LY62W1024
Rev. 1.11
128K X 8 BIT LOW POWER CMOS SRAM
REVISION HISTORY
Revision
Rev. 1.0
Rev. 1.1
Rev. 1.2
Rev. 1.3
Rev. 1.4
Description
Initial Issue
Revised I
SB1
LL/LLI-LLE(max)= 50/100
A
=> 20/50
A
I
DR
LL/LLI-LLE(max)= 20/40
A
=> 12/30
A
Added SL Spec.
Revised typos in
FEATURES
Revised I
SB1
/I
DR(MAX.)
Added I
SB1
/I
DR
values when T
A
= 25
℃
and T
A
= 40
℃
Revised
FEATURES
&
ORDERING INFORMATION
Lead free and green package available
to
Green package available
Added packing type in
ORDERING INFORMATION
Revised V
TERM
to V
T1
and V
T2
Deleted T
SOLDER
in
ABSOLUTE MAXIMUN RATINGS
Revised
PACKAGE OUTLINE DIMENSION
in page 10/11/12/13
Revised
ORDERING INFORMATION
in page 14
Deleted E Grade
Revised
PIN CONFIGURATION
in page 2
Correct
ORDERING INFORMATION
Typo.
Added top view of BGA in
PIN CONFIGURATION
Deleted E Grade in
ORDERING INFORMATION
Deleted
WRITE CYCLE
Notes :
1. WE#, CE# must be high or CE2 must be low during all address transitions
in page 7
Revised
GENERAL DESCRIPTION
in page 1
Revised
32-pin TSOP I & 36-ball TFBGA Package Outline Dimension
Issue Date
Aug.28.2005
Mar.30.2006
Nov.2.2007
May.6.2008
Mar.30.2009
Rev. 1.5
Rev. 1.6
Rev. 1.7
Rev. 1.8
Rev. 1.9
May.7.2010
Aug.30.2010
Aug.9.2011
Apr.06.2012
May.20.2016
Rev. 1.10
Rev. 1.11
Jun.28.2016
Feb.06.2017
Lyontek Inc.
reserves the rights to change the specifications and products without notice.
2F, No.17, Industry E. Rd. II, Science-Based Industrial Park, Hsinchu 300, Taiwan.
TEL: 886-3-6668838
FAX: 886-3-6668836
0
LY62W1024
Rev. 1.11
128K X 8 BIT LOW POWER CMOS SRAM
GENERAL DESCRIPTION
The LY62W1024 is a 1,048,576-bit low power CMOS
static random access memory organized as 131,072
words by 8 bits. It is fabricated using very high
performance, high reliability CMOS technology. Its
standby current is stable within the range of operating
temperature.
The LY62W1024 is well designed for very low power
system applications, and particularly well suited for
battery back-up nonvolatile memory application.
The LY62W1024 operates from a single power
supply of 2.7V ~ 5.5V and all outputs are fully TTL
compatible.
FEATURES
Fast access time : 35/55/70ns
Low power consumption:
Operating current : 12/10/7mA (TYP.)
Standby current : 1A (TYP.) LL-version
0.8A (TYP.) SL-version
Single 2.7V ~ 5.5V power supply
All outputs TTL compatible
Fully static operation
Tri-state output
Data retention voltage : 1.5V (MIN.)
Green package available
Package : 32-pin 450mil SOP
32-pin 600mil PDIP
32-pin 8mm x 20mm TSOP I
32-pin 8mm x 13.4mm sTSOP
36-ball 6mm x 8mm TFBGA
PRODUCT FAMILY
Product
Family
LY62W1024
LY62W1024(I)
Operating
Temperature
0 ~ 70℃
-40 ~ 85℃
V
CC
Range
2.7 ~ 5.5V
2.7 ~ 5.5V
Speed
35/55/70ns
35/55/70ns
Power Dissipation
Standby(I
SB1,
TYP.) Operating(I
CC
,TYP.)
1µA(LL)/0.8µA(SL)
12/10/7mA
1µA(LL)/0.8µA(SL)
12/10/7mA
FUNCTIONAL BLOCK DIAGRAM
PIN DESCRIPTION
SYMBOL
DESCRIPTION
Address Inputs
Data Inputs/Outputs
Chip Enable Inputs
Write Enable Input
Output Enable Input
Power Supply
Ground
No Connection
Vcc
Vss
A0 - A16
DQ0 - DQ7
DECODER
128Kx8
MEMORY ARRAY
A0-A16
CE#, CE2
WE#
OE#
V
CC
V
SS
NC
DQ0-DQ7
I/O DATA
CIRCUIT
COLUMN I/O
CE#
CE2
WE#
OE#
CONTROL
CIRCUIT
Lyontek Inc.
reserves the rights to change the specifications and products without notice.
2F, No.17, Industry E. Rd. II, Science-Based Industrial Park, Hsinchu 300, Taiwan.
TEL: 886-3-6668838
FAX: 886-3-6668836
1
LY62W1024
Rev. 1.11
128K X 8 BIT LOW POWER CMOS SRAM
PIN CONFIGURATION
NC
A16
A14
A12
A7
A6
A5
A4
A3
A2
A1
A0
DQ0
DQ1
DQ2
Vss
1
2
3
4
5
6
32
31
30
29
28
27
Vcc
A15
CE2
WE#
A13
A8
A9
A11
OE#
A10
CE#
DQ7
DQ6
DQ5
DQ4
DQ3
A11
A9
A8
A13
WE#
CE2
A15
Vcc
NC
A16
A14
A12
A7
A6
A5
A4
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
OE#
A10
CE#
DQ7
DQ6
DQ5
DQ4
DQ3
Vss
DQ2
DQ1
DQ0
A0
A1
A2
A3
LY62W1024
XXXXXXXX
XXXXXXXX
SOP / PDIP
7
8
9
10
11
12
13
14
15
16
26
25
24
23
22
21
20
19
18
17
LY62W1024
XXXXXXXX
XXXXXXXX
TSOP I / sTSOP
A
B
C
D
E
F
G
H
A0
DQ4
DQ5
Vss
Vcc
DQ6
A1
A2
CE2
WE#
NC
A3
A4
A5
A6
A7
A8
DQ0
LY62W1024
XXXXXXXX
XXXXXXXX
DQ1
Vcc
Vss
NC
NC
DQ2
A15 DQ3
A13
A14
DQ7 OE# CE# A16
A9
A10
A11
A12
1
2
3
4
5
6
TFBGA(See through with top view)
TFBGA(Top View)
PS: All pin out definition are relative with “Lyontek logo” orientation.
Lyontek Inc.
reserves the rights to change the specifications and products without notice.
2F, No.17, Industry E. Rd. II, Science-Based Industrial Park, Hsinchu 300, Taiwan.
TEL: 886-3-6668838
FAX: 886-3-6668836
2
LY62W1024
Rev. 1.11
128K X 8 BIT LOW POWER CMOS SRAM
ABSOLUTE MAXIMUN RATINGS*
PARAMETER
Voltage on V
CC
relative to V
SS
Voltage on any other pin relative to V
SS
Operating Temperature
Storage Temperature
Power Dissipation
DC Output Current
SYMBOL
V
T1
V
T2
T
A
T
STG
P
D
I
OUT
RATING
-0.5 to 6.5
-0.5 to V
CC
+0.5
0 to 70(C grade)
-40 to 85(I grade)
-65 to 150
1
50
UNIT
V
V
℃
℃
W
mA
*Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress rating
only and functional operation of the device or any other conditions above those indicated in the operational sections of this specification is
not implied. Exposure to the absolute maximum rating conditions for extended period may affect device reliability.
TRUTH TABLE
MODE
Standby
Output Disable
Read
Write
Note:
CE#
H
X
L
L
L
CE2
X
L
H
H
H
OE#
X
X
H
L
X
WE#
X
X
H
H
L
I/O OPERATION
High-Z
High-Z
High-Z
D
OUT
D
IN
SUPPLY CURRENT
I
SB1
I
SB1
I
CC
,I
CC1
I
CC
,I
CC1
I
CC
,I
CC1
H = V
IH
, L = V
IL
, X = Don't care.
Lyontek Inc.
reserves the rights to change the specifications and products without notice.
2F, No.17, Industry E. Rd. II, Science-Based Industrial Park, Hsinchu 300, Taiwan.
TEL: 886-3-6668838
FAX: 886-3-6668836
3
LY62W1024
Rev. 1.11
128K X 8 BIT LOW POWER CMOS SRAM
DC ELECTRICAL CHARACTERISTICS
SYMBOL
TEST CONDITION
PARAMETER
Supply Voltage
V
CC
Input High Voltage
V
IH*1
Input Low Voltage
V
IL*2
Input Leakage Current
I
LI
V
CC
≧
V
IN
≧
V
SS
Output Leakage
V
CC
≧
V
OUT
≧
V
SS
,
I
LO
Current
Output Disabled
Output High Voltage
V
OH
I
OH
= -1mA
Output Low Voltage
V
OL
I
OL
= 2mA
Cycle time = MIN.
- 35
CE# = V
IL
and CE2 = V
IH
,
I
CC
- 55
I
I/O
= 0mA
- 70
Other pins at V
IL
or V
IH
Average Operating
Power supply Current
Cycle time = 1µ s
CE# = 0.2V and CE2≧ V
CC
-0.2V,
I
CC1
I
I/O
= 0mA
Other pins at 0.2V or V
CC
- 0.2V
LL
LLI
CE#
≧
V
CC
-0.2V
SL
*5
25
℃
Standby Power
or CE2≦ 0.2V
I
SB1
SLI
*5
40℃
Supply Current
Others at 0.2V or
V
CC
- 0.2V
SL
SLI
Notes:
1. V
IH
(max) = V
CC
+ 3.0V for pulse width less than 10ns.
2. V
IL
(min) = V
SS
- 3.0V for pulse width less than 10ns.
3. Over/Undershoot specifications are characterized, not 100% tested.
4. Typical values are included for reference only and are not guaranteed or tested.
Typical values are measured at V
CC
= V
CC
(TYP.)
and T
A
= 25℃
5. This parameter is measured at V
CC
= 3.0V
MIN.
2.7
0.7*V
CC
- 0.2
-1
-1
2.4
-
-
-
-
-
-
-
-
-
-
-
TYP.
*4
3.0
-
-
-
-
2.7
-
12
10
7
1
1
1
0.8
1
0.8
0.8
MAX.
5.5
V
CC
+0.3
0.6
1
1
-
0.4
80
60
50
10
15
30
2
2
7
10
UNIT
V
V
V
µA
µA
V
V
mA
mA
mA
mA
µA
µA
µA
µA
µA
µA
Lyontek Inc.
reserves the rights to change the specifications and products without notice.
2F, No.17, Industry E. Rd. II, Science-Based Industrial Park, Hsinchu 300, Taiwan.
TEL: 886-3-6668838
FAX: 886-3-6668836
4
Test/Measurement
