrangement
2
3
4
7
10
9
7-10
8
3
2
1
4
7
12
16
19 18 17
13
3
2
1
4
8
6
11
15
18
23
3
1
2
4
9
12
16
21
25
26
24
9-19
10-26
Dimensions in Inches (millimeters) are subject to change without notice.
© 2014 Glenair, Inc.
Series 80 Mighty Mouse
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
P-10
