A1
G
PART NUMBER:
DWR - T X XX P - V X 3 X - 0X
10.80
.425
1.50
.059
HOUSING BLADE
ALIGNMENT
CORRECTION
HOUSING BLADE IS
OFF CENTRE TO
PREVENT IMPROPER
MATING
SERIES
DWR
PRODUCT TYPE
T = SLIMDRAWER FINISHED CONNECTOR
NUMBER OF POWER CONTACT POSITIONS
2, 4, 6 OR 8
NUMBER OF SIGNALCONTACT POSITIONS
00, 04, 06, 08, 10 ... 40
GENDER
P = PIN (MALE)
ORIENTATION
V = VERTICAL
2.74
.108
TYP.
2
3.30
.130
2
D
15.65
.616
25.81
1.016
REF
CONTACT OPTIONS
2 = POWER PIN SIZE CB8 (
3 = POWER PIN SIZE CB10 (
STD SIGNAL
3.50mm)
3.00mm)
6.35
.250
3
CONTACT TERMINATION
3 = PCB TAIL: POWER 3.75mm [.148"] DIA,
3.81mm [.150"] LONG
STD SIGNAL PCB TAIL
PLATING OPTIONS
2 = 0.38µm [15µ”] GOLD
3 = 0.76µm [30µ”] GOLD
6 = 5.08µm [200µ”] SILVER POWER,
0.38µm [15µ”] GOLD SIGNAL
MOUNTING OPTION
00 = NO MOUNTING FEATURE
01 = NO MOUNTING EARS
02 = 3.25mm [.128"] DIA THROUGH HOLE
04 = #4-40 THREADED HOLE
06 = M3 THREADED HOLE
08 = GUIDE PINS
3
ORIENTATION
PEG PREVENTS
BACKPLANE
ASSEMBLY ERRORS
0.46 [.018] x 0.76 [.030]
SIGNAL CONTACT TAILS
3.75
.148
POWER CONTACT
TAILS
3.81
.150
B
3.18
.125
4
4
SPECIAL CONFIGURATIONS
MANY UNIQUE FEATURES ARE READILY
AVAILABLE TO SUIT CUSTOMER REQUIREMENTS.
CONTACT AUTHORIZED AMPHENOL
REPRESENTATIVE FOR DETAILS.
A
CONNECTOR ORIENTATION
HOLE DOES NOT REQUIRE
PLATING
3.25
.128
A1
G
3.30
.130
1
2
1.02±0.05
.040±.002
4.11±0.08
.162±.003
3.25±0.05
.128±.002
FOR MOUNTING
CODE 02, 04 & 06;
MOUNTING FEATURE
REMOVED FOR
MOUNTING CODE
00 & 01;
2x
NOTES:
1.
MATERIALS: ALL MATERIALS ARE RoHS COMPLIANT PER EU DIRECTIVE 2011/65/EU AND AMENDMENTS
- HOUSING: HIGH TEMPERATURE RESISTANT NYLON, UL FLAMMABILITY RATING 94V-0, COLOUR BLACK
- SIGNAL CONTACTS: PHOSPHOR BRONZE PLATED WITH GOLD OVER 1.27µm (50µ”) NICKEL ON THE MATING
AREA AND 2.54µm (100µ”) MATTE TIN OVER NICKEL ON THE TAILS.
- POWER CONTACTS: COPPER ALLOY PLATED WITH GOLD OR SILVER OVER 1.27µm (50µ”) MIN NICKEL
WHEN MATED WITH SOCKET CONNECTOR DWR-TXXXS-VXXX-XX, THE ORDER OF MECHANICAL AND ELECTRICAL
ENGAGEMENT IS A) HOUSING BLADES, B) HOUSING SHROUD, C) POWER CONTACTS AND D) SIGNAL CONTACTS.
RATINGS SUBJECT TO DESIGN QUALIFICATION TESTING
- CURRENT RATING: UP TO 55A POWER, 4A SIGNAL
- INSULATION RESISTANCE: 5000 MEGOHMS
UL FILE NUMBER: E64911
S.CAELERS MAR17/11
S.MUGAN
JUN17/11
MILLIMETERS
CHECKED
INCHES
M.E. APP'D
Q.A. APP'D
DWG APPR.
ENG. REL. NO.
REF.
THIRD
ANGLE
PROJECTION
5
5
2.
3.
3.56±0.08
.140±.003
7.22
.284
2.74
.108
F
E
B
9.14
.360
5.89 0.05
[.232 .002]
FOR MOUNTING
CODE 08
2x
- DIELECTRIC WITHSTANDING VOLTAGE: 1500V DC
- OPERATING TEMPERATURE: -55°C TO +105°C
4.
UNLESS SPECIFIED OTHERWISE DRAWN
PRIMARY UNITS
Amphenol Canada Corp.
DWR SERIES SLIM DRAWER PIN CONNECTOR,
PIN & SIGNAL CONTACTS, VERTICAL PCB TAILS
( 3.75mm [.148"] x 3.81mm [.150"] LONG),
RoHS COMPLIANT
DWG.
NO.
REV
6
LOCATE HOLES
0.13 [.005] DIA
POSITION DIMENSIONS
ARE BASIC
SECONDARY
REFERENCE IN PARENTHESES
GENERAL TOLERANCES
1 DECIMAL PLACE
2 DECIMAL PLACES
6
RECOMMENDED PCB LAYOUT
COMPONENT SIDE OF BOARD
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION AND SUCH INFORMATION MAY NOT BE DISCLOSED TO OTHERS FOR
ANY PURPOSE OR USED FOR MANUFACTURING PURPOSES WITHOUT WRITTEN PERMISSION FROM AMPHENOL CANADA CORP.
A
B
C
D
3 DECIMAL PLACES
ANGULAR DEGREES
DO NOT
SCALE
DRAWING CODE ID NO.
P-DWR-TXXXP-VX3X-0X
03554
DWG SIZE:
C
SCALE:
D
1
OF
2
2:1
H
SHEET
E
F
G
A
B
C
D
E
F
G
REVISIONS
REV
DESCRIPTION, ECN, EAR NO.
H
Pin Connector
Part number
Number Number
of Power of Signal
Contacts Contacts
2
2
2
2
2
2
2
2
2
2
2
4
4
4
4
4
4
4
4
4
4
4
6
6
6
6
6
6
6
6
6
6
6
8
8
8
8
8
8
8
8
8
8
8
0
4
8
12
16
20
24
28
32
36
40
0
4
8
12
16
20
24
28
32
36
40
0
4
8
12
16
20
24
28
32
36
40
0
4
8
12
16
20
24
28
32
36
40
1
2
3
4
DWR-T200P-VXXX-XX
DWR-T204P-VXXX-XX
DWR-T208P-VXXX-XX
DWR-T212P-VXXX-XX
DWR-T216P-VXXX-XX
DWR-T220P-VXXX-XX
DWR-T224P-VXXX-XX
DWR-T228P-VXXX-XX
DWR-T232P-VXXX-XX
DWR-T236P-VXXX-XX
DWR-T240P-VXXX-XX
DWR-T400P-VXXX-XX
DWR-T404P-VXXX-XX
DWR-T408P-VXXX-XX
DWR-T412P-VXXX-XX
DWR-T416P-VXXX-XX
DWR-T420P-VXXX-XX
DWR-T424P-VXXX-XX
DWR-T428P-VXXX-XX
DWR-T432P-VXXX-XX
DWR-T436P-VXXX-XX
DWR-T440P-VXXX-XX
DWR-T600P-VXXX-XX
DWR-T604P-VXXX-XX
DWR-T608P-VXXX-XX
DWR-T612P-VXXX-XX
DWR-T616P-VXXX-XX
DWR-T620P-VXXX-XX
DWR-T624P-VXXX-XX
DWR-T628P-VXXX-XX
DWR-T632P-VXXX-XX
DWR-T636P-VXXX-XX
DWR-T640P-VXXX-XX
DWR-T800P-VXXX-XX
DWR-T804P-VXXX-XX
DWR-T808P-VXXX-XX
DWR-T812P-VXXX-XX
DWR-T816P-VXXX-XX
DWR-T820P-VXXX-XX
DWR-T824P-VXXX-XX
DWR-T828P-VXXX-XX
DWR-T832P-VXXX-XX
DWR-T836P-VXXX-XX
DWR-T840P-VXXX-XX
"A"
Overall
Length
mm
inch
47.70
1.878
54.10
2.130
59.59
2.346
65.07
2.562
70.56
2.778
76.05
2.994
81.53
3.210
87.02
3.426
92.51
3.642
97.99
3.858
103.48 4.074
65.99
2.598
72.39
2.850
77.88
3.066
83.36
3.282
88.85
3.498
94.34
3.714
99.82
3.930
105.31 4.146
110.79 4.362
116.28 4.578
121.77 4.794
84.28
3.318
90.68
3.570
96.16
3.786
101.65 4.002
107.14 4.218
112.62 4.434
118.11 4.650
123.60 4.866
129.08 5.082
134.57 5.298
140.06 5.514
102.57 4.038
108.97 4.290
114.45 4.506
119.94 4.722
125.43 4.938
130.91 5.154
136.40 5.370
141.88 5.586
147.37 5.802
152.86 6.018
158.34 6.234
"B"
Mounting Hole
Centrelines
mm
inch
36.53
1.438
42.93
1.690
48.41
1.906
53.90
2.122
59.39
2.338
64.87
2.554
70.36
2.770
75.84
2.986
81.33
3.202
86.82
3.418
92.30
3.634
54.81
2.158
61.21
2.410
66.70
2.626
72.19
2.842
77.67
3.058
83.16
3.274
88.65
3.490
94.13
3.706
99.62
3.922
105.11
4.138
110.59
4.354
73.10
2.878
79.50
3.130
84.99
3.346
90.47
3.562
95.96
3.778
101.45
3.994
106.93
4.210
112.42
4.426
117.91
4.642
123.39
4.858
128.88
5.074
91.39
3.598
97.79
3.850
103.28
4.066
108.76
4.282
114.25
4.498
119.74
4.714
125.22
4.930
130.71
5.146
136.19
5.362
141.68
5.578
147.17
5.794
"C"
Length Without
Mounting Ears
mm
inch
29.75
1.171
36.15
1.423
41.63
1.639
47.12
1.855
52.61
2.071
58.09
2.287
63.58
2.503
69.06
2.719
74.55
2.935
80.04
3.151
85.52
3.367
48.03
1.891
54.43
2.143
59.92
2.359
65.41
2.575
70.89
2.791
76.38
3.007
81.87
3.223
87.35
3.439
92.84
3.655
98.33
3.871
103.81
4.087
66.32
2.611
72.72
2.863
78.21
3.079
83.69
3.295
89.18
3.511
94.67
3.727
100.15
3.943
105.64
4.159
111.13
4.375
116.61
4.591
122.10
4.807
84.61
3.331
91.01
3.583
96.50
3.799
101.98
4.015
107.47
4.231
112.96
4.447
118.44
4.663
123.93
4.879
129.41
5.095
134.90
5.311
140.39
5.527
"D"
Pin Body
Length
mm
inch
26.57
1.046
32.97
1.298
38.46
1.514
43.94
1.730
49.43
1.946
54.91
2.162
60.40
2.378
65.89
2.594
71.37
2.810
76.86
3.026
82.35
3.242
44.86
1.766
51.26
2.018
56.74
2.234
62.23
2.450
67.72
2.666
73.20
2.882
78.69
3.098
84.18
3.314
89.66
3.530
95.15
3.746
100.63 3.962
63.14
2.486
69.55
2.738
75.03
2.954
80.52
3.170
86.00
3.386
91.49
3.602
96.98
3.818
102.46 4.034
107.95 4.250
113.44 4.466
118.92 4.682
81.43
3.206
87.83
3.458
93.32
3.674
98.81
3.890
104.29 4.106
109.78 4.322
115.27 4.538
120.75 4.754
126.24 4.970
131.72 5.186
137.21 5.402
"E"
Outside Power
Centrelines
mm
inch
9.14
0.360
15.54
0.612
21.03
0.828
26.52
1.044
32.00
1.260
37.49
1.476
42.98
1.692
48.46
1.908
53.95
2.124
59.44
2.340
64.92
2.556
27.43
1.080
33.83
1.332
39.32
1.548
44.81
1.764
50.29
1.980
55.78
2.196
61.26
2.412
66.75
2.628
72.24
2.844
77.72
3.060
83.21
3.276
45.72
1.800
52.12
2.052
57.61
2.268
63.09
2.484
68.58
2.700
74.07
2.916
79.55
3.132
85.04
3.348
90.53
3.564
96.01
3.780
101.50 3.996
64.01
2.520
70.41
2.772
75.90
2.988
81.38
3.204
86.87
3.420
92.35
3.636
97.84
3.852
103.33 4.068
108.81 4.284
114.30 4.500
119.79 4.716
"F"
Inside Power
Centrelines
mm
inch
9.14
0.360
15.54
0.612
21.03
0.828
26.52
1.044
32.00
1.260
37.49
1.476
42.98
1.692
48.46
1.908
53.95
2.124
59.44
2.340
64.92
2.556
9.14
0.360
15.54
0.612
21.03
0.828
26.52
1.044
32.00
1.260
37.49
1.476
42.98
1.692
48.46
1.908
53.95
2.124
59.44
2.340
64.92
2.556
9.14
0.360
15.54
0.612
21.03
0.828
26.52
1.044
32.00
1.260
37.49
1.476
42.98
1.692
48.46
1.908
53.95
2.124
59.44
2.340
64.92
2.556
9.14
0.360
15.54
0.612
21.03
0.828
26.52
1.044
32.00
1.260
37.49
1.476
42.98
1.692
48.46
1.908
53.95
2.124
59.44
2.340
64.92
2.556
"G"
Outside Signal
Centrelines
mm
inch
---
--
2.74
0.108
8.23
0.324
13.72
0.540
19.20
0.756
24.69
0.972
30.18
1.188
35.66
1.404
41.15
1.620
46.63
1.836
52.12
2.052
---
---
2.74
0.108
8.23
0.324
13.72
0.540
19.20
0.756
24.69
0.972
30.18
1.188
35.66
1.404
41.15
1.620
46.63
1.836
52.12
2.052
---
---
2.74
0.108
8.23
0.324
13.72
0.540
19.20
0.756
24.69
0.972
30.18
1.188
35.66
1.404
41.15
1.620
46.63
1.836
52.12
2.052
---
---
2.74
0.108
8.23
0.324
13.72
0.540
19.20
0.756
24.69
0.972
30.18
1.188
35.66
1.404
41.15
1.620
46.63
1.836
52.12
2.052
DATE
APP'D
B
C
D
SOCKET UPDATE
GUIDE PIN UPDATE (EAR14097)
ADD UL FILE NUMBER
MAR21/12
JUN19/12
MAY15/13
S.M
S.M
S.M
1
20.71
.815
REF
28.33
1.115
REF
2
MOUNTING OPTIONS
MOUNTING CODE:
00
MOUNTING CODE:
01
MOUNTING CODE:
02
A
C
3.25
.128
B
3
A
B
THREADED
INSERT
A
4
FOR INTERMEDIATE CONFIGURATIONS (NUMBER OF SIGNAL CONTACTS = 06, 10, 14 ...) DIMENSIONS CAN BE CALCULATED BY AVERAGING VALUES
IMMEDIATELY BEFORE AND AFTER. FOR EXAMPLE, DIMENSIONS OF DWR-T206P-VXXX-XX CAN BE OBTAINED BY AVERAGING VALUES
CORRESPONDING TO DWR-T204P-VXXX-XX AND DWR-T208P-VXXX-XX.
THREADED HOLE
TAPPED THROUGH
3.00
.118
B
A
32.39
1.275
5
GUIDE PIN
SECURED
WITH SCREW
AND LOCK
WASHER
5
MOUNTING CODE:
04, 06
UNLESS SPECIFIED OTHERWISE DRAWN
PRIMARY UNITS
SECONDARY
MOUNTING CODE:
08
JUN17/11
S.CAELERS MAR17/11
S.MUGAN
MILLIMETERS
CHECKED
INCHES
M.E. APP'D
Q.A. APP'D
DWG APPR.
Amphenol Canada Corp.
DWR SERIES SLIM DRAWER PIN CONNECTOR,
PIN & SIGNAL CONTACTS, VERTICAL PCB TAILS
( 3.75mm [.148"] x 3.81mm [.150"] LONG),
RoHS COMPLIANT
DWG.
NO.
REV
6
REFERENCE IN PARENTHESES
GENERAL TOLERANCES
1 DECIMAL PLACE
2 DECIMAL PLACES
6
ENG. REL. NO.
REF.
THIRD
ANGLE
PROJECTION
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION AND SUCH INFORMATION MAY NOT BE DISCLOSED TO OTHERS FOR
ANY PURPOSE OR USED FOR MANUFACTURING PURPOSES WITHOUT WRITTEN PERMISSION FROM AMPHENOL CANADA CORP.
A
B
C
D
3 DECIMAL PLACES
ANGULAR DEGREES
DO NOT
SCALE
DRAWING CODE ID NO.
P-DWR-TXXXP-VX3X-0X
03554
DWG SIZE:
C
SCALE:
D
2
OF
2
2:1
H
SHEET
E
F
G
Motor Drive Control（Motor Control）
京公网安备 11010802033920号
EEWORLD
